Using the ArgoxScan

8110/8120/8150/8250/8310/8312

The ArgoxScan can automatically scan barcode at a distance.

Simply aim and pull the trigger. Code scanning is performed

along the center of the light bar emitted from the reading

window. This bar must cover the entire code.

Successful scanning shall be obtained by tilting the scanner

with respect to the barcode to avoid direct reflections that

impair the reading performance, especially for 2D barcode.

Recommended Steps

When the required settings have been configured, all settings

are stored in non- volatile memory of scanner after reading

EXIT Label. Recommended steps are as follows.

1) Set right host interface for your scanner.

(The scanner is in factory default shown as bold label)

2) Set interface to optimize protocol of scanner with your

host in interface section.

3) Set system control of scanner, such as specific

adjustments double confirm, power saving, indicator

and scanning mode which you prefer usage in system

control section.

4) Set code options of scanner for your usage in code

option section. You must make sure to enable the

symbology first, then Min./Max. code length, code ID

checksum and truncate digits are also converted.

5) Set string format of the scanner, such as preamble,

postamble Prefix, suffix, code ID and code name

transmission for your application in string format

section.

Note: If still not work properly. Please contact your dealer for

further information.



CONTENTS

Chapter 1 Introduction

Introduction…………………………..……………….

1

Default Setting ……………………………………….

2

ArgoxScan8110/8120 specification ………………..

4

ArgoxScan8150/8250/8310/8312 specification …..

7

Programming the ArgoxScan…………………….. 10

Chapter 2 Parameter Setting

Interface……………………………………………….…

12

Interface Selection …………………………………..

12

Keyboard wedge …………………………………….

13

RS-232 …………………………………………….….

18

Wand Emulation …………………………….……….

21

Pin Assignments …………………………………….

24

System Control……………………………………….

28

Scan ………………………………………………….

28

Indication …………………………..…………………

34

Code Option…………………………………….………

36

UPCA ……………………………………..………….

36

UPCE …………………………………………………

42

EAN-13 ……………………………………………….

46

EAN-8 …………………………………………………

50

Code 39 ………………………………………………

54

Interleaved 2 of 5 ……………………………………

58

Industrial 2 of 5 ………………………………………

60

Matrix 2 of 5 Eur ……………………………………

62

Codabar ………………………………………………

64

Code-128 ……………………………………………

67

Code-93 ………………………………………………

71

Code-11 ………………………………………….……

74

MSI/Plessey ………………………………………….

76

UK/Plessey …………………………………………..

78

Telepen ……………………………………………….

80

Standard 2 of 5 ………………………………………

82

China Post ……………………………………………

84

Italian pharmacode …………………………………

86

Code 16K …………………………………..…………

88

PDF-417 ………………………………………………

90

EAN UCC Composite………………………………..

92

RSS-14 ……………………………………………….

94

RSS-Limited…………………………………..…… 96

RSS-Expanded…………………………………..…..

98

Micro-PDF…………………………………..………..

100

String Format……………………………………………

102

String Setting / Transmission

(Prefix/Suffix)…………………………………………

102

String Setting / Transmission

(Preamble/Postamble)………………………………

104

String Setting / Transmission

(Insert Group Characters)…………………………..

106

String Setting / Transmission

(Others)…….…………………………………………

110

Appendix…………………………………………………

112

Test Chart …………………………………………….

112

ASCII Code Table ……………………………………

115

Parameter setting List ……………………………….

116

0

1

Introduction

Installation- Keyboard Wedge

1) First of all, you must switch off power for the

terminal/computer.

2) Disconnect the keyboard cable from the back of the

terminal/computer.

3) Connect the appropriate interface cable to the scanner

and to the terminal/computer.

4) Turn the terminal/computer power on.

RS-232

1) Disconnect power to the terminal/computer.

2) Connect the appropriate interface cable and external

power supply (DC adapter) to the scanner.

3) Plug the serial connector into the serial port on the back

of your computer/terminal. Tighten the two screws to

secure the connector to the port.

4) Plug the power pack into power source.

5) Once the scanner has been fully connected, turn the

terminal/computer power back on.

