Side 1/1

40 310GBASE-LR 14L nm 2 km LC

40GBASE- LR Specifications 4L

Form Factor: QSFP+

Data Rate: 40G

Tx/Rx Wavelength: 1310nm

Compatible with: See Table

Reach: 2km

Cable Type: SMF

Interface Type: QSFP+

DDM/DOM: Yes

Connector Type: Duplex-LC

Power Supply: 3.3V

Temperature Range: 0-70°C

Warranty: Lifetime - See Warranty Document

40GBASE- LR Features 4L

• Hot pluggable SFP+ footprint

• Supports .995 to .5 Gb/s bit rates 39 42

• RoHs-6 compliant

• Built-in digital diagnostic function

• Compliant with OEM vendor mu i-source agreement lt

Testi ng

Compatibility Tested: Each transceiver is tested in an origi-

nal host switch for recognition (Loop back test)

Performance Tested: Tested over an optical connection of

the intended distance. Recreated in the lab using a bit fib re

spool method.

100% Testing of all Transceiver s: No Batch Testing (1-10%)

Popular Compatibility Options

Vendor Part Code

Wire 40GBASE-LR4L- WR

Cisco WSP-Q40GLR4L

Juniper JNP-QSFP-40GE-IR4

Mellanox MC2210511-IR4

Arista QSFP-40G-LRL4

Brocade -QSFP-LR4L 40G

HPe JL286A

D-Link DEM-QX02Q-IR4

Avaya AA1404001- E6

Huawei 02311YVB

Intel QSFP-IR4-40G

Avago QSFP-40GE-IR4

75+ other vendors available

Description

This 4 -0G LR4L compatible QSFP+ transceiver provides 4 throughput up to 2 over Single-Mode F (SMF) using 0G km ibre

a wavelength of 1310nm via an LC connector. It is guaranteed to be 100% compatible with the host OEM switch,

router or network interface card (NIC).

This easy to install, hot swappable transceiver has been programmed, uniquely serialized and application tested to

ensure that it will initialize and perform identically to the OEM Transceiver. Digital Optical Monitoring (DOM) support

is also present to allow access to real-time operating parameters. We stand behind the quality of our products and

proudly offer a lifetime warranty.

Produkt Specifikationer

Mærke:	Wire Technologies
Kategori:	Ikke kategoriseret
Model:	40GBASE-LRL4-WR
Produktfarve:	Sølv
Strømforbrug (typisk):	3.5 W
Driftstemperatur (T-T):	0 - 70 °C
Certificering:	CE, FCC, REACH
Bæredygtighedscertifikater:	RoHS
Maksimal dataoverførselshastighed:	41200 Mbit/s
Oprindelsesland:	Kina
SFP modtagertype:	Fiberoptisk
Grænsefladetype:	QSFP+
Fiber optisk strømstik:	LC
Enkelttilstand fiber (SMF) understøttet:	Ja
Multitilstand fiber (MMF) understøttet:	Ingen
Maksimal overførselsafstand:	2000 m
Bølgelængde:	1310 nm
Mærke kompatibilitet:	MSA Compliant
Gennemsnitstid mellem fejl (MTBF):	1000000 t
Fiber ethernet kabelteknologi:	40GBASE
Minimal driftstemperatur:	0 °C
Maksimal driftstemperatur:	70 °C
SFP transceiver standard:	LRL4
Tx effekt (min.):	-7 dBmW
Tx effekt (maks.):	4.3 dBmW
Duplex system:	Fuld
Digital diagnose overvågning (DDM):	Ja
