Whirlpool WH6FC11BS7A0X Manual

Whirlpool Opvaskemaskine WH6FC11BS7A0X

Læs gratis den danske manual til Whirlpool WH6FC11BS7A0X (60 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 3.6 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Whirlpool WH6FC11BS7A0X, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/60
ENQuick Guide
1
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Only the rst time you do this: ll the salt reservoir
with water.
3. Position the funnel (see gure) and ll the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently prevent-
ing scale buildup on heater, contributing also to better cleaning eciency.
This system regenerates itself with salt, therefore it is required to rell
salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in nal rinse and nishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
A
C
D
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be lled when the RINSE AID
REFILL indicator light in the control panel is lit.
NEVER pour the rinse aid directly into the appli-
ance tub.
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the program so
that the best washing and drying results are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
Program
Programs description
Drying
phase
NaturalDry
Available options
*)
Duration
of wash
program
(h:min)
**)
Water
con-
sumption
(litres/cycle)
Energy
con-
sumption
(kWh/cycle)
1.
Eco 50°- Program is suitable to clean normally soiled tableware, that for
this use, it is the most ecient programme in terms of its combined en-
ergy and water consumption, and that it is used to assess compliance
with the EU Ecodesign legislation.
3:35 8.7 0.63
2.
Intensive 65° - Program recommended for heavily soiled crockery, es-
pecially suitable for pans and saucepans.
2:45 17.5 1.60
3.
6th Sense® 50-60°- For normally soiled dishes with dried food residues.
Senses the level of soiling on the dishes and adjusts the program ac-
cordingly.
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
4.
Fast Wash&Dry 50°
- Normally soiled crockery. Everyday cycle, that ensu-
res optimal cleaning and drying performance in shorter time.
1:25 11.5 1.10
5.
Crystals 45° - Program for delicate items, which are more sensitive to
high temperatures, for example glasses and cups.
1:40 12.0 1.20
6.
Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes
with no dried food residues. Without drying.
-
0:30 9.0 0.50
7.
Silent
50° - Suitable for night-time operation of the appliance. With the
lowest noise.
3:30 16.0 1.15
8.
Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-
bacterial wash. Can be used to perform maintenance of the dishwasher.
-
1:50 12.0 1.30
9.
Prewash - Use to refresh crockery planned to be washed later.
No detergent to be used with this program.
- -
0:10 4.5 0.01
CONTROL PANEL
FIRST TIME USE
More information in the Daily Reference Guide on website.
PROGRAMS TABLE
1. On-O / Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light / Keylock
4. Eco program indicator light
5. Keylock indicator light
6. Display
7. Program number and remaining time indicator
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid rell indicator light
11. Salt rell indicator light
12. Power Clean® button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
3
1
2
8
13
14
5
4
6
7 11 12
9
10
THANK YOU FOR BUYING AWHIRLPOOL PRODUCT.
In order to receive amore complete assistance, please
register your appliance on: www.whirlpool.eu/register
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
Quick Guide
EN
2
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
1 2 3
4
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)
please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in
aclockwise direction.
The lower spray arm may
be removed by pulling it
upwards.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address:
dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
OPTIONS AND FUNCTIONS
Please scan the QR code on your product in order to have more detailed information.
LOADING THE RACKS
CAPACITY: 11 standard place-settings
CARE AND MAINTENANCE
More information in the Daily Reference Guide on website.
KEY LOCK - A long press (for 3 seconds) of MULTIZONE button, will
activate the KEY LOCK function. To deactivate the KEYLOCK, long press again.
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab) - If you use powder or liquid detergent, this option
should be o.
MULTIZONE - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
By default the appliance washes dishes in all racks.
POWER CLEAN® - Thanks to the additional power jets this option
provides a more intensive and powerful wash in the lower rack, in the
specic area. This option is recommended for washing pots and casseroles.
NaturalDry is a convection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying perfor-
mance every day. Door opens at the temperature that is safe to your kitch-
en furniture.
CUTLERY RACK
The third rack was designed to
house the cutlery.
(loading example for the cutlery rack)
UPPER RACK
Load delicate and light dishes: glasses, cups, sau-
cers, low salad bowls.
The upper rack has tip-up supports which can be
used in a vertical position when arranging tea/ des-
sert saucers or in a lower position to load bowls and
food containers.
(loading example for the upper rack
FOLDABLE FLAPS
WITH ADJUSTABLE
PO
SITION
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large
plates and lids should ideally be placed at the sides to
avoid interferences with the spray arm.
The lower rack has tip-up supports which can be used in
a vertical position when arranging plates or in a horizon-
tal position (lower) to load pans and salad bowls easily.
(loading example for the lower rack)
POWER CLEAN®
Power Clean® uses the special water jets in the rear of
cavity to wash more intensively the high dirty items. The
lower rack has a Space Zone, a special pull-out support in
the rear of the rack that can be used to support frying
pans or baking pans in upright position, thus taking up
less space.
Placing the pots/casseroles faced to the Power Clean® component please
activate the POWER CLEAN® on the panel.

Produkt Specifikationer

Mærke: Whirlpool
Kategori: Opvaskemaskine
Model: WH6FC11BS7A0X
