Item No. 17678-1 en Rev 05/11

ENGLISH

Operator’s Manual

DROP-IN FROST TOP

Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating

and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this

packaging to ship the equipment if repairs are needed.

Item Description HP Voltage Amps Plug

36419 Two-pan 1/4 hp 120V 4.9 5-15P

36420 Three-pan 1/3 hp 120V 5.9 5-15P

36424 Four-pan 1/3 hp 120V 5.9 5-15P

36426 Five-pan 1/2 hp 120V 12.9 5-20P

36428 Six-pan 1/2 hp 120V 12.9 5-20P

Fabricator components

OperatOr’s Manual

Unpacking the eqUipment and initial SetUp

When no longer needed, dispose of all packaging and materials in an

environmentally responsible manner.

1. Remove all packing material and tape, as well as any protective plastic

from the equipment.

2. Clean any glue residue left over from the plastic or tape.

NOTE

The refrigerated models must be provided with adequate

ventilation. The minimum requirement is the equivalent of 80 square

inches (516 cm

) of air intake and air exhaust.

Have the unit installed only by qualied service personnel. The cutout

opening in counter must be in accordance with the chart below. All openings

must be within 1/8” of the stated dimension and have a 7/8” radius at the

corners. Use the watertight gasket provided to seal between counter and unit

to prevent water from leaking into control areas.

NOTE

All cutout openings must be within 1/8” of listed opening sizes and

have a corner radius of 7/8”. Cutout dimensions given in inches and

(cm).

3. Refer to the Cutout Dimension Chart in this Manual for cutout

dimensions.

4. Place the watertight gasket over the cut-out and center the well.

5. Set the equipment into place.

FeatUreS and controlS

Figure 1. Features and Controls.

DRAIN VALVE. Used to empty water from the well(s).

ON/OFF SWITCH (some models). Switches the equipment power ON

or OFF.

ELECTRICAL PLUG. Grounded electrical plug connects to the

grounded power source.

SaFety precaUtionS

To ensure safe operation, read the following statements and

understand their meaning. Please read carefully.

WARNING

Warning is used to indicate the presence of a hazard that can cause

severe personal injury, death, or substantial property damage if the

warning is ignored.

CAUTION

Caution is used to indicate the presence of a hazard that will or can

cause minor personal injury or property damage if the caution is

ignored.

NOTE

Note is used to notify people of installation, operation, or maintenance

information that is important but not hazard-related.

For Your Safety!

These precautions should be followed at all times. Failure to follow

these precautions could result in injury to yourself and others.

To reduce risk of injury or damage to the equipment:

 Use only grounded electrical outlets matching the nameplate rated

voltage.

 Have the equipment installed by qualied personnel.

 When enclosed, unit must have required ventilation.

 Do not use an extension cord with this equipment. Do not plug this

equipment into a power strip or multi-outlet power cord.

 Unit should only be used in a at, level position.

 Do not spray controls or outside of equipment with liquids or cleaning

agents.

 Do not clean the equipment with steel wool.

 Keep equipment and power cord away from open ames, electric burners

or excessive heat.

 Do not operate unattended.

 Do not operate equipment in public areas and/or around children.

 Do not operate if equipment has been damaged or is malfunctioning in

any way.

FUnction and pUrpoSe

This unit is intended to hold containers of pre-chilled cold food product at the

proper serving temperature for service. This unit is not designed or intended to

cool hot food or cool any item not properly chilled before being placed on the

unit. Refrigerated cold pans are best used for holding periods up to four hours.

For best performance, stainless steel containers are recommended.

Before using this equipment it must be cleaned and dried thoroughly. This

equipment is not intended for household, industrial or laboratory use.
