Side 1/2

Please read the manual before using the equipment!

The B48 L is a battery powered one channel phantom power supply

for P48 condenser microphones. The 48V power supply is for those

applications when a condenser microphone is used where no

phantom power from a mixer is available. The additional mini-XLR

audio output and the included mini-XLR to mini-XLR connection

cable support a direct connection to all AKG body-pack

transmitters. The phantom power of the audio input supplies

microphones with 48V and meet the P48 standard. B48 L is

designed to meet the demand of lowest noise level even in

operation with high-end condenser microphones for professional

applications in theater or touring applications.

Insert two batteries into the battery compartment, aligning the batteries with the

polarity symbols inside the battery compartment. The B48 L provides a polarity

protection. If you insert the batteries the wrong way, the B48 L will not be

powered. Press the ON/OFF button

Green POWER status LED

» Green: Power OK, Phantom power >42V

» Dark: Phantom power <42V

Red LOW BAT status LED

» LR6 alkaline, FR6 lithium batteries: Operation time below 1 hour

» HR6 rechargeable batteries: Operation time below 2 hours

Audio frequency range

Gain

Finish

Audio input connector

Audio output connectors

Battery

Noise level

Operating temperature

Dimensions

Net weight

Item Number

20 – 24 000 Hz

0 dB

black

1x XLR 3-pin (f) audio input (48V/10mA)

1x XLR 3-pin (m) audio output

1x mini-XLR (m) audio output

for direct connection to AKG wireless body-

pack transmitter

2x AA size batteries (LR6, HR6, FR6)

< 2µV

-10 to 50 °C (14 to 122 °F)

123x65x28.5 mm (4.84x2.56x1.12 in.)

120 g (0.26 lbs)

3163Z00010

AKG Acoustics GmbH

Lemböckgasse 21–25, 1230 Vienna, AUSTRIA, e-mail: sales@akg.com

For other products and distributors worldwide visit www.akg.com

Features, specifications and appearance are subject to change without notice.

www.akg.com

5028606_A

1. Do not spill any liquids on the equipment and do not drop any objects through the

ventilation slots in the equipment.

2. The equipment may be used in dry rooms only.

3. The equipment may be opened, serviced, and repaired by authorized personnel only. The

equipment contains no user-serviceable parts.

4. Operate the equipment with the included AA size dry batteries or the dry or rechargeable

batteries recommended in this manual only.

5. If any solid object or liquid penetrates into the equipment, shut down the sound system

immediately. Remove the batteries from the equipment immediately and have the

equipment checked by AKG service personnel.

6. Do not place the equipment near heat sources such as radiators, heating ducts, or

amplifiers, etc. and do not expose it to direct sunlight, excessive dust, moisture, rain,

mechanical vibrations, or shock.

7. Clean the equipment with a moistened (not wet) cloth only. Be sure to disconnect the

power supply cable from the power outlet before cleaning the equipment! Never use

caustic or scouring cleaners or cleaning agents containing alcohol or solvents since these

may damage the enamel and plastic parts.

8. Use the equipment for the applications described in this manual only. AKG cannot accept

any liability for damages resulting from improper handling or misuse.

9. Any modifications made to the equipment without the express consent of AKG may lead

to violations of telecommunications legislation voicing the operating permit.

1. When scrapping the equipment, separate the case, circuit boards, and cables, and dispose

of all components in accordance with local waste disposal rules.

2. The packaging of the equipment is recyclable. Dispose of the packaging in an appropriate

container provided by the local waste collection/recycling entity and observe all local

legislation relating to waste disposal Environment and recycling.

Printed in Austria.

Produkt Specifikationer

Mærke:	AKG
Kategori:	Mikrofon
Model:	B48 L
Bredde:	123 mm
Dybde:	65 mm
Højde:	28.5 mm
Vægt:	120 g
Produktfarve:	Sort
Produkttype:	Batteri
Driftstemperatur (T-T):	-10 - 50 °C
Stik:	XLR, mini-XLR
Indgangsfrekvens:	20 - 24000 Hz
Kapabilitet:	P48
XLR udgående:	1
Monteringsbeslag inkluderet:	Ja
Fantomstrøm:	42 V
Forstærkning:	0 dBi
Cylindrisk batteri-størrelse:	AA