USB (Simulate with keyboard wedge)

1) Connect the USB cable between scanner and PC.

2) Windows will automatically detect the USB device.

Note: If any of the above operation is incorrect, turn off the

power immediately and check any improper

connections. Go through all above steps again.

2



Default setting

For each barcode shown as below:

Code Type

Read

Enable

Checksum

Verification

Enable

Checksum

Transmission

Enable

Code

ID

8110 / 8120

UPC-A A

UPC-E E

EAN-13 F

EAN-8 FF

Code-39

Interleaved

2 of 5 i

Industrial

2 of 5 - - i

Matrix 2 of 5 B

Codabar %

Code-128 #

Code-93

&

Code-11 One digit

O

MSI/Plessey @

UK/Plessey @

Telepen S

Standard 2 of 5

- - i

RSS-14 - - R4

RSS-Limited - - RL

RSS-Expanded

- - RX

China Post t

Italian

Pharmacode.

p

3

Code Type

Read

Enable

Checksum

Verification

Enable

Checksum

Transmission

Enable

Code

ID

8150

8250

8310

8312

UPC-A A

UPC-E E

EAN-13 F

EAN-8 FF

Code-39

Interleaved

2 of 5 i

Industrial

2 of 5 - - i

Matrix 2 of 5 B

Codabar %

Code-128 #

Code-93

&

Code-11 One digit

O

MSI/Plessey @

UK/Plessey @

Telepen S

Standard 2 of 5

i

China Post t

Italian

Pharmacode. p

Code-16K - - -

PDF417 - - -

EAN UCC

Composite - - - RC

RSS-14 - R4

RSS-Limited - RL

RSS-Expanded

- RX

Micro-PDF - - - U

4

Weight 155 g 120 g

ArgoScan 8110 / 8120

Specification Model 8110 Model 8120

Operational

Light Source 660 nm Visible Red LED

Optical System 2048 pixel CCD

(Charge-coupled device)

Depth of Scan Field

0-80 mm

(CODE 39,

PCS=90%, 20mils)

0-150 mm

(code 39,

PCS=90%, 20mils)

Scanning Width 80 mm at contact

75mm at contact

Scan Speed 50 scans/sec 100 scans/sec

Resolution 4mils, Code39, PCS=90%, on contact

5mils, Code39, PCS=45%, on contact

Print Contrast 30% or more

Scanning Angle Pitch: 60° Skew: 75°

Decode Capability

Auto-discriminates all standard

barcodes; Other symbologies can be

ordered optionally

Beeper Operation

7 tones or no beep

Indicator Green led Blue led

Mechanical

Length 182 mm

Width-handle 26 mm

Width-head 90 mm

Depth-handle 51 mm 49mm

Depth-head 35 mm

5

Cable – K/B wedge

Straight 2.0 m

Cable – universal

type Straight 2.3 m

Connector type RJ-45 phone jack connector

Case material ABS

Cushion material Rubber

Electrical

Input Voltage 5 VDC ± 0.25V

Power - Operating

380 mW 850mW

Power - Standby 240 mW 250 mW

Current - Operating

76 mA @ 5 VDC

170 mA@5 VDC

Current - Standby 48 mA @ 5 VDC

50 mA@5 VDC

DC Transformers Class 2; 5VDC @ 450 mA

Agency listing FCC Class A,CE, BSMI

Environmental

Operating

Temperature 0 to 45 (32 to 113 )

Storage -20 to 60

(-4 to 140 )

Humidity 5% to 90% relative humidity,

non-condensing

Light Level Up to 15000 Lux.

Up to 20000 Lux.

