INSTALLATION INSTRUCTIONS

RECOMMENDED MODELS

P/N 006355

Notice to installing contractor: Instructions must remain with installation.

FM0447

Rev. A

0823

Supersedes

0220

PREINSTALLATION CHECKLIST - ALL INSTALLATIONS

DATE INSTALLED:

MODEL NUMBER:

EFFLUENT*/SUMP/DEWATERING SEWAGE

55 / 59, 139 Series

140 / 4140, 145 / 4145, 160 / 4160 Series 270 / 4270 Series

180 / 4180, 191, 371, 372, 373 Series 280 / 4280, 290 / 4290 Series

Product information presented here reflects conditions at time of publication. Consult factory regarding discrepancies or inconsistencies.

MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347

SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961

Tel: (502) 778-2731 • 1 (800) 928-PUMP

Visit our website:

zoellerpumps.com

Trusted. Tested. Tough.

* Efuent systems should specify that pumps should not handle solids exceeding 3/4” (19 mm) in order to prevent large solids from entering leeching elds, mound

systems, etc. (70 Series have 3/8” (9 mm) solids capability. 50, 140/4140, 371 and 372 Series have 1/2” (13 mm), 130 Series has 5/8" (16 mm), 145/4145, 160/4160, 180/4180

and 373 models have 3/4” [19 mm].) Where code permits, sewage pumps can be used for efuent systems. Non-automatic pumps with external-level controls are

recommended for septic tank efuent applications.

1. Inspect all materials. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using. DO NOT remove the test plugs

from the pump.

2. Carefully read the literature provided to familiarize yourself with specic details regarding installation and use. These materials should be retained for future

reference.

SEE BELOW FOR

LIST OF WARNINGS

CAUTION

SEE BELOW FOR

LIST OF CAUTIONS

REFER TO WARRANTY ON PAGE 2.

1. To reduce the risk of electrical shock, a properly grounded receptacle or

control box must be installed in accordance with the governing codes. Never

remove ground pin from plug.

2. Make certain that the ground fault interrupter protected receptacle or control

box is within the reach of the pump’s power supply cord. DO NOT USE AN

EXTENSION CORD. Extension cords that are too long or too light do not deliver

sufcient voltage to the pump motor, and they could present a safety hazard

if the insulation were to become damaged or the connection end were to fall

into a damp or wet area.

3. Make sure the pump's electrical supply circuit is equipped with fuses or circuit

breakers of proper capacity. A separate branch circuit is recommended, sized

according to the local electrical codes for the current shown on the pump

name plate.

4. Testing for ground. As a safety measure, each electrical outlet should be checked

for ground using a circuit analyzer which will indicate if the power, neutral and

ground wires are correctly connected to your outlet. If they are not, call a quali-

ed licensed electrician.

5. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM ITS POWER

SOURCE BEFORE HANDLING. If pump is wired direct, de-energize the circuit

at the control box. Wear insulated protective shoes and do not stand in water.

Pumps equipped with a 3-prong ground plug are designed to help protect

against electrical shock. DO NOT, UNDER ANY CIRCUMSTANCES, REMOVE

THE GROUND PIN.

6. Installation and servicing of the pump, electrical circuits and hardware should

only be performed by a qualied, licensed electrician.

7. Risk of electrical shock. Do not remove power supply cord and strain relief

or connect conduit directly to the pump. If the supply cable is damaged, it

must be replaced by the Manufacturer or an Authorized Service and Warranty

Center to avoid a hazard.

8. Pump contains oil which becomes pressurized and hot when operating. Allow

2-1/2 hours after disconnecting before attempting service.

9. Pump is not intended for potable water due to possible contamination by oil

contained in the pump.

10. Risk of electrical shock. These pumps have not been investigated for use in

swimming pools and marine areas.

11. Prop65 Warning for California residents: Cancer and Reproductive Harm-

www.P65Warnings.ca.gov.

1. Check to be sure your power source is capable of handling the voltage

requirements of the motor, as indicated on the pump name plate.

2. The installation of variable level oat switches is the responsibility of the

installing party, and care should be taken that the tethered oat switch will

not hang up on the pump apparatus or pit peculiarities and is secured so that

the pump will shut off. It is recommended to use rigid pipe and ttings and

the pit be 18" (46 cm) or larger in diameter.

