Side 1/24

SOL14

AMORPHOUS SILICON SOLAR PANEL - 60W

ZONNEPANEEL IN AMORF SILICIUM - 60 W

PANNEAU SOLAIRE EN SILICIUM AMORPHE - 60 W

PLACA SOLAR DE SILICIO AMORFA - 60 W

SOLARZELLENPLATTE AUS AMORPHEM SILIZIUM - 60 W

USER MANUAL

GEBRUIKERSHANDLEIDING

NOTICE D’EMPLOI

MANUAL DEL USUARIO

BEDIENUNGSHANDLEITUNG

SOL14_v3 VELLEMAN

SOL14 – AMORPHOUS SILICON SOLAR PANEL - 60W

1. Introduction

To all residents of the European Union

Important environmental information about this product

This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the

environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a

specialized company for recycling. This device should be returned to your distributor or to a local recycling service.

Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into service. If the device was

damaged in transit, do not install or use it and contact your dealer.

2. Parts List

P1 - Amorphous Silicon Panel P2 - Screw Set (M5x45.M5x55.M5) P3 - Charge Regulator (5A)

Qty Qty Qty

28 1

P4 - Fuse (5A) P5 - Extension Cable P6 - 4-Pin Connector

Qty Qty Qty

P7 - Adapter Cable P8 - Male CLA Adapter Cable P9 - Battery Clamp Adapter Cable

Qty Qty Qty

3. Safety Instructions

• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer will not

accept responsibility for any ensuing defects or problems.

• Switch off the power before connecting or disconnecting the application.

• Never reverse the polarity of the load, the solar panel and the battery.

• Do not connect any other power supplies or chargers to this unit.

Produkt Specifikationer

Mærke:	Velleman
Kategori:	Batterioplader
Model:	SOL14
Vægt:	28400 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-40 - 85 °C
Driftstemperatur (T-T):	-40 - 85 °C
Dimensioner (BxDxH):	315 x 1420 x 950 mm
Pakketype:	Kasse
Batterier inkluderet:	Ingen
Udgangsspænding:	17.5 V
Effektkrav:	12V F/CLA; 5.5V USB; 3V, 6V, 9V, 12V DC
Kapabilitet:	SOL/SPC1
Kemisk sammensætning:	amorphous silicon
Emballage:	Karton