Shock 1.0m 1.2m

Contaminants Seals to resist airborne particulate

contaminants

Ventilation None required

7

ArgoScan 8150 / 8250 / 8310 / 8312

Specification Model

8150/8250

Model

8310/8312

Operational

Light Source 660

nm Visible Red

LED

630 nm Visible

Red

LED

Optical System 2048 pixel CCD

(Charge-coupled device)

Depth of Scan Field

0-250 mm

(CODE 39,

PCS=90%, 20mils)

Up to 600mm

(CODE 39,

PSC=90%, 20mils)

Scanning Width 120 mm 160mm

Scan Speed 200 scans/sec 450 scans/sec

Resolution 0.1mm(4mils);

Code39,PCS=90%,

on contact (8150);

Code39,PCS=45%,

on contact (8250)

0.1mm(4mils)

Code39,PCS=90%

Print Contrast 25% or more 25% or more

Scanning Angle Front: 60° Rear: 60° Yaw: 75°

Decode Capability

Auto-discriminates all standard

barcodes; Other symbologies can be

ordered optionally (2D symbologies for

8250 and 8312 only)

Beeper Operation

7 tones or no beep

Indicator Green led Green & Red led

Mechanical

Length 182 mm 164 mm

8

Depth-head 35 mm 35 mm

Weight 150 g (cable not

included)

176 g (cable not

included)

Cable – K/B wedge

Straight 2.0 m Coiled 2.5 m

Cable – universal

type Straight 2.3 m Coiled 2.5 m

Cable- USB Straight 2.0 m Coiled 2.5 m

Connector type RJ-45 phone jack connector

Case material ABS plastic ABS (over molded

at contact pointed)

Cushion material Rubber Double injection

Electrical

Input Voltage 5 VDC ± 0.25V

Power - Operating

1275 mW 800 mW

Power - Standby 600 mW 350 mW

Current - Operating

255 mA (8150);

180 mA (8250)

@ 5 VDC

160 mA @ 5 VDC

Current - Standby 120 mA (8150);

100 mA (8250)

@ 5 VDC

70 mA @ 5 VDC

DC Transformers Class 2; 5VDC @ 450 mA

Agency listing UL, FCC Class A,

CE

UL, FCC Class B,

CE

Environmental

Width-handle 26 mm 30 mm

Width-head 74 mm 78 mm

Depth-handle 51 mm 56 mm

12

Exit

Interface Selection

This decoder built-in scanner comes in one model and

supports interfaces such as keyboard wedge, RS232 serial

wedge, wand emulation, and the latest USB interface. In

most of the cases, simply selecting an appropriate cable with

a device code will work for a specific interface.

Interface selection: You can change factory interface

default for other type interface. By plugging different cables,

setting right interface, then the scanner will be changed to

another interface. However, you must make sure which cable

you need.

Keyboard/RS232/UBS Auto detection: By setting this

function, it will automatically select the Keyboard wedge or

RS-232 or UBS interface for user.

Option Bar Code Option Alphanumeric

Entry

Interface selection

Keyboard Wedge

RS-232

Wand emulation

USB

Keyboard

/RS232/USB

Auto detection

00

01

02

(8110/8150/8250)

03

04

Program

Note: -Default

13

Exit

Keyboard wedge

As a keyboard interface, the scanner supports most of the

popular PCs and IBM terminals. The installation of the wedge

is a fairly simple process without any changes of software or

hardware.

Keyboard Type: Select keyboard type connector of your

host computer. Scanner must be selected to the appropriate

host interface cable converter.

Option Bar Code Option Alphanumeric

Entry

Keyboard type

IBM AT, PS/2

Reserved

00

01

02

03

04

05

06

Program

14

Keyboard wedge

Keyboard Layout: The selecting of keyboard layout

supports many country languages other than USA keyboard

layout. First you need to confirm country language that you

desire. In DOS, using command “keyb” to select the

desirable keyboard layout or in WINDOWS entry “Control”

then pops “Keyboard” to select country at “language” item.

For details, please refer to your DOS or WINDOWS user’s

manual.

Keyboard Speed: By selecting, you can change output

speed of scanner to match with host computer. Generally, set

00 or 01 in working high speed. If some output characters of

barcode have been lost, you may need to set 05 or 06 to

match your host keyboard speed.

Function Key: Set Enable, scanner can output code as

pressing function-key in your application program while the

barcode datas contain ASCII value between 01

16

to 1F

16

.

Refer to ASCII table.

Numeric Key: The Keypad has to be selected if your

application program is only keypad numeric code acceptable.

