Side 1/2
1
WP-8000C
User Manual
1. Descriptions
2. Front panel & rear panel
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference
Check our website for any updates of this manual: www.artsound.be
with MAT-8000, which will be used as a remote source
selector and volume. The remote control panel is de-
signed with LED to provide direct display of the selected
sources, the up and down button will be used to increase
or decrease the source input channel. A ten levels
volume control is provided over the sources.
The communication between the panel and the matrix is
through universal industrial standard CAT5 cable, which
also is used to supply power from the matrix to this panel
panels could work together with the matrix.
1. SOURCE CHANNEL LED
The LED in background will display the source channel
1 to 8 as 01 to 08 and local input as L.
2. LABEL
The label could be end user-printed as guidance over
sources.
3. SOURCE LEVEL
Ten levels volume control over selected source output,
clockwise adjustment to increase the volume from low
to high level.
4. SOURCE UP & SOURCE DOWN
The two buttons are used to increase or decrease
5. the input sources channel from 1 to 8 and local input.
6. JTAG CONNECTOR
Connector for reprogramming.
7. SPARE 24V DC INPUT
Extra DC 24V will be needed to power supply the
remote control panel when the communication
distance is longer than 50 meters.
8. RJ45 COMMUNICATION PORT
The RJ45 port is used to communicate between the
remote control panel and the matrix, it also will be
used to power supply the panel within 50 meters.
1
4
2
3
5
6
7
WP-8000C
5. Specifi cations
Communication Speed 57600 bps
Communication Distance ≤ 1 km
Power Supply DC 24 V
Weight 73 g
Dimensions mm (w x d x h) 86 x 86 x 33
3. Connection & wiring
4. Operation
1. THE RJ45 PORT is used to communicate between
the remote control panel and the matrix. It can be
connected with network power supply in 50 meters
distance; If the connecting distance is over 50 me-
ters, they should be connected with external DC 24V
or there will be noise. The communication cable shall
be universal industrial CAT5 cable.
2. SPARE DC24V INPUT
3. RJ45 COMMUNICATION PORT
1. POWER SUPPLY.
The remote control panel will be power on whether
there is DC24V from the matrix or extra equipments.
The power indicator will be light on blue, which is also
used as status indicator to display if communication is
well or not.
2. SOURCE SELECTION.
Total 9 sources include line 1-8 and local input could
be selected on the panel through up and down but-
tons. The selected source will be displayed on the
LED.
3. VOLUME CONTROL.
A ten levels volume control is provided for the local
line input.
Discover the complete ArtSound
range at www.artsound.be
TM
Art_Sound
House Of Music NV
Kruishoutem, Belgium
www.artsound.be
Tel. +32 9 380 81 80
Fax. +32 9 386 12 35
info@artsound.be
1
GND +24V2
2
485-B 1
485-A 2
RE_D 3
GND 4
24V1 5
24V1 6
NC 7
NC 8
