Introducon
Dear Customer!
Thank you for purchasing our C5 Carplay & Android Auto device. Please read this User Manual carefully to learn how to operate the
device and ensure opmal performance. We recommend that you keep the User Manual for future reference.
1. Package
The standard package includes the following items:
2. Device layout
1. Power buon Turns the device on/off
2. Touch screen 5" TFT touch screen display
3. TF card slot
4.
Supports TF cards up to 64GB.
5. Charging port
Mini USB port
USB Client 2.0
6. Speaker
For connecng the charger
7. Reset buon
Provides audio output
8.
Reset
Installing a TF card
Insert the TF card as shown on the picture
•
1
2
3
4
5
6
7
8
Screw Hole
Fix cradle
User Manual
| 01
User Manual
9
9.
. Microphone hole
To record voice
User Manual
| 02
Operaon System
Linux OS
Memory
2GB Flash
LCD display
5" LCD display
Resoluon:
800RGB(H)x480(V)
Touch screen
Durable high-precision touch
screen
Mini USB
USB Client 2.0
TF
TF slot
Video -
3GP/ASF/AVI/DivX/mkv/MOV
Wifi
5G
Bluetooth
Two Channels
Charger
5V/2.5 A Input
Temperature
Operang Temperature: -20°C
to 80°C
Storage Temperature: -20°C
to 80°C
Working humidity range 45% to 80%RH
Storage humidity range 30% to 90%RH
Atmospheric pressure 86KPa to 106KPa
3. Specificaons
/MP4/MPG/TS/VOB/WEBM/
M4V/FLV
MP3/MP2/WAV/AAC/AMR
/M4A/OGG/APE/FLAC
Audio
4. Mounng Instrucons (Motorcycle):
4.2 Installaon at the Handlebars:
4.1. Install the device and sunshade:
1). Put the device in the sunshade.
2). Use a thumb to push the top unl
you heard a sound "click".
How to know if the installaon is good.
1) There are several ways to install the bracket
2) Install the device to the cradle, wring the screw behind
the moun o fasten the device.
as following:
4.3.1 via Cigaree lighter
4.3.2 via Motorcycle Baery Power
1) Connect the red line (+) to ignion switch and
2）Connect the black line (-) to the negave pole
When you turn on the motorcycle, the device will turn on automacally.
4.3 Connecon of the device to the power supply of the motorcycle/car.