So, scanner will output code as press numeric keypad when

it read numeric digit. (The keypad is in the right side of

keyboard, and Num Lock control key is also on.) If

Alt+Keypad is selected, the data characters will be

transmitted as “Alt” + numbers. For example, when sending

character “A”, the actual sending will be “Alt”+65. It is also

useful when using non-English OS and keyboard layout.

Option Bar Code Option Alphanumeric

Entry

Program

16

Keyboard wedge

Caps Lock: By selecting Caps lock”ON” or Caps lock”OFF”,

scanner can get Caps Lock status.

Power-on simulation: All of the PCs check the keyboard

status during power-on selftest. It is recommended to Enable

function if you are working without keyboard installation. It

simulates keyboard timing and pass keyboard present status

to the PC during power-on.

Inter-character delay: This delay is inserted after each data

characters transmitted. If the transmission speed is too high,

the system may not be able to receive all characters. Adjust it

and try out suited delay to make system work properly.

Block transmission delay: It is a delay timer between

barcode data output. The feature is used to transfer

continually with shorter barcode data or multi-field scanning.

17

Exit

Option Bar Code Option Alphanumeric

Entry

Caps lock

Caps lock”ON”

Caps lock”OFF”

00

01

Power-on simulation

Disable

Enable

00

01

Inter-character delay

00-99 msec 00-99

02

Block transmission

delay

00-99 10 msec 00-99

10

Program

19

Exit

Option Bar Code Option Alphanumeric

Entry

Flow control

None

RTS/CTS

Xon/Xoff

ACK/NAK

00

01

02

03

Inter-character delay

00-99 (msec) 00-99

00

Block transmission

delay

00-99 (10 msec)

00-99

00

Response delay

00-99 (100 msec)

00-99

20

Program

20

Exit

Option Bar Code Option Alphanumeric

Entry

Baud rate

300 BPS

600 BPS

1200 BPS

2400 BPS

4800 BPS

9600 BPS

19200 BPS

38400 BPS

00

01

02

03

04

05

06

07

Parity

None

Odd

Even

00

01

02

Data bit

8 bits

7 bits

00

01

Stop bit

One bit

Two bits

00

01

Program

22

Wand Emulation (for 8110/8150/8250)

Output speed:

This setting is same as serial transmission

baud rate, and it must be approbated your wand decode

resolution. The unit of speed is a width of minimum narrow

bar.

Margin delay: It is a timer of zone like space zone of

barcode label margin. The width of margin time will be added

before and after in each barcode data automatically when it

is transmitted.

Transmit delay: It is a delay time between barcode data

output. It is the same as Block transmission delay of

keyboard wedge.

23

Exit

Option Bar Code Option Alphanumeric

Entry

Output speed

620 pps

1250 pps

2500 pps

5000 pps

10000 pps

20000 pps

*pps: pixel per

second

00

01

02

03

04

05

Reserved

00

Reserved

00

Margin delay

00-99 (10 pixel)

00-99

15

Transmit delay

00-99 (10 msec)

00-99

30

Program

24

Pin Assignments

AS Series 8-pin RJ-45 Connector

Pin RS-232 Keyboard

1 VCC (+5V) VCC (+5V)

2 TXD NC

3 NC CLK / PC

4 NA DATA / PC

5 CTS DATA / KB

6 RXD NC

7 RTS CLK / KB

8 GND GND

8-pin 10-pin

AS Series 10-pin RJ-45 Connector

Pin RS-232 Keyboard

1 I/F I/F

2 VCC (+5V) VCC (+5V)

3 TXD NC

4 NC CLK / PC

5 GND DATA / PC

6 CTS DATA / KB

7 RXD NC

8 RTS CLK / KB

9 GND GND

10 NC GND

1

2

4

3

5 6

7 8

1

2

4

3

5 6

7 8

9

10

25

Keyboard Wedge Combo Connector (To Host Side):

Pin Mini-DIN 6P Male

DIN 5P Female

1 DATA / PC DATA / KB

2 NC NC

3 GND GND

4 VCC (+5V) VCC (+5V)

5 CLK / PC CLK / KB

6 NC NC

RS-232 DB-9F Connector (To Host Side):

Pin Definition

1 NC

2 TXD

3 RXD

4 NC

5 GND

6 NC

7 CTS

8 RTS

9 VCC (+5V)

4

2

3

1

8

6

9

7

5

3

1

2

4 5

3

4

5

6 2

1

DIN 5P Female Connector

Mini-DIN 6P Male Connector

27

28

Scan

Scanning mode:

Good-read off-The trigger button must be pressed to

activate scanning. The light source of scanner stops

scanning when there is a successful reading or no code is

decoded after the Stand-by duration elapsed.

