)NSTALLATION'UIDE

ProSafe 10 Gigabit Ethernet SFP+ Module AXM761

Install Your Optical Module

The 10 Gigabit small form-factor pluggable (SFP+) module provides a full-duplex 10G bps

each direction for Ethernet operation on NETGEAR managed switches.

The switch will automatically detect the AXM761, so you can simply plug it into an

available module slot.

The module can be inserted or removed while the switch is operational.

AXM761

Installing a AXM761 Module

Insert the module firmly into the slot that supports the SFP+ interface. Make sure the optical

cable you use is multi mode LC to LC duplex cable.

Removing a AXM761 Module

Release the module latch by pulling down the handle bar across the module, and pull the

module out of the module slot.

Technical Specifications

Standards IEEE 802.3ae 10GBase-SR

Wavelength 850nm

Dimensions (HxWxD) 0.46” x 0.53” x 2.19”

(11.9 mm x 13.7 mm x 55.7 mm)

Weight 17.1g

Operating Temperature 32 -158º F (0 - 70ºC)

Storage Temperature 32 -185 ºF (0 - 85ºC)

Operative relative humidity 85% @ (25ºC)

Operating Distance 2 - 300 m for 50/125 um MMF

2 - 33 m for 62.5/125 um MMF

Connectors LC

Power Consumption <1.0w

MTBF 4,986,536 hr (569 years)

Safety Certification UL 1950 CSA 22.2 No. 950

Environmental Compliance -RoHS

AXM761_IG_10July09.fm Page 1 Friday, July 10, 2009 2:36 PM

July 2009

This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste

Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European Union,

this product should be treated and recycled in accordance with the laws of your jurisdiction implementing

the WEEE Directive.

NETGEAR, Inc. in the United States and/or other countries. Other brand and product names are trademarks or

registered trademarks of their respective holders. Information is subject to change without notice.

Technical Support

Thank you for selecting NETGEAR products.

After installing your device, locate the serial number on the label of your product and use it

to register your product at . Registration is required http://www.NETGEAR.com/register

before you can use our telephone support service. Registration via our web site is strongly

recommended.

Go to for product updates and Web supporthttp://kbserver.netgear.com . For Warranty and

Regional Customer Support information, see the that came with your Warranty Card

product.

Regulatory Compliance

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability,

NETGEAR reserves the right to change the product described in this document without

notice. NETGEAR does not assume any liability that may accrue due to the use or

application of the product(s) or circuit layout(s) described herein.

Certificate of Manufacture/Importer

It is hereby certified the NETGEAR model AXM761 has been suppressed in accordance

with the condition set out in MBPT-Amtsb|Vfg 243/1991 and vfg 46/1992. The operation of

some equipment (for example, test transmitters) in accordance with regulation may,

however, be subject to certain restrictions. Please refer to the note in the operating

instructions. Federal Office for Telecommunications Approvals has been notified of the

placing of this equipment on the market and has been granted the right to test the series for

compliance with regulation.

Note: This device has been tested and found to comply with limits for a Class B digital

device, pursuant to part 15 of FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a commercial installation.

Laser Safety Warning

This is a Class 1 laser product.

Warning: Because invisible laser radiation may be emitted from aperture of the port when

no fiber cable is connected, avoid exposure to laser radiation and do not stare into

the open aperture.

AXM761_IG_10July09.fm Page 2 Friday, July 10, 2009 2:36 PM
