The Tornado Platinum Tour Edition and T-3000 tables are assembled with rods and

men installed at the factory for ease of setup. These helpful steps will clearly guide

you from “two boxes” to “fully functional in Foosball.”

The tables come packed in two boxes for ease of assembly. Each is a matched pair

consisting of two different size boxes that will have matching serial numbers. If re-

ceiving more than one table Do not mix and match the tops and bottoms, as they —

will not fit correctly. To properly move and assemble a table, have these handy

• At least one helper

• A Two-wheel dolly to move the boxes

• A Hammer

• A power screwdriver or drill with #2 Phillips bit

(or a Phillips screwdriver)

• A 3/4” open-end wrench to lock the leg levelers

• A ratchet with a 9/16” socket, or 9/16” wrench

• A level. The larger the better, up to about 24 inches

• Clean, dry cloths

• For a coin table: Coins to test the push chute mechanism

 Open the smaller box first. It contains the base of the cabinet.

 After you have taken off the lid stand the table up on its end and get the box out

of the way. To avoid scratching the table, this is best done on carpet or card-

board.

 Watch for any loose items that may fall out of the base .

 While the table is on its end knock out the blocks retaining the legs with a ham-

mer. Be careful they don’t fall on you.

 Remove the nuts and washers and install the bottom legs first, then the top

ones. This is your best chance to make sure the nuts are snug.

 If the leg levelers are not fully turned in, do so. You will loosen them later when

leveling the table.

 Now stand the base up. Good idea to have a helper to catch it.

 Place the base where you want the game to be installed.

 Open the parts pack and install the coin mechanism with 4 screws and washers

and 2 allen bolts connect it to the ball trap.

 You will remove a block that holds the ball trap in place. Test the mechanism a

few times to make sure the trap rotates properly and that the coin meter moves

1 number each time.

 Note that the diamond tray on the right end is removable for access to the coin

box.

 Note that the ready ramp in front lifts out to see the ball return rail.

 ON COIN TABLES, drop all the balls on one of the return ramps and test the coin

mech. The trap should rotate and dump into the ready exactly 9 balls

ramp. The other 6 balls will fall into the other side of the trap. Unlock both cabi-

net locks on the outside of the base, to prevent them from bending when you

put the top on .

 Stand the second box on end, pop the straps and remove the cardboard. The

top will only come out one way.

 Examine the hinges on both the base and the top to see how they fit together.

 Pick up the top by the ends hold it vertically and slide the hinges together, and

carefully lower the top.

 Open the top by grabbing the 5 man handle and 3 man handle pushed all the

way in and lift. Raise the prop stick and place it under the bolt indicated with an

arrow.

 Remove the parts pack, (because it will be really make sure you have the keys

hard to open the table if you lock the keys inside).

 Carefully close the table and test the locks.

 Use two acorn nuts from the parts pack to secure the hinges together (if you lock

the keys inside, removing these acorn nuts will allow you to open the table)

 Install the score beads on both ends of the table .

 Level the table. Best to use a 24 inch level directly on the playfield. Level each

end first placing the level between the goalie rod and 2 man rod. Easiest way is

to squat, put one knee under the table, and then lift by going to tiptoe. After the

ends are level put the level long ways on the center of the table. If one end is

low raise it by screwing out both levelers an equal amount.

 Lubricate the table using the bottle of silicone provided:

• Use a dry rag to wipe off both ends of each rod first.

• Start with a goalie rod pulled all the way to you.

• Put one drop on the top of the rod close to the outside of the cabinet and spin it

in and out.

• Then push it in, lean across and put one drop on the other end just outside the

cabinet.

• Spin in and out a couple more times.

• Repeat with all rods.

 Take a dry cloth and lightly wipe the lubricated rods in case there are any drop-

lets that might escape onto the surface.
