Side 1/4
USER GUIDE
The now legendary Wampler Pantheon provided a unique interpretation of the classic
“Blues Breaker” style stomp box, by capturing all the tonal nuance of the original, but with
added exibility and style. In doing so, it found its way onto thousands of pedalboards
across the world.
Enter the new – a dual overdrive pedal that takes this evolution several Pantheon Deluxe
steps further by offering a exible design with two completely independent Pantheon
circuits, one voiced as a classic blues breaker and one with a more modern boutique
featuring dual Inputs and Outputs, and for the rst time ever, Wampler have added
MIDI channel switching to one of their gain pedals.
The lets you dial in two channels of organic creamy gain, gritty Pantheon Deluxe
overdrive, or heavy distortion while retaining Wampler’s famous ease of use and
exibility. Channel 1 delivers a classic Blues Breaker tone, Channel 2 is a recreation of
the original Pantheon, a similar circuit to the Blues Breaker but with a modern boutique feel.
Independent side mounted Voicing and Gain Level switches allow you to further shape your tone to
perfection.
Combining both channels will unleash a whole new world of crisp, harmonic distortion possibilities. You can easily swap the
stacking order, without changing cabling, via the front-mounted Order switch. Optional independent inputs and outputs
allow you to: split each channel in a loop switcher, insert a pedal or chain of pedals between each side, or run the pedal in
stereo to dual ampliers. With the addition of MIDI In and Out, you can now also switch the analog channels of each circuit
on and off with a MIDI switcher - saving you valuable hardware loops on your loop switcher (if it also operates your midi
controls).
Each Channel of the Dual Overdrive feature independent Gain, Level, Treble, and Bass controls to Pantheon Deluxe
enhance the shaping of your tone. The Baxandall-style active Bass control is neutral at noon but boasts an extremely
powerful sweep as you move through the range. A single global Presence control simultaneously alters each channel to add
just the right amount of top-end chime to suit different guitars and ampliers - perfect for when playing live or when in the
studio.
The native sound of this style of pedal has passed the test of time. We are sure that with the advanced connectivity, and vast
array of stacking options, you are going to love the exibility and sheer grunt of the Dual Overdrive. Pantheon Deluxe
Volume: Controls the total
output volume of each channel.
Gain: Turning this control
clockwise will increase the
amount of gain applied to the
signal path of each channel.
Bass: Adjust the amount of
low-end frequencies, turning
clockwise will increase the
levels, counter clockwise to
decrease.
Treble: Adjust the amount of
high-end frequencies, turning
clockwise will increase the
levels, counter clockwise to
decrease.
Gain Level (Side switches L
and R): Set the switch
• top for maximum gain
• middle for medium gain
• bottom for lower gain
Voicing (Side switches L and
R): Set the switch
• top for hard clipping (crunchy)
• middle for blended clipping
• bottom for soft clipping
(smooth)
MIDI: Connect a 3.5mm TRS
MIDI cable via an adapter (if
connecting from one of our
other midi pedals you can use
3.5mm TRS to 3.5mm TRS) - In
at the bottom Triangle, Out at
the Top. See MIDI Section on
next page for more information.
Connections: This pedal has 2 pairs of input and output jacks: if you are using
only one set connect to the jacks marked with solid triangles; if you are using both
sets, the outline triangles indicate the separate output for Channel 1 and input for
Channel 2. This allows you to connect both channels independently (e.g to a loop
switcher), insert a pedal between the channels, or run in stereo.
Power Draw: 55mA, 9-18V Center Negative DC supply only, do not exceed 18V DC
Channel 1: Classic / vintage
“Blues Breaker” voicing
Channel 2: Original Pantheon
(Modern “Boutique” style)
voicing
Presence: Global presence control to add sparkle and
top end to both channels, start off with this turned all the
way counter-clockwise and adjust to suit. The presence
and treble controls are controlling different frequencies, so
multiple tones can be found by cranking presence up and
treble down, and vice versa.
Order: Change the
channel stacking
order with this
switch if you are
using only one input
and output cable.
NOTE: We recommend disconnecting the internal 9V battery if this pedal is used with a power supply.
If the power supplied is insufcient LEDS may icker when a foot switch is pressed to indicate this.