Momentary-The trigger button acts as a switch. Press button

to activate scanning and release button to stop scanning.

Alternate-The trigger button acts as a toggle switch. Press

button to activate or stop scanning.

Timeout off-The trigger button must be pressed to activate

scanning, and scanner stops scanning when no code is

decoded after the Stand-by duration elapsed.

Continue-Scanner always keeps reading, and it does not

matter when trigger button is pressed or duration is elapsed.

Test only-For test of scan performance only. It is improper to

be utilized to check the accuracy of transmitted data.

Double read timeout: The scanner will require a several

times successful decoding to confirm the data when enabled.

The more confirming times required, the more inhibitive

miss-reading code will be shown. The Multi field scan Enable

function won’t be able to work if set Double confirm.

Double confirm: If the barcode has been scanned twice,

then only the first barcode will be accepted.

Supplement Check Counter: It will be more reliable to read

the barcode with extension (supplement) like UPCE/A or

EAN-8/13, but slow down the decoding speed when this

counter is set more.

29

Exit

Option Bar Code Option Alphanumeric

Entry

Scanning mode

Good-read off

Momentary

Alternate

Timeout off

Continue

Test only

00

01

02

03

04

05

Stand-by duration

01-99 (second) 00-99

06

Double read timeout

01-99 (10 msec)

01-99

50

Double confirm

00-99

(00: no double

confirm)

00-09

00

Supplement Check

Counter

00-64

(verifications)

00-64

30

Program

31

Exit

Option Bar Code Option Alphanumeric

Entry

Global min. code length

00-99

(00-64)

00-99

(AS-8120)

04

Global max. code length

00-99

(00-64)

04-99

99

(AS-8120 ,

64 )

Inverted image scan

Disable

Enable

00

01

CTS trigger

Disable

Enable

00

01

*7AJ*

Power saving mode

(For 8310/8312)

Disable

Enable

00

01

Program

32

Scan

Position indication (8110 excluded): If the function is

enabled, scan beam will flash as a pointer to help you aim at

the bar code prior to scanning. The code will not be scanned

until you press the trigger.

Stand mode selection: Normally activated with continuous

mode. If it is set as LED “off”, the scanner red beam will turn

off automatically in case not used, but will turn on again

immediately when scanning bar codes. This is available for

all ArgoxScan series scanners (AS-8000/AS-8120/AS-8150/

AS-8250/AS-8310/8312)

PCS Enhancement: The reading performance under low

PCS value will be improved when this function is enabled. It

is recommended to set “Double confirm” (7AD) other than

“00”.

34

Indication

Power on alert: After power-on the scanner it will generate

an alert signal to indicate a successful self-test.

LED indication: After each successful reading, the LED

above the scanner will light up to indicate a good barcode

reading.

Beeper indication: After each successful reading, the

scanner will beep buzzer to indicate a good barcode reading,

and its Beep loudness, Beep tone freq. and Beep tone

duration are adjustable.

Beep loudness/Beep tone freq./Beep tone duration: You

can adjust Beep Loudness, Beep tone and Beep duration for

a good reading upon favorite usage.

Exit

35

E

xit

Option Bar Code Option Alphanumeric

Entry

Power on alert

Disable

Enable

00

01

LED indication

Disable

Enable

00

01

Beeper indication

Disable

Enable

00

01

Beep loudness

00-07 00-07

07

Beep tone freq.

00-99 (100Hz) 00-99

26

Beep tone duration

00-99 (10 msec)

00-99

10

Program

36

UPCA

Format

Leading

Zero

Data Digits

(11 Digits)

Check

Digit

Read: Enable or disable the read function.

