Side 1/12

2057 pump powered by

Zoeller Motor Works motor

FM1923

0823

Supersedes

1222

INSTALLATION INSTRUCTIONS

2000 SERIES HIGH TEMPERATURE INTERMITTENT PUMPS

AVAILABLE MODELS

P/N 014028

CAUTION

SEE BELOW FOR

LIST OF CAUTIONS

SEE BELOW FOR

LIST OF WARNINGS

PREINSTALLATION CHECKLIST - ALL INSTALLATIONS

1. Inspect your pump. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using. DO NOT remove the test plugs in the cover nor the

motor housing.

2. Carefully read the literature provided to familiarize yourself with specic details regarding installation and use. These materials should be retained for future reference.

1. Check to be certain your power source is capable of handling the voltage requirements of

the motor, as indicated on the pump name plate.

2. Check valves used in High Temperature service must be all metal swing type check valves.

3. Dewatering and efuent sump pumps are not designed to handle raw sewage.

4. Maximum intermittent operating temperature for high temperature pumps must not exceed

200 °F (93 °C).

5. The installation of automatic pumps with variable level oat switches or nonautomatic pumps

using auxiliary variable level oat switches is the responsibility of the installing party and

care should be taken that the tethered oat switch will not hang up on the pump apparatus

or pit peculiarities and is secured so that the pump will shut off. It is recommended to use

rigid piping and ttings and the pit be 18" (46 cm) or larger in diameter.

6. Vent hole. It is necessary that all submersible sump, efuent, and sewage pumps capable

of handling various sizes of solid waste be of the bottom intake design to reduce clogging

and seal failures. If a check valve is incorporated in the installation, a

/16" (5 mm) vent hole

must be drilled in the discharge pipe below the check valve and pit cover to purge the unit

of trapped air. Trapped air is caused by agitation and/or a dry basin. Vent hole should be

checked periodically for clogging. The 50 or 90 Series pumps have a vent located in the

pump housing opposite the oat, adjacent to a housing lug, but an additional vent hole is

recommended. The vent hole on some applications may cause too much turbulence. If you

choose not to drill a vent hole, be sure the pump case and impeller is covered with liquid

before connecting the pipe to the check valve and no inlet carries air to the pump intake.

NOTE: THE HOLE MUST ALSO BE BELOW THE BASIN COVER AND CLEANED PERIODICALLY.

Water stream will be visible from this hole during pump run periods.

7. Pump should be checked frequently for debris and/or build up which may interfere with

the oat “on” or “off” position. Repair and service should be performed by Zoeller Pump

Company Authorized Service Station only.

8. Do not operate a pump in an application where the Total Dynamic Head is less than the

minimum Total Dynamic Head listed on the Pump Performance Curves.

1. Make sure there is a properly grounded receptacle available. All pumps are furnished

with provisions for proper grounding to protect you against the possibility of electrical

shock.

2. Make certain that the receptacle is within reach of the pump’s power supply cord. DO NOT

USE AN EXTENSION CORD. Extension cords that are too long or too light do not deliver

sufcient voltage to the pump motor, and they could present a safety hazard if the insulation

were to become damaged or the connection end were to fall into a wet or damp area.

3. Make sure the pump electrical supply circuit is equipped with fuses or circuit breakers

of proper capacity. A separate branch circuit is recommended, sized according to the

“National Electrical Code”, for the current shown on the pump nameplate.

4. Testing for ground. As a safety measure, each electrical outlet should be checked for

ground using an Underwriters Laboratory Listed circuit analyzer which will indicate if the

power, neutral and ground wires are correctly connected to your outlet. If they are not,

call a qualied, licensed electrician.

5. For Added Safety. Pumping and other equipment with a 3-prong grounded plug must be

connected to a 3-prong grounded receptacle. For added safety, the receptacle may be

protected with a ground-fault circuit interrupter. When a pump needs to be connected in

a watertight junction box, the plug can be removed and spliced to the supply cable with

proper grounding. For added safety, this circuit may be protected by a ground-fault circuit

interrupter. The complete installation must comply with the National Electrical Code and

all applicable local codes and ordinances.

6. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM ITS POWER SOURCE BEFORE

HANDLING. Single phase pumps are supplied with a 3-prong grounded plug to help protect

you against the possibility of electrical shock. DO NOT, UNDER ANY CIRCUMSTANCES,

REMOVE THE GROUND PIN. The 3-prong plug must be inserted into a mating 3-prong

grounded receptacle. If the installation does not have such a receptacle, it must be changed

to the proper type, wired and grounded in accordance with the National Electrical Code

and all applicable local codes and ordinances. Three phase pumps require motor starting

devices with motor overload protection. See FM1596 for simplex installations or FM0486 for

duplex installations. Pumps must be installed in accordance with the National Electrical Code

and all applicable local codes and ordinances. Pumps are not to be installed in locations

classied as hazardous in accordance with National Electrical Code, ANSI/NFPA 70.

7. Risk of electrical shock. Do not remove power supply cord and strain relief or connect

conduit directly to the pump.

8. Installation and servicing of electrical circuits and hardware should be performed by a

qualied, licensed electrician.

