Side 1/12
Operating Instructions
For more products, accessories and our product support knowledge base, please visit
TurtleBeach.com
For warranty information, please visit http://support.turtlebeach.com
EAR FORCE
EAR FORCE
EAR FORCE
EAR FORCEEAR FORCE
X4
X4
X4
X4X4
R
R
R
Package Contents
System Requirements
o
o
o
o
o
o
o
o
o
X4 wireless headphones
Removable boom microphone
Foam cover for microphone
X4 infrared transmitter
X4 DC power adapter
(2) AAA batteries
Xbox controller cable (”puck”)
This Quick Start Guide
Digital Optical cable
Wireless Gaming Headphones with
and Dolby 5.1 Channel Surround Sound
XBOX Live Chat
Copyright © 2008 Voyetra Turtle Beach, Inc. (VTB, Inc.) All Rights Reserved. No part of this document may be reproduced without
permission. The Turtle Beach Logo, Ear Force, Play Like a Pro, All Your Ears Are Belong to Us and Turtle Beach are registered trademarks of
VTB, Inc. Chat Boost and X4 are trademarks of VTB, Inc. Xbox and XBOX Live are registered trademarks of Microsoft Corporation.
All other Trademarks are properties of their respective
owners and are hereby acknowledged. Product Features, visual design, prices, package contents and specifications are subject to change
without notice. V1 P/N TBS-2067-01
Dolby,
Pro Logic, and the double-D symbol are registered trademarks of Dolby Laboratories.
Manufactured under license from Dolby Laboratories.
o
s
s
s
s
o
o
o
XBOX 360 game console with one of the
following cables to support digital output:
Xbox 360 Component HD AV cable
VGA HD AV cable
S-Video AV cable
Advanced SCART AV cable
XBOX Live requires a subscription.
Power adapter requires connection to AC power.
The X4 XBOX controller puck is not compatible
with XBOX 360 Messenger Kit (a/k/a “Chatpad”)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures: (1.) Reorient or relocate the
receiving antenna. (2.) Increase the separation between the equipment and receiver. (3.) Connect the
equipment into an outlet on a circuit different from that to which the receiver is connected. (4.) Consult
the dealer or an experienced radio TV technician for help.
RoHS
COMPLIANT
2002/95/EC
Ear Force X4 Operating Instructions. Version 1.0 Copyright 2008 Voyetra Turtle Beach, Inc. All Rights Reserved Page 1
The Ear Force X4 Dolby surround sound gaming headphone system uses an infrared
signal to transmit wireless game audio from the XBOX 360 to the X4 wireless
headphones. The X4 transmitter uses Dolby Headphone technology to produce a
more realistic game experience by recreating the sound of a 5.1 channel speaker
system with the X4 stereo headphones. The X4 incorporates the following features
designed specifically to enhance Xbox 360 gaming:
Dolby Digital, Dolby Pro Logic II and Dolby Headphone processing technology.
Digital and analog inputs for listening to the XBOX and other audio sources.
High powered IR beam covers a wide reception range for freedom of movement
during game play.
Large, soft ear cushions and lightweight design for optimum comfort during long
gaming sessions.
Chat Boost automatically adjusts Xbox Live chat levels during loud game play.
Microphone monitor lets you hear what you’re saying.
Bass boost enhances deep game sounds.
Independent volume controls for balancing game and chat levels.
Automatic power-off function turns off the headphones after a period of no sound to
conserve battery power.
n
n
n
n
n
n
n
n
n
Main Features
X4 Transmitter
X4 Headphones
n
n
n
n
n
n
n
n
n
n
n
n
n
50mm diameter speakers with neodymium magnets
IR FM modulated carrier reception (2.3/2.8MHz)
Speaker Frequency Response: 20Hz - 20kHz , >120dB SPL @ 1kHz
Condenser Microphone : 50Hz - 15kHz
Headphone Amplifier: Stereo DC-coupled, 35mW/ch, THD <1%, Frequency Response: DC - 30kHz
Bass Boost: +9dB @20Hz - 150Hz
Chat Boost Talkback Expander: +10dB gain boost at maximum game volume
Audio mutes automatically when carrier signal is lost
Quad IR sensors for full 360 degree reception range
Operates on dual AAA batteries
Automatic battery power shut down after approx 2 minutes of carrier loss
Battery life: Greater than 20 hours of continuous use with alkaline cells
Weight: 9.5 Oz (270g)
Frequency Response
nIR FM Modulated carrier transmission (2.3/2.8MHz).
Automatic shut down of carrier transmission after approx. 2 minutes of silence
IR transmission range at zero degrees > 30 feet.
Automatic Gain Control (AGC) on FM transmitter limits carrier over-modulation.
Frequency response: 20Hz - 20kHz
Optical TOSLINK digital audio input compatible with 48kHz digital audio stream
Optical TOSLINK digital audio output pass-through of digital input stream.
150MIPS Digital Signal Processor for Dolby processing
Maximum analog input level with volume control on maximum setting: 2Vpp (700mV rms). Input
sensitivity may be adjusted to accept higher level signals by lowering the volume control.
Weight: 8.4 Oz (240g)
Power adapter: 9VDC @360mA (100VAC - 240VAC)
n
n
n
n
n
n
n
n
n
n
Technical Specifications
Ear Force X4 Operating Instructions. Version 1.0 Copyright 2008 Voyetra Turtle Beach, Inc. All Rights Reserved Page 2
