Side 1/2
Data sheet
Creation date February 26, 2020 2:42:25 PM CET
Catalogue status 21.02.2020 / We reserve the right to make technical changes. 1
SE HD 160 Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
When working with live voltages, you must follow special
guidelines and use special tools - tools which have been
specially produced and tested for this purpose.
Weidmüller offers a complete line of pliers which comply
with national and international testing standards.
All pliers are produced and tested according to DIN EN
60900.
The pliers are ergonomically designed to fit to the hand
form, and thus feature an improved hand position. The
fingers are not pressed together - this results in less
fatigue during operation.
General ordering data
Type SE HD 160
Order No. 9046320000
Version VDE-insulated heavy-duty diagonal-cutting pliers,
160 mm long
GTIN (EAN) 4032248357628
Qty. 1 pc(s).
Data sheet
SE HD 160 Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26
D-32758 Detmold
Germany
Fon: +49 5231 14-0
Fax: +49 5231 14-292083
www.weidmueller.com
Technical data
Creation date February 26, 2020 2:42:25 PM CET
Catalogue status 21.02.2020 / We reserve the right to make technical changes. 2
Dimensions and weights
Width 160 mm Width (inches) 6.299 inch
Weight 253 g Net weight 222 g
Environmental Product Compliance
REACH SVHC Lead 7439-92-1  
Pliers
Conductor diameter, max. (H) 2.3 mm Conductor diameter, max. (MH) 3 mm
Conductor diameter, max. (P) 1.6 mm Cutter hardness 62 HRC
Protective insulation, 1000 V Yes Shape (diagonal-cutting pliers) Standard
Total length 160 mm  
Classifications
ETIM 6.0 EC000142 ETIM 7.0 EC000142
eClass 9.0 21-04-47-01 eClass 9.1 21-04-37-06
eClass 10.0 21-04-47-01 UNSPSC 23-17-16-04
Approvals
Approvals
Downloads
Approval/Certificate/Document of
Conformity Manufacturer's Declaration - Pliers
Brochure/Catalogue CAT 6 TOOLS 15/16 EN
