Side 1/32

ENQuick Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

CONTROL PANEL

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

Pro-

gram

Programs description

Drying

phase

Natu-

ralDry

Available

options

Duration

ofwash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware,

that for this use, it is the most ecient programme in terms of its

combined energy and water consumption, and that it is used to

assess compliance with the EU Ecodesign legislation.

3:10 9.5 0.75

Sense® 50°- 60°- For normally soiled dishes with dried food

residues. Senses the level of soiling on the dishes and adjusts the

program accordingly.

1:25 - 3:00 7.0 - 14.0 0.90 - 1.40

Intensive 65° - Program recommended for heavily soiled crockery,

especially suitable for pans and saucepans.

2:50 16.0 1.60

Mixed 60° - Mixed soil. For normally soiled dishes with dried food

residues.

2:30 16.0 1.30

Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that

ensures optimal cleaning and drying performance in shorter time.

1:25 11.5 1.10

Crystals 45° - Program for delicate items, which are more sensitive

to high temperatures, for example glasses and cups.

1:40 11.5 1.20

Rapid 30’ 50° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Without drying.

0:30 9.0 0.50

Silent 50° - Suitable for night-time operation of the appliance.

With the lowest noise.

3:30 15.0 1.15

Sanitizing 65° - Normally or heavily soiled crockery, with addition-

al antibacterial wash. Can be used to perform maintenance of the

dishwasher.

1:40 10.0 1.30

PROGRAMS TABLE

Before using the appliance carefully read the Safety Instruction

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

8. Multizone indicator

lights

9. Multizone button

10. Delay button

11. Turbo button with

indicator light

12. Power Clean® button with indicator light

13. START/Pause button with indicator light / Tab

FIRST TIME USE

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the ap-

pliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

854 6 97 10 11 12 13

Quick GuideEN

DELAY - The start time of the program may be delayed for a period of

time between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

POWER CLEAN® - Thanks to the additional power jets this option pro-

vides a more intensive and powerful wash in the lower rack, in the spe-

cic area. This option is recommended for washing pots and casseroles.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

MULTIZONE - If there are not many dishes to be washed, a half load-

ing may be used in order to save water, electricity and detergent.

Bydefault the appliance washes dishes in all racks.

Please scan the QR code on your product in order to have more detailed information.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

TURBO - This option can be used to reduce the duration of the main

programs while maintaining the same washing and drying

performance levels.

NaturalDry is a convection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furni-

ture, thus door will not be opened when the option of TURBO is on.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

Pro-

gram

Programs description

Drying

phase

Natu-

ralDry

Available

options

Duration

ofwash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

10.

Pre-Wash - Use to refresh crockery planned to be washed later.

No detergent to be used with this program.

0:12 4.5 0.01

11.

Self- Clean 65° - Program to be used to perform maintenance of

the dishwasher, to be carried out only when the dishwasher is EMP-

TY using specic detergents designed for dishwasher maintenance.

0:50 8.0 0.85

OPERATION INDICATOR -

A LED light projected on the oor indicates

that the dishwasher is working.

One of the following operating modes can be selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds, stays o during

the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of the cycle

(default mode).

CUTLERY RACK

(loading example for the cutlery rack)

The third rack was designed to ho-

use the cutlery. Arrange the cutlery

as shown in the gure.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

POWER CLEAN®

Power Clean® uses the special water jets in the rear of cavity to wash more intensively the high dirty items. The lower rack has a

Space Zone, a special pull-out support in the rear of the rack that can be used to support frying pans or baking pans in upright

position, thus taking up less space.

Placing the pots/casseroles faced to the Power Clean® component please activate the POWER CLEAN® on the panel.

UPPER RACK

(loading example for the upper rack)

Load delicate and light dishes:

glasses, cups, saucers, low salad bowls.

LOWER RACK

For pots, lids, plates,

salad bowls, cutlery

etc. Large plates and

lids should ideally be

placed at the sides to

avoid interferences

with the spray arm.

The lower rack has tip-

up supports which can

be used in a vertical

position when arrang-

ing plates or in a hori-

zontal position (lower)

to load pans and salad bowls easily.

(loading example for the

lower rack)

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	W0I D741A S
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fuldt indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Installationsrum højde:	900 mm
Tilsluttet belastning:	1900 W
Støjniveau:	41 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	9
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Ikke anvendelig
Vandforbrug pr. cyklus:	9.5 L
Farve på kontrolpanel:	Sølv
Antal kuverter:	14 kuverter
Cyklustid:	190 min.
Forsinket start (maks.):	12 t
Opvaskeprogrammer:	Eco 50°C, Glass/delicate, Intensive 65°C, Mixed, Pre-wash, Quick, Silent 50°C
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.75 kWh
Energieffektivitetsskala:	A til G
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Støjemissionsklasse:	B
Energieffektivitetsklasse:	C
Energiforbrug pr. 100 cyklusser:	75 kWh
Brugerdefineret panel klar:	Ja
Temperatur (maks):	65 °C
Cyklustid (hurtigt vaskeprogram):	30 min.
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Maksimal varmtvandsforsyning temperatur:	60 °C
Whirlpool-teknologier (opvaskemaskine):	6th Sense, Powerclean Pro, Third rack
