Side 1/15
Aruba 303H Series Hospitality Access Points
Installation Guide
AP-303H-IG-01 | September 2017 1
The Aruba 303H Series access point is a high-performance dual-radio wireless device for hospitality and branch
deployments.
This access point use Multiple-Input, Multiple-Output (MIMO) technology to provide secure wireless connectivity
for both 2.4GHz 802.11 b/g/n and 5GHz 802.11 a/n/ac WiFi.
Alternatively, the wired Ethernet ports located on the bottom of the device allow users to connect to the device
directly when linked by an Ethernet cable.
The 303H Series access point can be attached to a standard single-gang wall box using the mount provided, or
converted into a desk-mounted remote access point for branch office deployments using the AP-303H-MNTD
mount kit (sold separately).
The 303H Series access point provides the following capabilities:
IEEE 802.11a/b/g/n/ac operation as a wireless access point
IEEE 802.11a/b/g/n/ac operation as a wireless air monitor
Compatibility with IEEE 802.3af/at PoE
Central management configuration
Supports PoE-in (E0 port)/PoE-out (E3 port)
Support for selected USB peripherals
Integrated Bluetooth Low Energy (BLE) radio
Package Contents
303H Series Access Point
Single gang wall-box mounting bracket
(2x) #6-32 slotted screws
T8H Torx security screw
Hardware Overview
The following sections outline the hardware components of the 303H Series access point.
Figure 1 303H Series (front view)
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible,
retain the carton, including
the original packing materials. Use these materials to repack and return the unit to the supplier if needed.
PoE-PSE Status
Radio Status
System Status
2Aruba 303H Series Hospitality Access Points | Installation Guide
LED
The LED displays located on the front and bottom of the access point indicate the following functions:
System Status
The System Status LED indicates the operating condition of the access point. See Table 1.
Table 1 System Status LED
1 blinking: 1s on/1s off
2 flashing: on/off repeated in less than 1s
Radio Status
The Radio Status LED indicates the operating mode of the access point’s radios. See Table 2.
Table 2 Radio Status LED
Color/State Meaning
Off Device is powered off
Green/solid Device is ready; fully functional
Green/blinking1Device is booting; not ready
Green/flashing2Device is ready; uplink negotiated at suboptimal speed (<1Gbps)
Amber/solid Device is ready; operating in power-save mode (PoE source: 802.3af)
Amber/flashing Device is ready; operating in power-save mode, with uplink negotiated at
suboptimal speed (<1Gbps)
Red/solid Error condition
Color/State Meaning
Off Meets one of the following conditions:
both radios are disabled
device is powered off
Green/solid Both radios enabled in access mode
Green/blinking1One radio enabled in access mode; one radio
disabled
Amber/solid Both radios enabled in monitor mode
Amber/blinking One radio enabled in monitor mode, other disabled
Alternating3One radio in access mode, other radio in monitor mode
