Side 1/1

40 85 400GBASE-CSR4 0nm m MPO

40GBASE-CSR4 Specifications

Form Factor: QSFP+

Data Rate: 40G

Tx/Rx Wavelength: 085 nm

Compatible with: See Table

Reach: 400m

Cable Type: MMF

Interface Type: QSFP+

DDM/DOM: Yes

Connector Type: MPO/MTP

Power Supply: 3.3V

Temperature Range: 0-70°C

Warranty: Lifetime - See Warranty Document

40GBASE- CSR4 Features

• Hot pluggable SFP+ footprint

• Supports .995 to .5 Gb/s bit rates 39 42

• RoHs-6 compliant

• Built-in digital diagnostic function

• Compliant with OEM Vendor multi-source agreement

Testi ng

Compatibility Tested: Each transceiver is tested in an origi-

nal host switch for recognition (Loop back test)

Performance Tested: Tested over an optical connection of

the intended distance. Recreated in the lab using a bit fiber

spool method

100% Testing of all Transceivers: No Batch Testing (1-10%)

Popular Compatibility Options

Vendor Part Code

Wire 40GBASE-CSR4-WR

Cisco QSFP-40G-CSR4

Juniper QSFPP-4X10GE- SR

Mellanox MC2210411-SR4E

Arista QSFP-40G-XSR4

Brocade -QSFP-ESR4 40G

HPe JG709A

Avago AFBR-79EEPZ

Palo Alto PAN-40G-QSFP-CSR4

Huawei HW QSFP-40G-eSR4

Dell 407-BBPH

Extreme 40GB-ESR4-QSFP

75+ other vendors available

Description

This 4 -CSR4 compatible QSFP+ transceiver provides 40G throughput up to 400m over Multi-Mode F re (MMF) us-0G ib

ing a wavelength of 0nm via an MPO/MTP connector. It is guaranteed to be 100% compatible with the host OEM 85

switch, router or network interface card (NIC).

This easy to install, hot swappable transceiver has been programmed, uniquely serialized and application tested to

ensure that it will initialize and perform identically to the OEM Transceiver. Digital Optical Monitoring (DOM) support

is also present to allow access to real-time operating parameters. We stand behind the quality of our products and

proudly offer a lifetime warranty.

Produkt Specifikationer

Mærke:	Wire Technologies
Kategori:	Ikke kategoriseret
Model:	40GBASE-CSR4-WR
Produktfarve:	Sølv
Strømforbrug (typisk):	1.2 W
Driftstemperatur (T-T):	0 - 70 °C
Certificering:	CE, FCC, REACH
Bæredygtighedscertifikater:	RoHS
Maksimal dataoverførselshastighed:	42000 Mbit/s
Oprindelsesland:	Kina
SFP modtagertype:	Fiberoptisk
Grænsefladetype:	QSFP+
Fiber optisk strømstik:	MTP/MPO
Enkelttilstand fiber (SMF) understøttet:	Ingen
Multitilstand fiber (MMF) understøttet:	Ja
Maksimal overførselsafstand:	400 m
Bølgelængde:	850 nm
Mærke kompatibilitet:	MSA Compliant
Gennemsnitstid mellem fejl (MTBF):	1000000 t
Fiber ethernet kabelteknologi:	40GBASE
Minimal driftstemperatur:	0 °C
Maksimal driftstemperatur:	70 °C
SFP transceiver standard:	CSR4
Tx effekt (min.):	-4 dBmW
Tx effekt (maks.):	5 dBmW
Duplex system:	Fuld
Digital diagnose overvågning (DDM):	Ja
