Side 1/8

GB -1-

Chart

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

(see at right for options description)

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the program.

When the door is opened during a washing cycle, the

cycle is temporarily paused: the Start indicator blinks.

To resume the cycle push Start button and close

the door within 3 seconds.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute

(0:01 is shown into the display).

If pressed when the dishwasher is switched off,

it drains any possible liquids from dishwasher

(1 minute process).

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional options) and may

vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic

calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/

Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.

RECYCLING WATER SYSTEM: these programs save water in a dedicated tank.

A TANK CLEANING CYCLE (at least 30 min.) is automatically run every 30 cycles or after every power off, to assure the best product conditions.

Table of programs

Deter-

gent

Consumption

Drying

Phase

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Sensor 40-70°C

Delay

Multizone

Recommended program for routine

washes, with dried-on food (e.g. EN

50242).

X 7-14 1.00-1.60 70-155 Full

Pre-Wash cold

Delay

Multizone

Crockery to be washed later. — 4.0 0.03 14 NO

Glasses 40°C

Delay

Multizone

Light soiling, for example glasses and

cups.

X 10.0 0.85 100 Light

Quickwash 45°C

Delay

Multizone

Lightly soiled crockery, with no dried-

on food.

X 11.0 0.80 30 NO

Eco

50°C

Delay

Multizone

Normally soiled crockery.

Energy-saving program.

X 6.0 1.03 185 Full

Overnight 55°C

Delay

Multizone

Normally soiled crockery, gentle and

quiet thanks to the lower spray

pressure (39 dbA).

X 10.0 1.20 290 Light

5019 396 01998

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS

QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

Options and display description

SALT INDICATOR

When lit (at the end of

the cycle), the salt

reservoir needs to be

refilled.

RINSE AID

INDICATOR

When lit (at the end of

the cycle), the rinse aid

dispenser needs to be

refilled.

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates

the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY

BUTTON EXCEPT CANCEL/OFF BUTTON. FOR ENERGY SAVING THE

CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER 30 SECONDS IF

NO CYCLE HAS STARTED.

OPERATION

INDICATOR

A LED light projected

on the floor indicates

that the dishwasher is

working.

TABLET SETTING

This setting allows to optimize the cycle performances

according the type of detergent used.

Push the Tablet button for 3 seconds (until the indicator lights

up) if you are using the combined detergents in tablet (rinse aid,

salt and detergent in 1 dose).

If you are using powder detergent or liquid detergent, the

Tablet indicator on the control panel has to be off.

DELAYED START BUTTON

Push the button (repeatedly)

to delay the start of the

program. Adjustable from 1 to

24 hours. With each press of

the button, the delayed start

indicator increases by one

hour and after 24 restarts from

0. Then press the START

button. The dishwasher will

start after the set time.

MULTIZONE

Allows you to choose the washing

zones. Press this button (repeatedly)

to select the wash zones:

both racks

only lower rack

only upper rack

- indicator lits

Quick reference guide

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADG 6240 FD
Vekselstrømsindgangsspænding:	220 - 230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	597 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	41000 g
Ledningslængde:	1.5 m
Energieffektivitetsklasse (gammel):	A+
Årligt energiforbrug:	293 kWh
Placering af apparat:	Fuldt indbygget
Tilsluttet belastning:	2200 W
Støjniveau:	42 dB
Antal vaskeprogrammer:	6
Forsinket start-timer:	Ja
Vaskeprogrammer:	Forvask
Dør farve:	Ikke anvendelig
Vaskeklasse:	A
Vandforbrug pr. cyklus:	6 L
Farve på kontrolpanel:	Sort
Antal kuverter:	13 kuverter
Cyklustid:	185 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Eco, Pre-wash, Quick
Halv belastning:	Ja
Tørringsklasse:	A
Årligt vandforbrug:	1680 L
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	1.03 kWh
Indikator for resterende tid:	Ja
Vandpåfyldning:	Cold, Hot
Temperatur (maks):	70 °C
Selvrensende filter:	Ja
Tørresystem:	Statisk
Quick wash:	Ja
