French Door Bottom Mount Refrigerator with Ice
Dispenser (WRFC5036R*)
PRODUCT DIMENSIONS
Handle and door style will vary with model.
Dimensions 'C' and 'D' include rollers extended 3/4" (1.9 cm).
Electrical Requirements
Electrical: A 115 V, 60 Hz AC only, 15 A or 20 A fused, grounded electrical
supply is required. It is recommended that a separate circuit serving only your
freezer be provided. Use an outlet that cannot be turned off by a switch. Do not
use an extension cord.
Water: A cold water supply with water pressure between 35 psi and 120 psi
(241 kPa and 827 kPa) is required to operate the water dispenser and ice
maker. If you have questions about your water pressure, call a licensed,
qualied plumber.
NOTE: If the water pressure is less than what is required, the ow of water
from the water dispenser could decrease or ice cubes could be hollow or
irregularly shaped.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a reverse
osmosis system going to the water inlet valve of the refrigerator needs to be
between 35 psi and 120 psi (241 kPa and 827 kPa).
If a reverse osmosis water ltration system is connected to your home cold
water supply, the water pressure to the reverse osmosis system needs to be a
minimum of 40 psi to 60 psi (276 kPa to 414 kPa).
Description Dimensions
A Depth without handles
297/16" (74.85 cm)
B Depth with handles
317/16" (79.95 cm)
C Height to top of cabinet
68" (175 cm)
D Overall Height
69" (177.6 cm)
E Width of cabinet
35" (90.5 cm)
F Width with door open 90° 44¼" (112.4 cm)
G Depth without doors 25" (63.5 cm)
Model Number WRFC5036R*
Model Size 23.4 cu ft (662.61 L)
Because Whirlpool Corporation policy includes a continuous commitment
to improve our products, we reserve the right to change materials and
specifications without notice.
Dimensions are for planning purposes only. For complete details, see
Installation Instructions packed with product. Specifications subject to
change without notice.
W11778218A
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
C
D
E
90° 90°
F
A
B
G
