SOLAR LED STREET LIGHT WITH SENSOR
INSTRUCTION MANUAL
TECHNICAL DATA
BATTERY SPECIFICATIONS
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future reference. If you
have any another query, please contact our dealer or local vendor from whom you have purchased the
product. They are trained and ready to serve you at the best. The warranty is valid for 3 years from the date
of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal wear
and tear. The company gives no warranty against damage to any surface due to incorrect removal and
installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of product for
24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MODEL
SKU
POWER/LUMEN
BEAM ANGLE
LEDS
SOLAR PANEL
DETECTION ANGLE/AREA
DIMENSION
INSTALLATION HEIGHT
LIFESPAN
BODY TYPE
VT-ST20CCT
24099
20W / 3000LM
140° x70°
SMD2835 x 96PCS
12.5W, Mono Crystalline Silicon
120°/ 3-8Mtrs
232x492.5x58MM
3-5Mtr
35,000hrs
ABS+PC
BATTERY
CHARGING TIME
WORKING TIME
Lithium, 18650/7.4V/5400mAh, Replaceable
6-7Hrs
Mode A: 60Hr Max. Mode B: 45Hr
