Side 1/4

Operator’s Manual

Conveyor Bagel and Bun Toasters

Model JT2B

2017 The Vollrath Company L.L.C. Part No. 350803-1 en 8/23/17

Thank you for purchasing this Vollrath equipment. Before operating the

equipment, read and familiarize yourself with the following operating

and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. Save the original box and packaging. Use this packaging

to ship the equipment if repairs are needed.

SAFETY PRECAUTIONS

To ensure safe operation, read the following statements and understand

their meaning. This manual contains safety precautions which are

explained below. Please read carefully.

Warning is used to indicate the presence of a hazard that will or can

cause severe personal injury or death.

Caution is used to indicate the presence of a hazard that will or can

cause minor or major personal injury if the caution is ignored.

NOTICE: Notice is used to note information that is important but not

hazard-related.

To reduce risk of injury or damage to the equipment

• Plug only into grounded electrical outlets matching the voltage on

the rating plate.

• Use this equipment in a flat, level position.

• Unplug equipment and let it cool before cleaning or moving.

Equipment remains hot after it is turned off.

• Do not touch during operation. Unplug when not in use.

• Keep equipment and power cord away from open flames, electric

burners or excessive heat.

• Do not operate unattended.

• Closely supervise equipment operating in public areas and/or

around children.

• Do not operate if equipment has been damaged or is malfunctioning

in any way.

FUNCTION AND PURPOSE

This equipment is intended to toast bread products. It is intended for

use in commercial foodservice operations only. It is not intended for

household, industrial or laboratory use.

CLEARANCE AND ENVIRONMENT REQUIREMENTS

Do not place toaster on surfaces or near walls, partitions or kitchen

furniture unless they are made of non-combustible material or clad with

non-combustible heat-insulating material. Toasters must not be used

near or below curtains and other combustible materials.

Do not place the toaster adjacent to a heat producing appliance.

SET UP

1. Place the toaster on a hard, flat, stable surface.

2. Turn the toaster on it’s side with the bottom facing you.

3. Install the feet.

NOTICE: Feet must be installed. Failure to install the feet will

restrict airflow and cause the toaster to overheat.

4. Install the collection pan by placing the back edge of the pan on the

lip at the back of the toaster. Line up the hole in the pan with the

screw. Tighten the screw to secure the collection pan.

WARNING

CAUTION

Item No. Model Description

CT4B-2081200

JT2B

Bagel/bun toaster, 208V, 1200 slices per hour

CT4B-2401200 Bagel/bun toaster, 240V, 1200 slices per hour

2 Conveyor Bagel and Bun Toasters Operator’s Manual – Model JT2B

FEATURES BEFORE FIRST USE

1. Clean the toaster. See “Cleaning” on page 3.

2. Insert the crumb tray. Make sure the feed ramp is placed in the up

position.

OPERATION

NOTICE: The crumb tray must be installed in the toaster during

operation. Failure to install the crumb tray will cause the

toaster to overheat.

Tips

Preheat

1. Plug the toaster into a grounded electrical outlet that matches the

rating on the name plate found on the side of the toaster.

NOTICE: Using a voltage other than the nameplate rated voltage

will cause damage to the unit. Incorrect voltage,

modification to the power cord or electrical components

can damage unit and will void the warranty.

2. Toasters with an adjustable heat shield: Adjust the heat shield so the

tallest bread product can pass below it. Excess space above the

product will create heat loss and may reduce performance.

3. Rotate the power knob to the full power position (I).

4. Set the conveyor speed control knob to 7.

5. Wait 5 minutes for the toaster to preheat.

Test

1. Adjust the settings for the product to be toasted. See the Tips chart

at the top of this page.

2. Test the settings by placing a sample of the bagel or bun to be

toasted onto the feed ramp. Place the bagel or bun with the cut side

facing up.

3. Evaluate the results.

Toast Bagels or Buns

1. Adjust the conveyor speed as needed to achieve desired browning.

• Toast too light: Rotate the speed control knob to a lower number

to reduce the speed and darken the toast.

• Toast too dark: Rotate the speed control knob to a higher number

to increase the speed control and lighten the toast.

2. For best performance do not overload the toaster. Wait a few

seconds before loading a second row of bagels or buns into the

toaster.

If a Bagel or Bun Becomes Stuck

1. Rotate the power knob to the OFF position (O) and unplug the

toaster.

2. Let the toaster cool completely.

3. Use tongs to remove the bagel or bun. Take care to not bump the

glass heating elements above and below the conveyor.

A Conveyor Speed Control Knob

B Power Knob

Full Power - maximum heat

Off

Standby - reduces electrical consumption by 75%.

C Heat Shield - Adjustable on the high-clearance toasters

D Feed Ramp

E Crumb Tray

F Collection Pan

G Reset Button - Reference only. Access is via the front of the

toasters. See page 4.

Back View

Front View

CAUTION

Burn Hazard

Do not touch the equipment while it is heating or operating.

Hot surfaces can burn skin.

Bread Product Suggestions

Bagels, wheat or rye bread or

products with high moisture content.

Use a slower conveyor speed.

Buttered or coated, such as pastries Not recommended.

Frozen Must be thawed before toasting.