Check-sum transmission: By setting Enable, checks sum

will be transmitted.

Truncate leading/ending: The leading or ending digits of

barcode data characters can be truncated when these values

are set to non-zero. It will beep instead of reading anything

when the truncate value is more than the barcode data digits

or the value of Truncate Leading is overlapped with that of

the Ending. The maximum value of truncate digits is 15.

Code ID setting: Code ID setting is a character used to

represent the symbol upon a succeeding reading. A Code ID

setting is prefixed to the data begin or end transmitted if the

feature is selected. If you want application to transmit Code

ID, you must set Code ID transmission to Enable first. Refer

to Code ID transmission.

38

UPCA

Insertion group number selection: The scanner offers max.

two insertion groups for one symbology. By setting one or two

digits to indicate which insertion group you want to insert.

You may refer to Character insertion. The function is to insert

specific characters as a group into transmitted data of

selected symbologies. Enable the group insertion by

selecting the group number.

Example: Group 2 set 02 or 20.

Group 1 and 4 set 14 or 41.

Notes 1): Group number set to “0” means that no group

insertion required.

2): Details about the Insert Group settings please refer

to page 98~101, and page 107 ASCII code table.

Supplement digits: The Supplement digits barcode is the

supplemental 2 or 5 characters for WPC code.

Format

Leading

Zero

Data Digits

(11 Digits)

Check

Digit

Supplement Digits

2 or 5 or

UCC / EAN

128

39

Exit

Option Bar Code Option Alphanumeric

Entry

Insert group number

selection

00-44 00-44

00

Supplement digits

(For 8110/8150/8250)

None

2 digits

5 digits

UCC/EAN 128

Auto detection

00

01

02

03

04

Supplement digits

(For 8120/8310/8312)

None

2 digits

5 digits

2,5 digits

UCC/EAN 128

2, UCC/EAN 128

5, UCC/EAN 128

All

00

01

02

03

04

05

06

07

Program

40

UPCA

Truncation / Expansion: The leading “0” digits of UPCA

data characters can be truncated when the function is

enabled.

41

Exit

Option Bar Code Option Alphanumeric

Entry

Truncation/

Expansion

(For 8110)

Disable

Enable

00

01

Truncation/

Expansion (For

8120/8150/8250/

8310/8312)

None

Truncate leading

zero

Expand to EAN13

00

01

02

The

Program

42

UPCE

Read: Format

Leading

Zero

Data Digits (6

Digits)

Check

Digits

Check-sum transmission: By setting Enable, checks sum

will be transmitted.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Check-sum

transmission

Disable

Enable

00

01

Truncate leading

0-15 00-15

00

Program

43

Exit

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< E >

44

UPCE

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Supplement digits:

Format

Leading

Zero

Data Digits

(6 Digits)

Check

Digit

Supplement Digits

2 or 5 or

UCC/EAN

128

Expansion: The expansion function is used only for UPCE

and EAN-8 code reading. It extends to 13-digits with “0” digits

when the feature is enabled.

Example: Barcode “0123654”

Output: “0012360000057”

UPCE-1: Enable scanner to read UPCE with leading digit 1.

Option Bar Code Option Alphanumeri

c Entry

Insert group number

selection

00-44 00-44

00

Supplement digits

(For 8110/8150/8250)

None

2 digits

5 digits

UCC/EAN 128

Auto detection

00

01

02

03

04

Program

46

EAN-13

Read: Format

Data Digits (12 Digits)

Check Digits

Check-sum transmission: By setting Enable, checks sum

will be transmitted.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Truncate leading zero: Refer to Truncation / Expansion of

UPCA.

The

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Check-sum

transmission

Disable

Enable

00

01

Truncate leading

0-15 00-15

00

Program

47

Exit

Truncate ending

0-15 00-15

00

Truncation leading

zero

Disable

Enable

00

01

48

EAN-13

Code ID setting: Refer to page 36 Insertion group number

selection of UPCA.

Insertion group number selection: Refer to Insertion group

selection of UPCA.

