Side 1/13

O' M

Part No. 354861

4/29/2024

C C O

Thank you for purchasing this Vollrath® product! Save this manual for

reference and the packaging in case shipping is necessary.

SAFETY PRECAUTIONS

To help ensure safe use, please read and fully understand this

manual and all safety messages before operation!

WARNING

Warning indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

CAUTION

Caution indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

NOTICE:  addresses practices not related to physical injury.

To reduce risk of injury or damage to the unit

• Only plug this unit directly into a grounded electrical outlet that

matches the nameplate-rated voltage. Do not use extension cords

or power strips of any kind.

• Use in a ﬂat, level position.

• Turn o, unplug, and let the unit cool before cleaning or moving

and when not in use.

• Outside of unit should not be sprayed with liquid or foam.

• Clean unit with something other than steel wool.

• Keep unit and power cord away from open ﬂames, electric

burners, and excessive heat.

• Operate in non-public areas, away from children—and attend the

unit during use.

• Only operate a unit that is functioning properly and is not

damaged.

• Clean the unit daily.

• Do not set anything on top of the unit or door; never stack units.

• The unit may be hot, even though the indicator light is o.

Item Model Description #

Shelves

CO4-208240HS COV-208240-HS CONV OVEN - HALF-SIZE 208-240V 4

CO4-208240FS COV-208240-FS CONV OVEN - FULL SIZE 208-240V 4

CO4-120HS COV-120-HS CONV OVEN - HALF SIZE 120V 3

FUNCTION & PURPOSE

This unit is intended to cook fresh or frozen foods in commercial

foodservice operations. It is not intended for household, industrial,

or laboratory use.

UNPACKING THE UNIT

1. Remove all packing material and tape, as well as any

protective plastic.

2. Clean any glue residue left over from the plastic or tape.

3. Place the unit in desired location.

4. Plug unit into a properly grounded electrical supply matching

the nameplate rating.

NOTICE:  Using incorrect voltage can cause damage and will

void the warranty.

CO4-120HS

CO4-208240HS

CO4-208240FS

Countertop Convection Ovens

CO4-208240HS CO4-120HS

CO4-208240FS

A. Bake Light—turns on and off as the oven and rear heating elements cycle around the set temperature.

B. Bake Control—sets and adjusts baking temperature between 100 °F–550 °F (37.78 °C–260 °C); ●● is off. Rear heating elements and

convection fans are operational when the Bake Timer is set.

C. Broil Light—indicates when the Top Heating Element is broiling; the light turns on and off as the oven temperature changes.

D. Broil Control—sets and adjusts broiling temperature between 100 °F–550 °F (37.78 °C–260 °C) when Bake Control (B) is set to Broil.

Top heating elements will turn on. Convection Fans, rear elements, and Bake Timer do not function in Broil Mode.

E. Bake Timer Light—indicates when the Bake Timer and Bake Control are set.

F. Bake Timer—determines time in Bake mode from 15–120 minutes or can be set to continuously ON.

G. Steam Button—sprays a small amount of water into the baking chamber when pushed.

LOCATION & INSTALLATION

WARNING

Fire Hazard, Injury, or Property Damage.

Unit must be installed by qualiﬁed personnel in accordance with all federal, state, and local codes. Improper installation can

result in injury or death. Unit must be used with the included legs to avoid overheating and ﬁre.

• This unit should be installed adjacent to non-combustible surfaces in a ﬂat location.

• Ensure the unit is level to avoid damage during operation.

• Ambient temperatures must be at or below 104 °F (40 °C).

• Item CO4-208240FS is equipped with a water-spray feature and must be connected to a potable water supply with 3–30 PSI—at the

¾" (1.9 cm) male inlet on the back of the oven.

• Install included 4" legs to meet agency requirements (CO4-208240FS only).

• To avoid damage, plug the unit into a properly grounded electrical supply that matches the nameplate rating.

Ventless Operation

Based on independent UL testing, this product complies with NFPA96 for ventless operation using the EPA202 test method.

Ventless allowance is dependent upon AHJ approval.

BEFORE FIRST USE

1. Clean the unit per the Cleaning and Maintenance Section.

2. Set temperature to 550 °F in Bake mode.

3. Set timer for 30 minutes to burn in; smoke and odors are normal. After 30 minutes, the unit is ready to use.

OPERATION

WARNING

Burn Hazard.

To avoid burns and splattering, do not touch cookware, heating surfaces, or food—or drop water onto cooking

surfaces while operating.

Bake Mode (All Models)

1. Place wire shelves or pans inside the unit, allowing at least 2" (5 cm) between, ensuring food will not contact the top element.

2. Set Bake Control to the desired temperature.

FEATURES & CONTROLS

NOTICE: CO4-208240FS fans are self-reversing and stop briefly during the baking cycle when changing directions.
