Side 1/2
VT-61003
104771, 104781
104791
78551, 78561
78571
MODEL SKU WATTS
LUMENS
BODY
TOTAL
CURRENT
INPUT
VOLTAGE
CRI
LIFE
SPAN
ON/OFF
CYCLE
SHAPE
DIMENSION
(LxWxH)
BEAM
ANGLE
IP
RATING
3W
Sphere
360°
Sphere
360°
Sphere
360°
Sphere
360°
Sphere
360°
PLASTIC
IP20
>80
>80
>80
>80
>80
IP20
IP20
IP20
IP20
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
AC:220-240
50/60Hz
26mA 20000H >15000
20000H >15000
20000H >15000
20000H >15000
20000H >15000
φ90.5x28mm
90.2x90.2x28.2mm
120.5x120.5x28.4mm
170.8x170.8x28.4mm
220.4x220.4x28.8mm
295x295x28.6mm
φ294x29.1mm
φ120.5x28.4mm
φ170.8x28.4mm
φ220.8x28.9mm
ROUND
SQUARE
SQUARE
SQUARE
SQUARE
SQUARE
ROUND
ROUND
ROUND
ROUND
36mA
71mA
103mA
160mA
PLASTIC
PLASTIC
PLASTIC
PLASTIC
660LM
330LM
1200LM
1850LM
1980LM
2500LM
2640LM
6W
12W
18W
24W
VT-61006
VT-61012
VT-61018
VT-61024
3W
ROUND PANEL
φ80
(7 7-82mm)
φ110
(107-112mm)
φ155
(150-155mm)
φ205
(200-205mm)
φ280
(275-280mm)
6W 12W 18W 24W
INSTALLATION
HOLE SIZE
1.Cut a hole using an appropriate tool according to the cut-out size.
4. Check whether the lamp is flat and electrified.
5. Clean the lamp with clean cloth.
6. Switch on the power and test the light.
3. Hold the two clips back against the panel light and push it
into the hole. Allow the springs to pull the light up to the ceiling.
2.Switch OFF the power & Connect
AC: 220-240V voltage with terminals.`
RECESSED PANEL INSTALLATION DIAGRAM
LED BACKLIT RECESSED PANEL
TECHNICAL DATA
INTRODUCTION & WARRANTY
WARNING
ATTENTION!
USAGE GUIDELINES/MAINTENANCE
MOUNTING
INSTRUCTION MANUAL
'This product contains a light source of energy eciency class <F/E>', where <F/E> shall be replaced by
the energy eciency class of the contained light source.
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instruc-
tions carefully before starting the installation and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They
are trained and ready to serve you at the best. The warranty is valid for 5 years from the date of purchase. The
warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The company
gives no warranty against damage to any surface due to incorrect removal and installation of the product. The
products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the
warranty. This product is warranted for manufacturing defects only.
Do not look directly at LED light beam. Product can only be supplied by rated voltage or voltage within
the range provided. It's forbidden to use the product with damaged protective cover. Product must not be
used in unfavorable conditions, e.g. dust, water, moisture, vibrations, explosive air atmosphere, fumes, or
chemical fumes, etc. In the area of strong electromagnetic interference, the functioning of the product
may be disrupted.
Any maintenance work must be performed when the power supply is cut o and the product has cooled
down. Clean only with so and dry cloths. Do not use chemical detergents. Do not cover the product.
Ensure free air access. Product may heat up to a higher temperature.
Read the manual before mounting. Mounting should be performed by a qualified electrician. Exercise
caution. Product has a protective contact /terminal. Failure to connect the protective lead may lead to
electric shock. Mounting diagram: see pictures. Check for proper mechanical fastening and connection to
electrical power prior to first use.
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a certified person.
• For Indoor use only
• The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person.
• If the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
• Method of attachment of the cable or cord such that any replacement can
only be made by the manufacturer, his service agent or similar qualifed
person.
This marking indicates that this
product should not be disposed
of with other household wastes.
Replaceable (LED only)
light source by a professional
Caution, risk of electric shock.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
SPHERE
STAYS BRIGHT
360°
104801,104811
104821
78581,78591
78601
104831,104841
104851
78611, 78621
78631
104861, 104871
104881
78641, 78651
78661
104891,104901
104911
78671, 78681
78691
3W
SQUARE PANEL
(75-80mm)
110*110
(105-110mm)
155*155
(150-155mm)
205*205
(200-205mm)
280*280
(275-280mm)
6W 12W 18W 24W
INSTALLATION
HOLE SIZE
1.Cut a hole using an appropriate tool
according to the cut-out size.
4. Check whether the lamp is flat and electrified.
5. Clean the lamp with clean cloth.
6. Switch on the power and test the light.
3. Hold the two clips back against the panel light and push it
into the hole. Allow the springs to pull the light up to the ceiling.
2.Switch OFF the power & Connect
AC: 220-240V voltage with terminals.`
4.Press the buckle outwards,
remove the aluminum substrate
pressing strip from the bayonet,
and remove the pressing strip.
This step is only required for
24W panel light, other items are
not required.
5.Press the buckle outwards,
remove the aluminum substrate
from the buckle, and remove
the light source board.
6.Take out two-cord cable (wire diameter
18-22AWG) and insert it into the plug-in
terminal. Connect the external power
supply for testing.
1.Power o, tap the central area of the
diusion plate with a pointed tool, and
take out the cracked diusion plate
2.Remove the power wire from the
plug terminal
3.If there is no hot melt column in the
lamp body or the hot melt column is
not hot melt,this step will be adjusted
without treatment.If the hot-melt column
has been fused to fix the aluminum
substrate,cut the hot-melt part of the
hot-melt point with diagonal pliers.
DISASSEMBLY DIAGRAM
(For Market surveillance team only)
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC
EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
