AT33EV

Elliptical 1/2 inch Standard Mount Cartridge

The original model of this stereo cartridge is the AT33ANV, which was available

as a special release to celebrate our 45th anniversary. The A33ANV was the

first in the AN33 series to feature a Duralumin cantilever, which received wide

acclaim for its sound quality.

Retaining the basic specification, we present a further improved and evolved

model.

The A33EV is a ½ inch, standard mount 0.3 x 0.7 mm elliptical cartridge

featuring a tapered Duralumin cantilever which reduces the effective mass of

the cartridge, resulting in a more durable cantilever. The Dual Moving Coil

cartridge design increases channel separation and extends the frequency

response range delivering extraordinary audio quality. Internally constructed

with a neodymium magnet enhances magnetic energy and PCOCC wire for

pure audio transmission.

• Elliptical stylus chip and durable duralumin tapered pipe cantilever.

• 10Ωmid impedance specifications.

• Dramatically increased magnetism with neodymium magnets and PCOCC as

the coil.

• High separation, wide-response dual moving coil.

• VC Mold eliminates unnecessary vibrations.

• “Hanenite” anti-vibration rubber eliminates unwanted vibrations.

RRP ex VAT 499,00 €

RRP inc. VAT £529.00

Ean code: T4961310103972

Specifications*:

Type: MC-type

Playback frequency range: 15-50,000Hz

Output voltage: 0.3mV (1kHz and 3.54cm/sec.)

Channel separation: 30dB (1kHz)

Output balance: 0.5dB (1kHz)

Stylus pressure: 1.8-2.2g (2.0g standard)

Coil impedance: 10 Ω(1kHz)

DC resistance: 10 Ω

Load resistance: More than 100 Ω(when head amp connected)

Coil inductance: 22µH (1kHz)

Static compliance: 40×10-6cm/dyne

Dynamic compliance: 10×10-6cm/dyne (100Hz)

Stylus needle shape: oval (0.3×0.7mil)

Cantilever: Duralumin tapered pipe

Vertical tracking angle: 23°

Dimensions: H16×W16.6×D26.5mm

Weight: 6.9g

Accessories: Non-magnetic screwdriver × 1, Washer × 2, Protector × 1,

Cartridge installation screws 13 mm × 2 and 19 mm × 2,

Nut × 2, Brush × 1, PCOCC lead set × 1

* Specifications are subject to change without notice.

PCOCC = Pure Copper by Ohno Continuous Casting process
