Side 1/1

LED SOLAR FLOODLIGHT

INTRODUCTION & WARRANTY

Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these

instructions carefully before starting the installing and keep this manual handy for future reference. If you

have any another query, please contact our dealer or local vendor from whom you have purchased the

product. They are trained and ready to serve you at the best. The warranty is valid for 2 years from the

date of purchase. The warranty does not apply to damage caused by incorrect installation or abnormal

wear and tear. The company gives no warranty against damage to any surface due to incorrect removal

and installation of the product. This product is warranted for manufacturing defects only.

WARNING!

1. Please make sure to turn o the power before starting the installation.

2. Installation must be performed by a qualiﬁed electrician.

3. The light source of this luminaire is not replaceable; when the light source reaches its end of life the

whole luminaire shall be replaced.

4. If the external ﬂexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by

the manufacturer or his service agent or a similar qualiﬁed person in order to avoid a hazard.

5. Replace any cracked protective shield.

This marking indicates that this product should

not be disposed of with other household

wastes.

INSTALLATION GUIDE:

MAINTENANCE & WARNING

TECHNICAL DATA:

PARTS INCLUDED

REMOTE CONTROL

INSTALLATION

Plug the twist after e twist cap

Use 2 e xpans ion screws t

fix the s olar lamp on the wall

all

Use 2 expansion screws to

fix the s olar panels on the wall

1. Before installing please remove all the parts to check if all are in good condition or not.

2. The luminaire is connected to the solar panel against the sun light. Please makes sure the solar panel

is adjusted in correct angle in order to receive sunlight.

3. The remote control is designed with an operation distance of 8-15m

A. The lamp comes with two inﬂated studs as shown in the parts included section.

B. The solar panel Angle must be adjusted in correct direction to receive sunlight.

C. Lamps cannot be installed in low-lying areas, so as not to soak;

5. Plug the male and female plugs and tighten the waterproof cap and install it.

6. Aer installation test the light using the remote control.

• Do not use solvents, petrol, etc. Otherwise the light will be damaged.

• Clean the light with a dry, lint-free cloth.

• Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee ﬂawless function of

the product.

• Especially during the winter, keep the product free from snow and ice.

• Conﬁrm installation direction is correct (solar panel should be at top)

• Conﬁrm no objects blocking the solar panel to receive sunlight

• Keep away from the ﬁre.

• Don't immerse in the water

Wireles s

remote control

Time

switch

lntelligent

light control

NOTE: The battery must be

fully charged before using 3-5

rainy days

IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU

FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.

V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B

MODEL SKU LUMENS

VOLTAGE

PANEL SIZE UNIT SIZE

BATTERY

CAPACITY

OPERATION

TEMPERATURE

CHARGING

TIME

WORKING

TIME

INSTALLATION

HEIGHT

VT-40W

7821,7822

7839,7840

7823,7824

7841,7842

7825,7826

7843,7844

7827,7828

7845,7846

7829,7830

7847,7848

400LM

6W 174x260mm 170x190x55mm

3.2V, 5000mah

4-6 H

12 H

2.5 - 3 M

3 - 3.5 M

3.5 - 4 M

4 - 4.5 M

4.5 - 5 M

VT-80W

800LM

10W

174x340mm 170x190x55mm

3.2V, 6000mah

4-6H

12H

VT-120W

1200LM 6V

15W

235x350mm

180x235x55mm

3.2V, 12000mah

4-6H

12H

VT-180W

1800LM

20W 390x300mm

235x290x55mm

3.2V, 16000mah

4-6H

12H

SOLAR

PANEL

WATTS

MULTI-LANGUAGE MANUAL QR CODE

Please scan the QR code to access the manual in

multiple languages.

VT-240W

2600LM

30W

390x340mm

260x365x55mm

3.2V, 20000mah

4-6H

12H

Solar Flood LightSolar Panel

Remote Control

3 Meter WireExpansion Screw

Force to turn on the lights

(Optical control is null)

Force turn o the lights

(Optical control is null)

High Bright

Low Bright

Optically Controlled Mode

5 Hours Regular

8 Hours Regular

3 Hours Regular

-20C~60C

PAP

INSTRUCTION MANUAL
