AWM-LTH Page 1 of 2

Installation Guide

AWM-LTH

Heavy Duty VESA Tilt Head

COMPONENT CHECKLIST

IMPORTANT INFORMATION

! Please ensure this product is installed as per these installation instructions.

! Curvedmonitors,deepdevices(suchasall-in-onePCs)andosetVESAlocationsexertadditionalleveragethatcanexceedthe

capacityofthemounteventhoughthemonitorweightmaybewithinthestatedrange.

! Themanufactureracceptsnoresponsibilityforincorrectinstallation.

! ThisproductiscompatiblewithAWMSeriesmonitorarmproducts.

Monitorweightshouldbe

withintheweightrangeof

all modular elements that

make up the complete

monitormountingsolution.

REQUIRED TOOLS

• Phillips Head Screwdriver

Heavy Duty

Tilt Head

(x1)

Screw

M4x25mm

(x4)

Screw

M4x16mm

(x4)

Screw

M4x12mm

(x4)

Spacer

(x4)

4mm

allen key

(x1)

WEIGHT RANGE

0 - 18kg

(0 - 40 )lb

AWM-LTH Page 2 of 2

atdec.com | atdec.co.uk | atdec.com.au

No portion of this document or any artwork contained herein should be reproduced in any way without

the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer

1. Attach VESA head to monitor

1.2Ensuresuitablescrewsizeisused. VESAmountingcompatibility1.3

Note: Forothersizes,useasuitable

adaptor plate

1.1ScrewtheVESAheadontomonitor

Note:Spacersmayberequiredfor

curved, recessed or uneven monitor

surfaces.

2. Mount monitor onto arm

3.1Usetheknobtotightenandloosenthe

tilttensiontosuityourmonitorweight.

Note:Alwayssupportthemonitor

whilstadjustingtopreventitfrom

fallingforwardsharply.

Tighten

Loosen

2.1 Push tilt head onto the shaft at the

endofthemonitorarm.

2.3 Tightenthejointscrewtosecure

thetiltheadandmonitorinplace.

3. Adjust tilt tension

Flush

Too long Too short

Spacer

5mm 12mm

Note: Check the arm rotation

issmoothaftertightening.

2.2Ensuretiltheadisfullypushed

ontoshaft.

100mm

75mm

100mm

75mm
