Whirlpool ADP 8453 Manual

Whirlpool Opvaskemaskine ADP 8453

Læs gratis den danske manual til Whirlpool ADP 8453 (8 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Whirlpool ADP 8453, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

GB -1-

Chart

(see at right for options description)

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the program.

When the door is opened during a washing cycle,

the cycle is temporarily paused: the Start indicator

blinks. To resume the cycle close the door and

push Start button again.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute

(0:01 is shown into the display).

If pressed when the dishwasher is switched off,

it drains any possible liquids from dishwasher

(1 minute process).

PROGRAM SELECTION

BUTTON

Push “P” button (repeatedly)

until selected program number

is shown on the display

(P1...Px) - see “Table of

programs” below.

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional options) and may

vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic

calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/

Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.

Table of programs

Deter-

gent

Consumption

Drying

Phase

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Sensor 40-70°C

Delay

Half load

Recommended program for

routine washes, with dried-on

food (e.g. EN 50242).

X 7-14 1.00-1.60 70-155 Full

Pre-Wash cold

Delay Crockery to be washed later. — 4.0 0.03 14 NO

Fragile 40°C

Delay

Light soiling, for example

glasses and cups.

X 10.0 0.85 100 Light

Rapid 45°C

Delay

Lightly soiled crockery, with no

dried-on food.

X 11.0 0.80 30 NO

Eco

50°C

Delay

Half load

Normally soiled crockery.

Energy-saving program.

X 11.0 0.92 230 Full

Fast Daily 60°C

Delay

Half load

Normally soiled crockery. X 10.0 1.30 80 Full

Steam

Delay

Program including steam

action dedicated for heavily

soiled crockery, pots and pans.

Soaking or hand pretreatment

is no longer needed.

X 14.0 1.70 180 Full

Hygiene

Delay

Normally or heavily soiled

crockery, with additional

antibacterial wash. Program

interruption (e.g. due to door

opening) can compromise

elimination of germs.

X 13.0 1.50 118 Full

5019 396 03622

Options and display description

SALT INDICATOR

When lit (at the end of the cycle),

the salt reservoir needs to be

refilled.

HALF LOAD BUTTON

Half load cycle can be used for the

upper or lower rack. Select the

required program then press the

“Half Load” button - the light

comes on. Turns off at the end of

the program.

The “Half Load” option can be

used with the programs

indicated in the table of

programs.

TABLET SETTING

This setting allows to optimize the cycle performances

according the type of detergent used.

Push the Tablet button for 3 seconds (until the indicator lights

up) if you are using the combined detergents in tablet (rinse aid,

salt and detergent in 1 dose).

If you are using powder detergent or liquid detergent, the

Tablet indicator on the control panel has to be off.

DELAYED START BUTTON

Push the button (repeatedly)

to delay the start of the

program. Adjustable from 1 to

24 hours. With each press of

the button, the delayed start

indicator increases by one

hour and after 24 restarts from

0. Then press the START

button. The dishwasher will

start after the set time.

RINSE AID INDICATOR

When lit (at the end of the cycle),

the rinse aid dispenser needs to

be refilled.

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates

the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS

QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY

BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES

AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

Quick reference guide

Whirpool is a registered trademark of Whirpool USA

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADP 8453
