ADAM-3968/20
68-pin SCSI-II to Three 20-pin Wiring
Terminal Module for DIN-rail Mounting
User’s Manual
ADAM and the ADAM logo are trademarks of Advantech
Part No. 2003396810 1st Edition
Printed in taiwan July 2000
Introduction
The ADAM-3968/20 is a 68-pin SCSI-II to three 20-pin wiring terminal
module for DIN-rail mounting. This terminal module can be readily
connected to the Advantech PC-Lab cards and allow easy yet reliable to
individual daughter boards.
Features
Low cost universal DIN-rail mounting screw terminal module for
PC-LabCards with 68-pin SCSI-II connectors
Converts one 68-pin SCSI-II connector to three 20-pin connectors
Case dimensions: 77.5mm(W) X 80mm(L) X 54.3mm(H)
(3.1” X 3.2" X 2.1")
Pin Assignments
Architecture
Note: An +12V supply must be applied externally when the daughter
boards such as PCLD-782/785 etc. is connected via a 20-pin connector
through ADAM-3968/20.
