Outdoor PTZ

Mounting on the Wall

Using Accessory Sets

Installation Guide

For Models:

I93, I94, I95, I96, KCM-8211

www.acti.com

Installation Guide

Table of Contents

Mounting Accessory Set Solutions .................................. 3

Heavy Duty Wall Mount Installation Procedures ............. 4

Step 1: Unpack the Camera ...................................................................... 4

Step 2: Install the Heavy Duty Wall Mount ............................................... 6

Optional: Add Extension Tube ................................................................. 6

Step 3: Install the Camera ......................................................................... 7

Step 4: Connect the Cables ...................................................................... 9

How to Waterproof the Cable Using the Cable Gland ........................... 10

How to Waterproof the Cable Using the Conduit Gland ........................ 14

Heavy Duty Wall Mount with Junction Box

Installation Procedures ................................................... 18

Step 1: Unpack the Camera .................................................................... 19

Step 2: Unpack the Junction Box ........................................................... 20

Step 3: Drill the Holes on the Wall .......................................................... 21

Step 4: Waterproof the Cables ................................................................ 21

Step 5: Install the Junction Box ............................................................. 23

Step 6: Install the Heavy Duty Wall Mount ............................................. 24

Optional: Add Extension Tube ............................................................... 24

Step 7: Install the Camera ....................................................................... 25

Step 8: Connect the Cables .................................................................... 26

Appendices ....................................................................... 28

How to Install Extension Tubes .............................................................. 28

How to Use the Power Adapter (For I9x Models) .................................. 29

How to Attach the Safety Wire Strap (For I9x Models) ......................... 30

Safety Information ............................................................ 32

Produkt Specifikationer

Mærke:	ACTi
Kategori:	Ikke kategoriseret
Model:	PMAX-0305
Type:	Montering
Bredde:	145 mm
Dybde:	232 mm
Højde:	90 mm
Produktfarve:	Hvid
Husmateriale:	Aluminium
Understøttet placering:	Universel
Kapabilitet:	B54, B55, B56, B61, B64, B65, B67, I51, I71, I93, I94, I95, I96, KCM-8211
Maksimal vægtkapacitet:	- kg