3. Vent hole. It is necessary that all submersible sump, efuent, and sewage

pumps capable of handling various sizes of solid waste be of the bottom intake

design to reduce clogging and seal failures. If a check valve is incorporated

in the installation, a 3/16" (5 mm)vent hole must be drilled in the discharge pipe

below the check valve and pit cover to purge the unit of trapped air. Vent

hole should be checked periodically for clogging. The vent hole on a High

Head application may cause too much turbulence. If you choose not to drill a

vent hole, be sure the pump case and impeller is covered with liquid before

connecting the pipe to the check valve. NOTE: THE HOLE MUST BE BELOW

THE BASIN COVER AND CLEANED PERIODICALLY. Water stream will be visible

when pump is operating.

4. Pump should be checked frequently for debris and/or build up which may

interfere with the oat “on” or “off” position. Repair and service should be

performed by an Authorized Service and Warranty Center.

5. Maximum operating temperature for standard model pumps must not exceed

130 °F (54 °C). Maximum operating temperatures for 70 series and model

211 must not exceed 110 °F (43 °C). Maximum operating temperatures

for 73, 75, must not exceed 104 °F (40 °C).

6. Do not operate a pump in an application where the Total Dynamic Head is

less than the minimum Total Dynamic Head listed on the Pump Performance

Curves.

7. For health reasons, do not unplug, turn off, or disable pump and use pump tank

system as a way to ll up a sink or laundry tray, etc.

8. Pumps must be installed in accordance with the National Electrical Code and

all applicable local codes and ordinances. Pumps are not to be installed in

locations classied as hazardous in accordance with National Electric Code,

ANSI, NFPA 70.

NOTE: Pumps with the "UL" mark and pumps with the "US" mark are tested to UL

standard UL778. CSA certied pumps are certied to CSA standard C22.2 No. 108.

Zoeller Pump Company

Product on our website:

http://reg.zoellerpumps.com/

NOTICE: VENT HOLE FOR

CHECK VALVE

SEE #3 IN CAUTION SECTION

BELOW AND #4 ON PAGE 3

Many Zoeller products contain

registered trademarks for

design and/or the color green:

U.S. #4,849,524 / #5,024,907

55, 57 pumps powered by

Zoeller Motor Works motor

in lieu of all other warranties expressed or implied; and we do not authorize any

representative or other person to assume for us any other liability in connection

with our products.

Contact Manufacturer at, 3649 Cane Run Road, Louisville, Kentucky 40211, Attention:

Customer Support Department to obtain any needed repair or replacement of

part(s) or additional information pertaining to our warranty.

MANUFACTURER EXPRESSLY DISCLAIMS LIABILITY FOR SPECIAL,

CONSEQUENTIAL OR INCIDENTAL DAMAGES OR BREACH OF EXPRESSED

OR IMPLIED WARRANTY; AND ANY IMPLIED WARRANTY OF FITNESS FOR A

PARTICULAR PURPOSE AND OF MERCHANTABILITY SHALL BE LIMITED TO THE

DURATION OF THE EXPRESSED WARRANTY.

Some states do not allow limitations on the duration of an implied warranty, so

the above limitation may not apply to you. Some states do not allow the exclusion

or limitation of incidental or consequential damages, so the above limitation or

exclusion may not apply to you.

This warranty gives you specic legal rights and you may also have other rights

which vary from state to state.

LIMITED WARRANTY

Manufacturer warrants, to the purchaser and subsequent owner during the warranty

period, every new product to be free from defects in material and workmanship

under normal use and service, when properly used and maintained, for a period

of one year from date of purchase. Proof of purchase is required. Parts that fail

within the warranty period that inspections determine to be defective in material

or workmanship will be repaired, replaced or remanufactured at Manufacturer's

option, provided however, that by so doing we will not be obligated to replace an

entire assembly, the entire mechanism or the complete unit. No allowance will

be made for shipping charges, damages, labor or other charges that may occur

due to product failure, repair or replacement.

This warranty does not apply to and there shall be no warranty for any material

or product that has been disassembled without prior approval of Manufacturer,

subjected to misuse, misapplication, neglect, alteration, accident or uncontrollable

act of nature; that has not been installed, operated or maintained in accordance

with Manufacturer's installation instructions; that has been exposed to outside

substances including but not limited to the following: sand, gravel, cement, mud,

tar, hydrocarbons, hydrocarbon derivatives (oil, gasoline, solvents, etc.), or other

abrasive or corrosive substances, wash towels or feminine sanitary products,

etc. in all pumping applications. The warranty set out in the paragraph above is

CONDITION COMMON CAUSES

A. Pump will not start or run.

Check fuse, low voltage, overload open, open or incorrect wiring, open switch, impeller or seal bound mechanically, motor or

wiring shorted. Float assembly held down. Switch, damaged or out of adjustment.

