Side 1/32

User Manual

PoE & PoE+ Giga-

MiniMc LFPT

PoE&PoE+Giga-MiniMc(LFPT) User Manual ii

The documentation and the software included with this product are copyrighted 2023

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. The information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties that may result from its use.

Acknowledgments

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident, or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced free of charge during the warranty period. For out-of-

warranty repairs, customers will be billed according to the cost of replacement mate-

rials, service time, and freight. Please consult your dealer for more details.

If you believe your product to be defective, follow the steps outlined below.

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages displayed when the prob-

lem occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain a return merchandize authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a completed Repair and Replacement

Order Card, and a proof of purchase date (such as a photocopy of your sales

receipt) into a shippable container. Products returned without a proof of pur-

chase date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship the pack-

age prepaid to your dealer.

Part No. 2009039000 Edition 1

Printed in Taiwan August 2023

Produkt Specifikationer

Mærke:	Advantech
Kategori:	Audio/video konverter
Model:	IMC-390-SE-US
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	92.58 mm
Dybde:	97 mm
Højde:	20.32 mm
Vægt:	450 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-35 - 75 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Driftstemperatur (T-T):	0 - 50 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC Class A, UL/cUL, CSA
Netværksstandarder:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z
LED-indikatorer:	Ja
AC-adapter inkluderet:	Ja
Indgangsspænding:	100 - 240 V
Driftshøjde:	0 - 10000 m
Intern:	Ingen
Maksimal dataoverførselshastighed:	1000 Mbit/s
Plug and play:	Ja
Fiber optisk strømstik:	SC
Maksimal overførselsafstand:	40000 m
Bølgelængde:	1310 nm
Ekstern strømadapter:	Ja
Ethernet-grænsefladetype:	Gigabit Ethernet
Total Power over Ethernet (PoE):	25.5 W
Power over Ethernet plus (PoE+) porte, antal:	2
Auto MDI/MDI-X:	Ja
Jumbo Frames support:	Ja
Jumbo rammer:	10240
DIN-skinne montering:	Ja
Auto-forhandling:	Ja
Fiberkanal porte:	1
Fibertilstandsstruktur:	Enkeltilstand
Indgående omregner interface:	10Base-T, 100Base-T, 1000Base-T
