Operator’s Manual
Refrigerated Beverage Dispensers
©
2020 The Vollrath Company L.L.C. Part No. 352405-1 ml 9/21/20
Thank you for purchasing this Vollrath equipment. Before operating the
equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. Save the original box and packaging. Use this packaging
to ship the equipment if repairs are needed.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
explained below. Please read carefully.
Warning is used to indicate the presence of a hazard that will or can cause
severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can cause
minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment
• Plug only into grounded single-phase electrical outlets that match the
volta
ge on the rating la
bel.
•
Do not use extension cords to connect the machine.
• Use this equipment in a flat, level position.
• Unplug machine before cleaning, performing maintenance or moving.
• Keep machine and power cord away from open flames, electri
c
bur
ners or excessive heat.
• Do not operate the machine unless all panels are secured with screws.
• Do not put objects or fingers in panels, louvers or spigot.
• Do not operate unattended.
• Closely supervise the machine when operating in public areas and/or
around children.
• Do not operate the machine if it is damaged, malfunctioning or
has
damage
d cord or plug.
• Use the machine with beverages as indicated in the
FUNCTION AND
PURPOSE.
FUNCTION AND PURPOSE
The Vollrath Refrigerated Beverage Dispensers are designed to refrigerate
and serve pre-mixed cold beverages in commercial food service
operations.
• Agitator and stirring paddle bowl circulation is suitable for most
beverages and is recommended for beverages that can foam such as
coffee, tea and natural fruit juices.
• Fountain spray bowl circulation is suitable for many beverages but is
not recommended for beverages that can foam such as coffee, t
ea and
nat
ural fruit juices.
• These machines are NOT intended for use with beverages that includ
e
pi
eces of fruit, large pulp or seeds because these could block th
e
spigot
or mixing motor.
• They are not intended for outdoor, household, industrial or laboratory
use.
WARNING
CAUTION
Item No.
Bowl
Circulation
Capacity
Gallon (Liter)
Number of
Bowls
VBBC1-37-A
Agitator
2.11
(8)
One
VBBC2-37-A Two
VBBC3-37-A Three
VBBC4-37-A Four
VBBD1-37-S
Stirring Paddle
3.17
(12)
One
VBBD2-37-S Two
VBBD3-37-S Three
VBBD4-37-S Four
VBBE1-37-S
5.28
(20)
One
VBBE2-37-S Two
VBBE3-37-S Three
VBBE4-37-S Four
VBBD1-37-F
Fountain Spray
3.17
(12)
One
VBBD2-37-F Two
VBBD3-37-F Three
VBBD4-37-F Four
VBBE1-37-F
5.28
(20)
One
VBBE2-37-F Two
VBBE3-37-F Three
VBBE4-37-F Four
2 Refrigerated Beverage Dispensers Operator’s Manual
CLEARANCE AND ENVIRONMENT REQUIREMENTS
• Indoor use only.
• Ambient temperature: 41° - 86°F (5° - 30° C).
• Minimum clearance required: 6" (15.2 cm) on all sides of the machine.
INSTALLATION
NOTICE: Do not lay the machine on its side or back.
NOTICE: Do not lift the machine by the bowl(s). Only lift by grasping
the bottom of the machine.
NOTICE: After unpacking the machine, it must sit in the upright
position for 24 hours before turning it on. This will allow
the oil in the compressor to settle into place.
Attach the Legs (Some Machines)
Some Refrigerated Beverage Dispensers require 4" (100 mm) legs to
meet the NSF standard for cleaning under the machine. If legs are
included with your machine, they must installed.
1. Position the machine on a countertop capable of supporting the
weight when all bowls are filled to capacity.
2. Replace the feet on the machine with installed with the 4" (100 mm)
legs whenever they are provided with the machine.
Attach the Drip Tray
Gently slide the drip tray into position until you hear it click.
BEFORE FIRST USE
Before use, the machine must be disassembled, cleaned and sanitized.
1. Disassemble the machine. See DISASSEMBLE THE MACHINE.
2. Clean the components. See CLEAN THE MACHINE.
3. Re-assemble and lubricate the components. See ASSEMBLE THE MACHINE.
4. Sanitize the machine. See CLEAN THE MACHINE.