Motor overheats and trips

overload or blows fuse.

Incorrect voltage, negative head (discharge open lower than normal) impeller or seal bound mechanically, motor shorted.

C. Pump starts and stops too often.

Float switch tether length too short, check valve stuck open, or none installed in long distance line, overload open, bidding,

sump pit too small.

D. Pump will not shut off.

Debris under oat assembly, oat bound by basin sides or other, switch damaged or out of adjustment.

Pump operates but delivers little

or no water.

Check inlet, strainer housing, discharge pipe, and vent holes for obstructions. Discharge head exceeds pump capacity. Low

or incorrect voltage. Incoming water containing air or causing air to enter pumping chamber. Incorrect motor rotation. (3

phase pumps only)

Drop in head and/or capacity

after a period of use.

Increased pipe friction, clogged line or check valve. Abrasive material and adverse chemicals could possibly deteriorate impeller

and pump housing. Check line. Remove base and inspect.

G. Tank or ttings leak.

Carefully tighten pipe joints (use pipe dope) and screws. Check gasket location, tighten lid evenly. Do not over tighten ttings

or screws.

If the above checklist does not reveal the problem, consult the Product Support Department. Do not attempt to service or otherwise disassemble

pump. Service must be peformed by a Zoeller Authorized Service and Warranty Center. Visit www.zoeller.com for a complete list of service centers.

SERVICE CHECKLIST

DO’S & DON'T’S FOR INSTALLING UNIT

1. DO read all installation material with the unit.

2. DO inspect unit for any visible damage caused by shipping. Contact dealer

if unit appears to be damaged.

3. DO remove all debris from the basin. Be sure that the pump will have a hard,

level surface beneath it. DO NOT install on sand, gravel or dirt.

4. DO be sure that the area is large enough to allow proper clearance for the

level control switch(es) to operate properly.

5. DO Always Disconnect Pump From Power Source Before Handling.

DO always connect to a separately protected and properly grounded circuit.

DO NOT ever cut, splice, or damage power cord (Only splice in a watertight

junction box).

DO NOT carry or lift pump by its power cord.

DO NOT use an extension cord.

6. DO install a check valve and a union in the discharge line.

DO NOT use a discharge pipe smaller than the pump discharge.

7. DO NOT utilize this unit for pumping gasoline or other hazardous liquids.

8. DO test pump immediately after installation to be sure the system is working

properly.

9. DO review all applicable governing codes and verify that the installation

conforms to each of them.

10. DO consult manufacturer for clarications or questions.

11. DO

consider a two-pump system with an alarm where an installation may become

overloaded or primary pump failure would result in property damages.

12. DO consider a D.C. Backup System where a sump or dewatering pump is

necessary for the prevention of property damages from ooding due to A.C.

power disruptions, mechanical or electrical problems or system overloading.

13. DO inspect and test system for proper operations at least every 3 months.

In instances where property damages are incurred as a result of an alleged product failure, the property

owner must retain possession of the product for investigation purpose.

Produkt Specifikationer

Mærke:	Zoeller
Kategori:	Vandpumpe
Model:	E186

Har du brug for hjælp?

Hvis du har brug for hjælp til Zoeller E186 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Vandpumpe Zoeller Manualer

Zoeller E186 Manual

15 Juni 2025

Zoeller M161 Manual

15 Juni 2025

Zoeller 519-0005 Manual

24 August 2024

Zoeller Aquanot Spin 508 Manual

23 August 2024

Zoeller M73 Manual

23 August 2024

Zoeller M53 Manual

23 August 2024

Zoeller Flex 540 Manual

23 August 2024

Zoeller Shark Grinder 803 Manual

23 August 2024

Vandpumpe Manualer

Nyeste Vandpumpe Manualer

Little Giant 5-MSP Manual

16 Juni 2025

Little Giant VCL-24ULS Manual

16 Juni 2025

Little Giant 6EC-CIM Manual

16 Juni 2025

Little Giant 6EC-CIA-SFS Manual

16 Juni 2025

Little Giant VCMX-20ULS Manual

15 Juni 2025

Milwaukee M18 FVP5 Manual

15 Juni 2025

Little Giant VCMA-20ULS Manual

15 Juni 2025

Little Giant VCCA-20ULS Manual

15 Juni 2025

Little Giant 9SC-CIM Manual

15 Juni 2025

Little Giant 6-CIA Manual

15 Juni 2025
