Side 1/5

Pressurized Drying System PDS-21

Caution! Read These Instructions Before Operation and Save

SPECIFICATIONS

5.7 Inch/145 mm, 2-Stage Tangential By-Pass

120 VAC

106 inches of Vacuum

Over 2600 LPM

1200 Watts

9.3 amps

Double ball bearing construction

UL Recognized, Category PRGY8

Thermal protection in case of overheating due to blocked intake.

PVC (Vinyl) Tubing 3/8 inch ID X ½ inch OD

Hose Barb Adapter 3/8 inch X ¼ MIP

Available at most “Big Box” Hardware Stores

Cautionary Note:

Atmospheric dust and carbon particles from the motor

brushes may emerge through the hoses, leaving a black

residue. Please be advised to plug active unused hoses to

the plug-off system, minimizing leftover residue, which may

discolor light colored carpet.

GENERAL SAFETY WARNINGS

Never restrict airflow to the inlet. This

Will cause it to overheat and possibly

catch fire.

Ensure that children do not have

access to the equipment. Keep

small children and animals away

from the intake vent. Strong

suction may cause severe injury.

Do not block air output with anything

other than the supplied plug-off system

Do not introduce liquid or flammable materials

into the intake

When using any electrical equipment, basic

precautions should always be followed.

Never operate electrical equipment in

standing water.

• Never service or clean this unit while it is

plugged in.

• Never sit or stand on the unit or use as a

shelf.

• Never intend for outdoor use

• Do not disconnect the unit by pulling on the

cord. Grasp the plug firmly and pull it out of the

wall socket or power receptacle.

• Do not operate the unit with a cut or frayed

power cord.

• To reduce the risk of fire and electric shock, do

not use the air mover with any solid-state

speed control device.

• Always use a grounded outlet.

• Do not use when you are tired, distracted or

under the influence of drugs, alcohol or

medication.

* Do not handle plug with wet hands.

• Do not leave device plugged when not in use

• Store this equipment indoors; do not expose

to harsh weather.

• Never intend for outdoor use.

• Use only Manufacturer’s recommended

attachments.

• Do not pull or carry by the cord, use the cord

as a handle, close doors on the cord, or pull

the cord around sharp edges.

• Do not run over cord.

• Always keep cord and housing away from

heated.

• Always turn the unit off before unplugging.

• Use only as described in this manual.

• Do not place mouth or other body parts Over

the intake holes.

Motor Specification Other Specification

Owners Manual

VIKING Equipment Co., Toll Free: 1-800-252-5201 www.vikingairmovers.com

OPERATING INSTRUCTIONS

1. Check the PDS-21 for any obstructions of the Intake holes

before plugging in the unit or operation of the unit.

2. Set the machine to desired position for operation.

3. Cut tubing to the desired length and attach to the barb fittings.

4. Drill a ½ inch hole in the base of the wall to be dried, and

insert tubing.

5. Plug the power cord into a GFCI outlet.

Do not use an extension cord in conjunction with the Standard

Power Cord

WARRANTOR:

VIKING EQUIPMENT COMPANY

240 CLARY AVE

SAN GABRIEL, CA 91776

TOLL FREE: (800) 252-5201

WARRANTY AND LIMITATION OF LIABILITY

Viking Equipment Co., Inc. (the "Company") warrants to the first

end-user purchaser that the equipment and parts thereof, when

shipped, will be free from defects in materials and the Company’s

workmanship. If any such defects exist or later appear, the Company

shall provide prompt remedial action, as stated herein, to correct

defect. The Company shall have no obligation or liability under this

Warranty unless the customer has obtained a Return Material

Authorization (RMA). To get an RMA you must present proof of

purchase, by the use of the original sales receipt, Internet Product

Registration, or other reasonable and reliable means. To obtain an

RMA, call Viking Equipment Company at (800) 252-5201 and ask for

the Customer Service Department, which will then issue an RMA

number and will arrange for repair or replacement, at our option,

according to the following schedule:

This warranty covers Viking Pressurized Drying Systems (PDS-21).

