Handheld Quick Start Guide
See full manual for more detail
Register sprayers with serial number & date
Charge Battery Remove & Fill Tank Connect Tank
1. Align tank grooves into
slide rail & lower sprayer
3. Rotate collar to locked
The optimum sprayer distance is 2-3 feet
(0.6-0.9 m) from surface being sprayed
Spray in an “S” like fashion from top to
Start at opposite end of room & progress
toward the door to avoid walking through
spray pattern & touching sprayed surfaces
1. Rotate collar to unlocked
2. Pull locking ring to remove
3. Lift sprayer unit o of
4. Fill tank with water-based
chemical that is approved
A fully charged battery will
spray up to 4 hours before
• All users should follow safe cleaning practices to protect
themselves from harmful exposure when cleaning
• Review chemical MSDS sheet for how to secure and store
your chemical solution when not in use
• with waterRemove all chemical from tank and ush
• Spray water through each nozzle size for at least
If nozzle becomes plugged, soak in hot soapy water and blow
pressurized air through to remove blockage
counterclockwise to insert nozzle
Turn clockwise until you hear a
Select particle size for your
chemical’s dwell time* & application:
*Average dwell times may vary based on
humidity, temperature, spray speed
Electrostatic Discharge (ESD)
In environments less conducive to natural
electrostatic charge dissipation, ESD events
may occur, resulting in a mild static shocking
sensation for the operator. To avoid this,
operators should maintain a rm grip on
the handle grounding strip & frequently
touch objects that are not being sprayed to
dissipate the negative charge that builds up
Utilize nozzle extension for better control
and reduce amount of back-spray on the
Maintain proper grip of handle to ensure
contact to grounding strip on trigger
To reduce any static build up in the user,
the user’s free hand should be used to
touch grounded surfaces that have not
been sprayed (e.g. metal components of