9. Pump installation and servicing should be performed by a qualied person.

10. Risk of electric shock. These pumps have not been investigated for use in swimming pool

areas.

11. Prop65 Warning for California residents:

: Cancer and Reproductive Harm-

www.P65Warning.ca.gov.

REFER TO WARRANTY ON PAGE 2.

Product information presented here reflects conditions at time of publication. Consult factory regarding discrepancies or inconsistencies.

MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347

SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961

Tel: (502) 778-2731 • 1 (800) 928-PUMP

Visit our website:

zoellerpumps.com

Trusted. Tested. Tough.

SERIES HP DISCHARGE SOLIDS PH MATERIAL

2057 1/3 1-1/2" 1/2" (13 mm) 1 Cast iron / Stainless steel

2098 1/2 1-1/2" 1/2" (13 mm) 1 Cast iron / Stainless steel

2137 1/2 1-1/2" 5/8" (16 mm) 1 Cast iron / Stainless steel

2282 1/2 2" or 3" 2" (50 mm) 1 Cast iron / Stainless steel

Zoeller Pump Company

Product on our website:

http://reg.zoellerpumps.com/

In instances where property damages are incurred as a result of an alleged product failure, the property

owner must retain possession of the product for investigation purpose.

PERFORMANCE CHARACTERISTICS

SWITCH DATA

ENVIRONMENTAL LIMITATIONS:

• Switch is designed for 200 ºF (93 °C) water or lower.

• Switch can be exposed to chemicals associated with boiler water treatment and at concentrations typically associated with this process.

• Not to be used with ammable liquids.

• Not meant for use in hazardous locations as dened by the

National Electric Code and ANSI/NFPA 70.

• Switch is not designed to be directly wired to power source

derivatives (oil, gasoline, solvents, etc.), or other abrasive or corrosive

substances, wash towels or feminine sanitary products, etc. in all pumping

applications. The warranty set out in the paragraph above is in lieu of

all other warranties expressed or implied; and we do not authorize any

representative or other person to assume for us any other liability in

connection with our products.

Contact Manufacturer at, 3649 Cane Run Road, Louisville, Kentucky 40211,

Attention: Customer Service Department to obtain any needed repair or

replacement of part(s) or additional information pertaining to our warranty.

MANUFACTURER EXPRESSLY DISCLAIMS LIABILITY FOR SPECIAL,

CONSEQUENTIAL OR INCIDENTAL DAMAGES OR BREACH OF EXPRESSED

OR IMPLIED WARRANTY; AND ANY IMPLIED WARRANTY OF FITNESS

FOR A PARTICULAR PURPOSE AND OF MERCHANTABILITY SHALL BE

LIMITED TO THE DURATION OF THE EXPRESSED WARRANTY.

Some states do not allow limitations on the duration of an implied warranty,

so the above limitation may not apply to you. Some states do not allow

the exclusion or limitation of incidental or consequential damages, so

the above limitation or exclusion may not apply to you.

This warranty gives you specic legal rights and you may also have other

rights which vary from state to state.

LIMITED WARRANTY

Manufacturer warrants, to the purchaser and subsequent owner during

the warranty period, every new product to be free from defects in material

and workmanship under normal use and service, when properly used

and maintained, for a period of one year from date of purchase by the

end user, or 18 months from date of original manufacture of the product,

whichever comes rst. Parts that fail within the warranty period, one

year from date of purchase by the end user, or 18 months from the date

of original manufacture of the product, whichever comes rst, that

inspections determine to be defective in material or workmanship, will be

repaired, replaced or remanufactured at Manufacturer's option, provided

however, that by so doing we will not be obligated to replace an entire

assembly, the entire mechanism or the complete unit. No allowance will

be made for shipping charges, damages, labor or other charges that may

occur due to product failure, repair or replacement.

This warranty does not apply to and there shall be no warranty for any

material or product that has been disassembled without prior approval of

Manufacturer, subjected to misuse, misapplication, neglect, alteration,

accident or act of God; that has not been installed, operated or maintained

in accordance with Manufacturer's installation instructions; that has

been exposed to outside substances including but not limited to the

following: sand, gravel, cement, mud, tar, hydrocarbons, hydrocarbon

GALLONS

LITERS

2098

24080

160

20 30 40 50

2057

320 400

70 80 90 100

2137

110

2282

FEET

METERS

PUMP PERFORMANCE CURVE

MODEL 2057/2098/2137/2282

@ 200 °F (93 °C) WATER TEMPERATURE

120

FLOW PER MINUTE

TOTAL DYNAMIC HEAD

TOTAL DYNAMIC HEAD/FLOW

PER MINUTE

EFFLUENT AND DEWATERING

MODEL

Feet

Shut-off Head:

2057 2098 2137 2282

Meters Gal. Liters

43511 53419025066148391. 55

20 6.1

4.6

3.0 31

-- --

11 7 56

23 87

155

212 75

30 114

201

284 85

322

208

18 ft.(5.5m) 22 ft.(6.7m) 25 ft.(7.6m) 24 ft.(7.3m)

Gal. Liters Gal. Liters Gal. Liters

014036