Supplement digits:

Format

Data Digits

(12 Digits)

Check

Digits

Supplement Digits

2 or 5 or

UCC / EAN

128

ISBN/ISSN: The ISBN (International Standard Book Number)

and ISSN (International Standard Serial Number) are two

kinds of barcode for book and magazines. The ISBN is 10

digits with leading “978” and the ISSN is 8 digits with leading

“977” of the “EAN-13” symbology.

Example: Barcode “9789572222720” - Output: “9572222724”

Example: Barcode “9771019248004” - Output: “10192484”

Option Bar Code Option Alphanumeric

Entry

Code ID setting

00-ffH ASCII

code

00-ffH

< F >

Insert group number

selection

00-44 00-44

00

Program

49

Exit

Supplement digits

(For 8110/8150/8250)

None

2 digits

5 digits

UCC/EAN 128

Auto detection

00

01

02

03

04

Supplement digits

(For 8120/8310/8312)

None

2 digits

5 digits

2,5 digits

UCC/EAN 128

2, UCC/EAN

128

5, UCC/EAN

128

All

00

01

02

03

04

05

06

07

ISBN/ISSN conversion

Disable

Enable

00

01

52

EAN-8

Supplement digits: Format

Data Digits

(7 Digits)

Check

Digits

Supplement Digits

2 or 5 or

UCC/EAN 128

Truncation / Expansion: Refer to Truncate Leading zero of

UPCE.

Expansion: Refer to Expansion of UPCE.

Option Bar Code Option Alphanumeric

Entry

Supplement digits

(For 8110/8150/8250)

None

2 digits

5 digits

UCC/EAN 128

Auto detection

00

01

02

03

04

Supplement digits

(For 8120/8310/8312)

None

2 digits

5 digits

2,5 digits

UCC/EAN 128

2, UCC/EAN 128

5, UCC/EAN 128

All

00

01

02

03

04

05

06

07

Program

63

Exit

Checksum

Transmission

Disable

Enable

00

01

Max. code length

00-64 00-64

00

Min. code length

00-64 00-64

00

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< B >

Insert group number

selection

00-44 00- 44

00

71

Exit

Code-93

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Checksum2

(Optional)

Checksum Verification: The checksum is made as the sum

module 47 of the numerical values of all data digits.

Checksum Transmission: By setting Enable, checksum

will be transmitted.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Checksum

Verification

Disable

Enable

(two digits)

00

01

Checksum

Transmission

Disable

Enable

00

01

Program

74

Code-11

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Checksum2

(Optional)

Checksum Verification: The checksum is presented as the

sum module 11 of all data digits.

Checksum Transmission: By setting Enable, checksum1

and checksum2 will be transmitted upon your selected

checksum verification method.

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Checksum

Verification

Disable

One digit

Two digits

00

01

02

Program

75

Exit

Checksum

Transmission

Disable

Enable

00

01

Max. code length

00-64 00-64

00

Min. code length

00-64 00-64

00

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< O >

Insert group number

selection

00-44 00-44

00

77

Exit

Mod 11/10 03

Checksum

Transmission

Disable

Enable

00

01

Max. code length

00-64 00-64

00

Min. code length

00-64 00-64

00

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< @ >

Insert group number

selection

00-44 00-44

00

78

UK/plessey

Read: Format

Data Digits

(Variable)

Checksum1+2

(Optional)

Checksum Verification: The UK/Plessey has one or two

optional checksum digits. The checksum1 and checksum2

will be calculated as the sum module 10 or 11 of the data

digits.

Checksum Transmission: By setting Enable, checksum will

be transmitted.

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Checksum

Verification

Disable

Enable

00

01

Program

79

Exit

Checksum

Transmission

Disable

Enable

00

01

Max. code length

00-64 00-64

00

Min. code length

00-64 00-64

00

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< @ >

Insert group number

selection

00-44 00-44

00

80

Telepen

Read: IATA (International Air Transport Association).

Checksum Verification: The checksum is presented as the

sum module 10 or 11 of the data digits.

Checksum Transmission: By setting Enable, checksum will

be transmitted.

