Operator’s Manual
Conveyor Bagel and Bun Toasters, 1400 Slices Per Hour
Model JT3BH
©
2017 The Vollrath Company L.L.C. Part No. 350814-1 en 12/27/17
Register your product at Vollrath.com/registration and become eligible to win a free 10" Vollrath Tribute® fry pan.
Thank you for purchasing this Vollrath equipment. Before operating the
equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE
to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can
cause severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment
• Plug only into grounded electrical outlets matching the voltage on
the rating plate.
• Use this equipment in a flat, level position.
• Unplug equipment and let it cool before cleaning or moving.
Equipment remains hot after it is turned off.
• Unplug when not in use.
• Keep equipment and power cord away from open flames, electric
burners or excessive heat.
• Do not operate unattended.
• Closely supervise equipment operating in public areas and/or
around children.
• Do not operate if equipment has been damaged or is malfunctioning
in any way.
FUNCTION AND PURPOSE
This equipment is intended to toast bread products. It is intended for
use in commercial foodservice operations only. It is not intended for
household, industrial or laboratory use.
CLEARANCE AND ENVIRONMENT REQUIREMENTS
Do not place toaster on surfaces or near walls, partitions or kitchen
furniture unless they are made of non-combustible material or clad with
non-combustible heat-insulating material. Toasters must not be used
near or below curtains and other combustible materials.
Do not place the toaster adjacent to a heat producing appliance.
SET UP
1. Place the toaster on a hard, flat, stable surface.
2. Turn the toaster on it’s side with the bottom facing you.
3. Install the feet.
NOTICE: Feet must be installed. Failure to install the feet will
restrict airflow and cause the toaster to overheat.
4. Install the collection pan by placing the back edge of the pan on the
lip at the back of the toaster. Line up the hole in the pan with the
screw. Tighten the screw to secure the collection pan.
WARNING
CAUTION
Item No. Model Description
CT4BH-2081400
JT3BH
Bagel/bun toaster, 208V, 1400 slices per hour
CT4BH-2201400 Bagel/bun toaster, 220V, 1400 slices per hour
CT4BH-2401400 Bagel/bun toaster, 240V, 1400 slices per hour
2 Conveyor Bagel and Bun Toasters, 1400 Slices Per Hour Operator’s Manual – Model JT3BH
FEATURES
BEFORE FIRST USE
1. Clean the toaster. See “Cleaning” on page 3.
2. Insert the crumb tray. Make sure the feed ramp is placed in the up
position.
OPERATION
NOTICE: The crumb tray must be installed in the toaster during
operation. Failure to install the crumb tray will cause the
toaster to overheat.
Tips
Preheat
1. Plug the toaster into a grounded electrical outlet that matches the
rating on the name plate found on the side of the toaster.
NOTICE: Using a voltage other than the nameplate rated voltage
will cause damage to the unit. Incorrect voltage,
modification to the power cord or electrical components
can damage unit and will void the warranty.
2. Adjust the heat shield so the tallest bread product can pass below it.
Excess space above the product will create heat loss and may
reduce performance.
3. Set the toggle switch to Top-Bottom.
4. Rotate the power knob to the full power position (I).
5. Set the conveyor speed control knob to 7.
6. Set the Top and Bottom heat control to high.
7. Wait 5 minutes for the toaster to preheat.
Test
1. Adjust the settings for the product to be toasted. See the Tips chart
at the top of this page.
2. Test the settings by placing a sample of the product to be toasted
onto the feed ramp. Place bagels or buns with the cut side facing up.
3. Evaluate the results.
Toast
1. Adjust the heat control settings, toggle switch and conveyor speed
as needed for desired results. Allow time for the toaster to adjust to
new heat settings before placing bread on the conveyor.
2. For best performance do not overload the toaster. Wait a few
seconds before loading a second row of bagels or buns into the
toaster.
If a Bread Item Becomes Stuck
1. Rotate the power knob to the OFF position (O) and unplug the
toaster.
2. Let the toaster cool completely.
3. Use tongs to remove the bagel or bun. Take care to not bump the
glass heating elements above and below the conveyor.
A Conveyor Speed Control Knob
B Power Knob
Full Power - maximum heat
Off
Standby - reduces electrical consumption by 75%.
C Heat Shield
D Feed Ramp
E Crumb Tray
F Top Heat Control Knob
G Toggle Switch - Switches between heat modes
Top - Toasts the top side, warms the bottom side
Top-Bottom - Toasts both sides
H Bottom Heat Control Knob
I Collection Pan
J Reset Button (Reference only. Access is via the front of the
toasters. See page 3.)
J
Back View
Front View
C
D
I
A
B
H
E
F
G
CAUTION
Burn Hazard
Do not touch the equipment while it is heating or operating.
Hot surfaces can burn skin.
Bread Product Suggestions
Bagels, wheat or rye bread or
products with high moisture content.
Use a slower conveyor speed.
Buttered or coated, such as pastries Not recommended.
Frozen Must be thawed before toasting.
