Item No. 2350097-1 en Rev 08/11









Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating

and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this

packaging to ship the equipment if repairs are needed.

     

36352 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Industry Well

36353 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Industry Well

36354 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Industry Well

36355 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Industry Well

36356 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Vollrath Well

36357 Drop-In, Bottom Mount Thermostatic Control 120V 8.3 Vollrath Well

36358 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Vollrath Well

36359 Drop-In, Bottom Mount Thermostatic Control 208-240V 3.6-4.2 Vollrath Well

Fabricator components

OperatOr’s Manual

Unpacking the eqUipment and initial SetUp

When no longer needed, dispose of all packaging and materials in an

environmentally responsible manner.

1. Remove all packing material and tape, as well as any protective plastic

from the equipment.

2. Clean any glue residue left over from the plastic or tape.

The equipment must be installed only by qualied service personnel. The

equipment must be installed by following local codes and ordinances.

The clearance to the sides is 0” (0 mm).

The minimum distance between wells is 1-1/2” (38 mm).

 

All 19-7/8” x 11-7/8”







3. Hold unit in place and drill holes through the holes in the well through the

mounting surface.

4. Place the bead of silicone sealer rated at a minimum of 450 °F (232 °C)

between the countertop and the inside of the well to prevent water from

leaking into control areas. Place the bead of silicone sealer rated at a

minimum of 450 °F (232 °C) in mounting holes when using rivets or

other fasteners.

FeatUreS and controlS



 dial. Used to set or adjust the

temperature of the well. The higher the number the higher the

temperature, the lower the number the lower the temperature. On

models with no On/Off switch, the “0” position is off.

 light. Illuminates when the well is in the heating mode.

. Switches the equipment power ON

or OFF.

. Used to empty water from the well.

SaFety precaUtionS

To ensure safe operation, read the following statements and

understand their meaning. Please read carefully.

WarnInG

Warning is used to indicate the presence of a hazard that can cause

severe personal injury, death, or substantial property damage if the

warning is ignored.

cautIon

Caution is used to indicate the presence of a hazard that will or can

cause minor personal injury or property damage if the caution is

ignored.



Note is used to notify people of installation, operation, or

maintenance information that is important but not hazard-related.



These precautions should be followed at all times. Failure to follow

these precautions could result in injury to yourself and others.

To reduce risk of injury or damage to the equipment:

 Use only grounded electrical outlets matching the nameplate rated

voltage.

 Have the equipment installed by qualied personnel.

 Do not use an extension cord with this equipment. Do not plug this

equipment into a power strip or multi-outlet power cord.

 Do not operate without water.

 Do not spray controls or outside of equipment with liquids or cleaning

agents.

 Do not clean the equipment with steel wool.

 Keep equipment and power cord away from open ames, electric

burners or excessive heat.

 Do not operate unattended.

 Do not operate equipment in public areas and/or around children.

 Do not operate if equipment has been damaged or is malfunctioning in

any way.

FUnction and pUrpoSe

This unit is intended to hold containers of hot food at the proper serving

temperature. This unit is not designed or intended to cook raw food or reheat

prepared food.

Before using this equipment it must be cleaned and dried thoroughly.

This equipment is not intended for household, industrial or laboratory use.
