Side 1/4

Operator’s Manual

35 Inch Cheese Melters

Model JW30

2017 The Vollrath Company L.L.C. Part No. 351019-1 en 12/5/17

Thank you for purchasing this Vollrath equipment. Before operating the

equipment, read and familiarize yourself with the following operating

and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE

REFERENCE. Save the original box and packaging. Use this packaging

to ship the equipment if repairs are needed.

SAFETY PRECAUTIONS

To ensure safe operation, read the following statements and understand

their meaning. This manual contains safety precautions which are

explained below. Please read carefully.

Warning is used to indicate the presence of a hazard that will or can

cause severe personal injury or death.

Caution is used to indicate the presence of a hazard that will or can

cause minor or major personal injury if the caution is ignored.

NOTICE: Notice is used to note information that is important but not

hazard-related.

To reduce risk of injury or damage to the equipment

• Plug only into grounded electrical outlets matching the voltage on

the rating plate.

• Use this equipment in a flat, level position.

• Unplug equipment and let it cool before cleaning or moving.

Equipment remains hot after it is turned off.

• Unplug when not in use.

• Keep equipment and power cord away from open flames, electric

burners or excessive heat.

• Do not operate unattended.

• Closely supervise equipment operating in public areas and/or

around children.

• Do not operate if equipment has been damaged or is malfunctioning.

FUNCTION AND PURPOSE

This equipment is intended to melt cheese, finish cooked food such as

nachos, cheese fries, potato skins and garlic bread in higher-volume

food service operations and large restaurants. It is not intended to bake

food or cook raw food. It is intended for use in commercial foodservice

operations only. It is not intended for household, industrial or

laboratory use.

CLEARANCE AND ENVIRONMENT REQUIREMENTS

Do not place oven on surfaces or near walls, partitions or kitchen

furniture unless they are made of non-combustible material or clad with

non-combustible heat-insulating material. Ovens must not be used near

or below curtains and other combustible materials.

Do not place the oven adjacent to a heat producing appliance.

Allow a minimum of 8 inches (20.3 cm) of clearance on the left and

right sides of the oven.

WARNING

CAUTION

Item No. Model Description

CM4-20835

JW30

Cheese Melter, 35" wide, 208V

CM4-24035 Cheese Melter, 35" wide, 240V

2 35 Inch Cheese Melters Operator’s Manual – Model JW30

SET UP

Install the legs

NOTICE: Legs must be installed. Failure to install the legs will

restrict airflow and cause the oven to overheat.

Screw the legs onto the threaded nuts below the cheese melter.

Install the Shelf

Insert the pins on the shelf into the slots on the brackets on the sides of

the oven.

FEATURES

BEFORE FIRST USE

Clean the oven. See “Cleaning” on page 3.

OPERATION

Preheat

1. Plug the oven into a grounded electrical outlet that matches the

rating on the name plate found on the oven.

NOTICE: Using a voltage other than the nameplate rated voltage

will cause damage to the unit. Incorrect voltage,

modification to the power cord or electrical components

can damage unit and will void the warranty.

2. Adjust the shelf to the desired position.

3. Press the On/Off switch to the ON position. The front and rear heater

elements will turn on and the oven will be in standby mode.

4. Set the timer for 10 minutes. The center elements turn on and the

oven is full power.

Melt Cheese, Finish Cooked Food

1. Place the food on or in an oven-proof pan and place the pan on the

shelf.

2. Set the timer to the appropriate length of time to melt cheese, brown

or finish cooked food items.

3. When the time on the timer has expired, the oven will enter a

standby mode.

4. When finished using the oven, press the On/Off switch to the OFF

position.

Bypass the Standby Mode (Optional)

By default, the oven is in standby mode until the timer is set. This

feature can be bypassed to allow all four elements to activate when

power is switch ON.

To bypass the feature, move the toggle switch on the back of the oven

to the up position.

The timer can still be used. But the oven will not enter standby mode

when the time is expired. When time is expired, press the On/Off switch

to the OFF position.

A Fan

B Adjustable Shelf

C Timer

D On/Off Switch

E Reset Button

F Standby Mode Bypass Switch

Front View

Back View

CAUTION

Burn Hazard

Do not touch the equipment while it is heating or operating.

Hot surfaces can burn skin.
