Side 1/4
1 605 947
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualied service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ISSUE 1
VIP- 997
INTERIOR / EXTERIOR IP STROBE
INTRODUCTION
T VIP-997 Interior/Exterior IP Strobehe
private mode notication appliance provides
bright strobe functionality with both power and
activation provided by the IP network. Multiple
strobes may be synchronized to ash in
unison.
SPECIFICATIONS
Features
Cost eective and versatile solution to
applications requiring visual alerts or strobes
Power over Ethernet (PoE) 802.3af
compatible
Night Ring functionality in conjunction with
other Valcom IP speakers
Synchronized strobing when used with
additional VIP-997 strobes
Activation Methods
Valcom Group Page
SIP Phone Call
Dimensions / Weight
9.0"H x 7.8"W x 5.5 "D
( . cm H x 19.8cm W x 13. m D)22 86 97c
3.3 lbs. (1.5 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch 6W
Environment
Temperature: - 40° to +7 0° C
Humidity: 0 to 85% non-precipitating
These products are intended for use with a UL
Listed power source marked “Class 2” or
“LPS” rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended
for intra-building.
Precautionary Designations
WARNING: To Reduce The Risk Of
Fire Or Electric Shock. Do Not Expose
This Apparatus To Rain Or Moistur e.
AVERTISSEMENT: An de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système
à la pluie ou à l'humidité.
Apparatus shall not be exposed to
dripping or splashing and no objects
lled with liquids, such as vases, shall
be placed on the apparatus.
L’appareil ne doit pas être exposé à
des égouttements et éclaboussures et
aucun Objet Rempli de liquide, comme
vase, ne doit être placé sur l’appareil.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is
operated in a commercial environment.
This equipment generates, uses and can
radiate radio frequency energy and if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential
2 947605
area may cause harmful interference in
which case the user will be required to
correct the interference at his own
expense.
INSTALLATION
Operation
The VIP-997 provides private mode
notication via network connection. Activation
of the strobe is triggered by including the
VIP-997 as a member of a Valcom IP Paging
group. The VIP-997 can also operate as a
visual Night Ring device in conjunction with a
SIP PBX and can provide audio Night Ring to
other Valcom IP speakers when activated.
Interface to customer telephone system can
be via SIP registration to a Voice over IP
(VoIP) telephone system, or FXO port (when
used with a Valcom Enhanced Station Port).
Mounting
The VIP-997 is designed for double-gang
electrical box mounting, or can be attached
directly to a solid surface. The VIP-997 is
labeled with an arrow indicating the UP
direction and the VIP-997 must be installed in
that orientation. (Figure 2)
If mounting to an outlet box (Figure 3), conrm
the outlet box is securely installed following
the outlet box manufacturer’s directions. If
installing directly to a solid surface, note the
information shown in Figure 4 for secure
mounting to stud walls. For other types of wall
construction, use appropriate fasteners.
Network Connection
A weatherproof connector for the premise
ethernet cable is pre-assembled to the
VIP-997 strobe. Use a standard ethernet
cable to connect the strobe to the local
network.
IMPORTANT: If using a pre-terminated
ethernet cable, verify the RJ45 cable end will
t through the End Cap opening of the
weatherproof connector. If a boot is used
around the RJ45 connector, it must not extend
more than 35mm from the end of the RJ45
connector.
To connect the premise cable (shown in
Figure 1),unscrew the End Cap [1] and
Threaded Barrel [3] from the open end of the
connector. Remove the Rubber Bushing [2]
from the Threaded Barrel. Insert the ethernet
cable from the network through the End Cap
and Threaded Barrel and place the Rubber
Bushing around the ethernet cable between
the End Cap and Barrel.
Insert the network cable RJ45 connector into
the RJ45 jack in the Main Barrel [5]. Conrm
the Gasket [4] is in place, then insert the
Threaded Barrel into the Main Barrel and
tighten. Slide the Rubber Bushing into the end
of the Threaded Barrel, then screw the End
Cap onto the Threaded Barrel and tighten.
Power Connections
The only method of powering the VIP-997 is
via a Power over Ethernet (PoE) switch or
power injector meeting the 802.3af
specication. Make all required signal
connections before connecting to Ethernet
switch or power injector meeting the 802.3af
specication.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chion sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplicateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not t into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la che polarisée ou de mise à la terre. Une
che polarisée possède deux lames dont une plus large que l'autre. Une che de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la che fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise obsolète.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specied by the manufacturer.
N'utilisez que des xations / accessoires spéciés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specied
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
damaged, liquid has been spilled, objects have fallen into the apparatus or the
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la che est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
