GMK315 Mounting Kit

CHEVROLET

2012-13 SONIC

VEHICLE APPLICATIONS

TECH Ver. 11/12 PRINT Ver. 11/12

DASH DISASSEMBLY AND RADIO REMOVAL

2 3

KIT ASSEMBLY INSTRUCTIONS

Note: This kit is an (ISO) mounting kit only. The mounting sleeve of your new radio

cannot be used when ISO mounting an aftermarket radio.

DO NOT attach the (4) OEM Panel metal clips yet.

1. Insert pocket into lower section of GMK315 panel, it will lock into place.

2. Insert ISO mountable radio between ISO mount brackets and loosely attach to sides

of radio using screws provided with radio when possible, or screws supplied with kit.

3. Slide radio forward or backward for desired look and tighten screws.

4. You may use the trim ring supplied with you radio or the single din trim

included with the GMK315.

5. Test fit kit/radio by mounting it using the (4) OEM screws, and making sure the

main frame of the GMK315 aligns correctly and does not leave any gaps when

installed. If everything looks correct go to step #6. If not, go back to step # 3.

6. Snap OEM air vents from OEM panel into the GMK315 panel.

7. Attach the metal panel fastener clips (from OEM panel) (4) to the mounting tab on

the back side of the GMK315 panel.

8. Suggested…Attach a rear support bracket to the rear of the new radio and adjust as

necessary to support the weight of the radio.

Single ISO Mount Applications

Double DIN Mount Applications

DO NOT attach the (4) OEM Panel metal clips yet.

1. Insert ISO mountable radio between ISO mount brackets and loosely attach to

sides of radio using screws provided with radio when possible, or screws supplied

with kit.

2. Slide radio forward or backward for desired look and tighten screws.

3. You may use the trim ring supplied with you radio or the single din trim included

with the GMK315

4. Test fit kit/radio by mounting it using the (4) OEM screws, and making sure the

main frame of the GMK315 aligns correctly and does not leave any gaps when

installed. If everything looks correct go to step #5. If not, go back to step # 2.

5. Snap OEM air vents from OEM panel into the GMK315 panel.

6. Attach the metal panel fastener clips (from OEM panel) (4) to the mounting tab on

the back side of the GMK315 panel.

7. Suggested…Attach a rear support bracket to the rear of the new radio and adjust as

necessary to support the weight of the radio.

Fig A

Fig B

1. With a soft took remove OEM dash panel surrounding the radio, including air vents.

Note: if panel seems difficult to remove you can remove the glove box and push on

the bottom right tab on the panel to help loosen.

2. Remove (4) 7mm Hex Head Screw. Remove radio and unplug all harnesses and

antenna connections.

3. Remove OEM air vents to be used on the GMK315 panel.
