WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. 1 Dec 2017
waclighting.com
Phone (800) 526.2588
Fax (800) 526.2585
Headquarters/Eastern Distribution Center
44 Harbor Park Drive
Port Washington, NY 11050
Central Distribution Center
1600 Distribution Ct
Western Distribution Center
Ontario, CA 91760
INSTALLATION INSTRUCTION
SQUARE
FM-07 , FM-11SQ SQ
WARNING
IMPORTANT: NEVER attempt any work without shutting o the electricity.
- Read all instructions before installing.
- System is intended for installation by a qualied electrician in accordance with the National Electrical Code and local regulations.
- Go to the main fuse box, or circuit breaker. Place the main power switch in the “OFF” position and unscrew the fuse(s) or
switch ”OFF” the circuit breaker switch(es) that control the power to the xture or room that you are working on.
- Place the wall switch in the “OFF” position.
- Supply conductors (Power Wires) Connecting the xture must be rated minimum 90°C. If uncertain, consult an electrician.
CAUTIONS
- These luminaires (xtures) are designed to meet the latest NEC requirements and are listed in full compliance with UL 1598.
- Before attempting installation, check your local electrical code, as it sets the wiring standards for your locality.
Fig. 1
Fig. 2 (back of the fixture once clipped into the mounting plate)
1.
Install plate the the mounting provided to junction box using
the junction box screw provided s.
Note: Carefully align the slots on the mounting plate with the
direction you want your fixture to be in to prevent uneven
installation.
2. Provide electrical service according to the “National Electrical
Code” or your local electrical code to the outlet box.
4. Connect supply wires to fixture wires and insulate with
proper wire nuts:
Connect incoming ground wire to ground wire mounting plate
(green or bare).
Connect incoming common wire to xture common (white).
Connect incoming hot wire to xture black wire.
5.
Raise the fixture to the junction box, guide the spring clips into
the slots in the mounting plate and press the front of the
fixture firmly at the clip locations to lock the fixture in place.
Note: To ensure an easier installation, press one side of the
fixture in first until you hear a click, then repeat with the other
side.
Wire Connector
Qty: 3 pcs
P3
INCLUDED ACCESSORIES BAG
Junction Box Screw
Qty: 2 pcs
#8-32, * 3/4”
Stainless Steel
3", 4" or electrical 3/0-4/0
box, (by others)
Junction Box Mounting Screw
Fixture
INSTALLATION FOR FM-07 AND FM-11SQ SQ
Uses ” junction box or a combination 3 , 4" junction box
3/0-4/0 electrical box.
Wire Connector
Spring Clip
Spring Clip Slot
Mounting Plate
Qty: pc1
3.
Clip the retention cable into the retention cable slot
on the mounting plate to assist with wiring.
Retention Cable Slot
Mounting Plate