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Checksum

Verification

Disable

Enable

00

01

Checksum

Transmission

Disable

Enable

00

01

Program

81

Exit

Max. code length

00-64 00-64

00

Min. code length

00-64 00-64

00

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< S >

Insert group number

selection

00-44 00-44

00

82

Standard 2 of 5

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Check-sum verification: The checksum is made as the sum

module 10 of the numerical values of all data digits.

Check-sum transmission: By setting Enable, checksum

will be transmitted.

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Check-sum

verification

Disable

Enable

00

01

Program

*JAB*

83

Exit

*JAC*

Check-sum

transmission

Disable

Enable

00

01

Max. code length

00-64 00-64

00

Min. code length

00-64 00-64

00

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< i >

Insert group number

selection

00-44 00-44

00

84

China Post

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Max. code length

00-64

11

Min. code length

00-64

11

Program

85

Exit

Truncate leading

0-15

00-15

00

Truncate ending

0-15

00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< t >

Insert group number

selection

00-44

00

86

Italian Pharmacode (Code 32)

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Leading “A”: If this function is enabled, each prefix of data

shall be A.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Max. code length

00-64

12

Program

88

Code-16K (for 8250/8312)

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< >

Program

92

EAN UCC Composite (for 8312)

For the coupon extended code application. Coupon extended

code is a supplementary barcode that is printed to the right of

the UPC/EAN in UCC/EAN-128 symbology.

Option Bar Code Option Alphanumeric

Entry

*YAA*

Read

Disable

Enable

00

01

*YAD*

Max. code length

00-64

64

*YAE*

Min. code length

00-64

01

*YAF*

Truncate leading

0-15 00-15

00

*YAG*

Truncate ending

0-15 00-15

00

Program

93

Exit

*YAH*

Code ID setting

00-ffH

ASCII code

00-ffH

< RC >

*YAI*

Insert group number

selection

00-44 00-44

00

*YAK*

UCC / EAN128

emulation

Disable

Enable

00

01

94

RSS-14

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

UCC/EAN 128 emulation: Refer to Transmission, Code ID

transmission must be set as AIM ID enable. Then ]C1 will be

identified as prefix of barcode data transmission.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Program

95

Exit

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Code ID setting

00-ffH ASCII

code

00-ffH

< R4 >

Insert group number

selection

00-44 00-44

00

UCC/EAN128

emulation

Disable

Enable

00

01

96

RSS-Limited

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

UCC/EAN 128 emulation: Refer to UCC/EAN 128 emulation

of RSS-14.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Truncate leading

0-15 00-15

00

Truncate ending

0-15 00-15

00

Program

97

Exit

Code ID setting

00-ffH ASCII

code

00-ffH

< RL >

Insert group number

selection

00-44 00-44

00

UCC/EAN128

emulation

Disable

Enable

00

01

98

RSS-Expanded

Read: Format

Data Digits

(Variable)

Checksum1

(Optional)

Max./Min. code length: Refer to Max./Min. code length of

Code-39.

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

UCC/EAN 128 emulation: Refer to UCC/EAN 128 emulation

of RSS-14.

Option Bar Code Option Alphanumeric

Entry

Read

Disable

Enable

00

01

Max. code length

00-99 00-99

99

Program

100

Micro-PDF (for 8312)

Truncate leading/ending: Refer to Truncate leading/ending

of UPCA.

Code ID setting: Refer to Code ID setting of UPCA.

Insertion group number selection: Refer to page 36

Insertion group number selection of UPCA.

Option Bar Code Option Alphanumeric

Entry

*XAA*

Read

Disable

Enable

00

01

*XAF*

Truncate leading

0-15 00-15

00

*XAG*

Truncate ending

0-15 00-15

00

*XAH*

Code ID setting

00-ffH ASCII

code

00-ffH

< >

Program

Mærke:	Argox
Kategori:	Stregkodelæser
Model:	AS-8310

Argox AS-8310 Manual

Produkt Specifikationer

Har du brug for hjælp?

Stregkodelæser Argox Manualer

Stregkodelæser Manualer

Nyeste Stregkodelæser Manualer