Year One-100% labor and parts (all components other than those

noted below).

Year Two-Labor only

Year Three through Five-Only materials and workmanship of the

housing are covered.

Motor Brushes, PVC Hoses, Brass Barb fittings,

gaskets and other wear items are not warranted.

Warranty service shall only be performed by a service

provider authorized by the company.

Freight to Company is the responsibility of the end-

user. The end-user is responsible for normal care and

proper return packaging.

Equipment or Parts there of manufactured by other are

warranted hereunder only to the extent of such

manufacturer's warranty to the Company.

Since after purchase, the Equipment and Parts thereof are under

the sole control of the Purchaser, this warranty is subject to, and

shall be applicable only if, the following conditions are met:

a. The Company's instructions as to usage, operation and

maintenance have been followed;

b. The Equipment and Parts thereof, have been used under

normal indoor operation conditions.

c. The Equipment and Parts thereof have been correctly

operated and maintained and have not been damaged by

misuse, neglect, or accident.

d. The purchaser p2-ha not attempted or performed corrective

work or change on the Equipment and/or parts thereof.

e. The Company should received notice (RMA Requested) of

any defect no later than thirty (30)days after the Purchaser

first had knowledge of the same.

This warranty is in lieu of any and all other warranties,

express, implied or statutory including, without limitation,

warranties of merchantability and fitness for a particular

purpose or use.

LIMITATION OF LIABILITY

THE COMPANY SHALL HAVE NO LIABILITY WHATSOEVER IN

ANY EVENT FOR PAYMENT OF ANY INCIDENTAL OR

CONSEQUINTAIL DAMAGES, INCLUDING, WITHOUT

LIMITATION, WATER DAMAGE (THE END-USER SHOULD

TAKE PRECAUTIONS AGAINST SAME), LOST PROFITS,

DELAY, OR LOSS OF USE, OR DAMAGES FOR INQUIRY TO

ANY PERSON OR PROPERTY. BY ACCEPTING THE

EQUIPMENT AND/OR PARTS THEREOF, THE FIRST

END-USER PRUCHSER OR SUBSEQUENT USWR AGREES

THAT THE COMPANY SHALL NOT BE LIABLE FOR

INDEMNIFICATION OR CONTRIBUTION (IN WHOLE OR IN

PART) EITHER EXPRESSLY OR BY IMPLICATION. IF OR ANY

REASON ANY OF THE FOREGOING PROVSIONS SHALL BE

INEFFECTIVE, THE COMPANY'S LIABILITY FOR DAMAGES

ARISING OUT OF ITS MANUFACTURE OR SALE OF ITS

EQUIPMENT OR PARTS, OR USE THEREOF, WHETHER

SUCH LIABILITY IS BASED ON WARRANTY, CONTRACT,

NEGLIGENCE, STRICT LIABILITY IN TORT OR OTHERWISE

SHALL NOT IN ANY EVENT EXCEED THE FULL PURCHASE

PRICE OF SUCH EQUIPMENT AND PARTS THEREOF.

Any action against the Company based upon any liability or

obligation arising from or under any law applicable to the sale of its

Equipment or Parts, or the use there of, must be commenced within

six months after the cause of such action arises.

SYMPTOM PROBLEM SOLUTION

Unit will not turn on

Not plugged in

Switch is worn

Tripped circuit

breaker

Short in power cord

Plug machine in proper

outlet

Replace Switch

Reset Breaker

Replace power cord or

replace cord end

PDS-21 is making

strange noises

Motor bearing is

worn

Replace motor

Motor runs but no

airflow detected

Intake vent is

obstructed

Turn off PDS-21. Remove

obstruction. Restart motor

Intake vent is

obstructed

Remove obstruction. Allow

motor to cool. Motor will

start automatically.

Motor brushed worn

Motor brushes are normal

to cool. Motor will start

automatically.

TROUBLESHOOTING

Motor stops running

VIKING Equipment Co., Toll Free: 1-800-252-5201 www.vikingairmovers.com

a division of
