Side 1/16

page 1

tm tm

Greetings from the rainforests of the Paciﬁc Northwest. We would

like to congratulate you on your purchase of the LC6i; a six-chan-

nel, high-performance, line-output converter. This unique product will

accept two, four, or six channels of speaker-level signal from a factory-

installed ampliﬁer or source unit and convert it to a high-quality, low-

noise pre-amp signal. Therefore the LC6i is an ideal OEM (Original

Equipment Manufacturer) interface component as it will allow you to use

your factory-installed source unit but give you the ability to add really

good aftermarket ampliﬁer(s) and processor(s). Whether this is your ﬁrst

product from the rainforest dwellers of AudioControl, or you are already

a ﬁrm believer, you will deﬁnitely enjoy how great the LC6i can make

your performance system sound.

Now before you start salivating just thinking about the beneﬁts and all

of the nifty applications for your LC6i, take a few minutes to sit back,

have a cold beverage, and read through this manual. We always love to

get calls from our customers, but have tried to answer all of your ques-

tions in this manual so it contains lots of useful facts and information

- - and besides, we spent a lot of time writing it!

Here are some of the cool features that your LC6i offers:

• Six input and output channels

• Speaker-level inputs – can accept 400-watt signals!

• Internal channel summing

• GTO™ - signal-sensing inputs

• Level matching controls

• 12 volt trigger output

• Input for optional subwoofer level control

• Cardboard box for easy storage

TMmaking good sound betterTM

22410 70th Avenue West • Mountlake Terrace, WA 98043

Phone 425-775-8461 • Fax 425-778-3166 • www.audiocontrol.com

page 2

If you are like many people who enjoy the look and features of your

factory-installed source unit but feel your system overall is lacking pow-

er bass, we have good news. The LC6i has high-impedance speaker-and

level inputs that allow it to accept ampliﬁed signals from all known fac-

tory-installed source units (even Bose) and output a high-quality pre-amp

signal via standard RCA connectors. This will allow you to add

better-quality aftermarket ampliﬁers, processors and speakers while

keeping the convenience features of your factory-installed source unit.

Unlike inexpensive speaker-level and line-output converters, the LC6i

offers the highest sound quality and can handle the full signal strength of

a 400-watt ampliﬁer.

Most factory-installed source units lack the features that make it easy

to upgrade with really good-sounding, performance aftermarket products.

One of those key features is a 12-volt trigger that will turn on devices

like the LC6i and your external ampliﬁers. Therefore, we have equipped

your LC6i with our unique GTO™ (Great Turn On) signal-sensing in-

puts. Once the GTO input of your LC6i detects a speaker-level signal on

the Main Inputs, it powers up. When the speaker-level signal goes away,

your LC6i will automatically turn-off. Optionally, your LC6i is also

equipped with a standard 12-volt trigger (Remote In) that will allow you

to turn on your LC6i in the traditional manner.

Since you will be using an external ampliﬁer(s) and processor in your

system, you will need the ability to “trigger” or turn-on these devices (a

romantic dinner won’t quite work here). Your LC6i has a high-current

12-volt output (labeled Remote Out) that will provide a trigger to these

remote devices, when the LC6i is powered up. Please note that this out-

put is not to be used as the main power for these devices.

The LC6i has the unique ability to internally sum together multiple (4

or 6) input channels from the factory source unit into 2 channels. This

is particularly handy when using the LC6i with a factory system that has

multiple, actively crossed-over signals being sent from the OEM source

unit or ampliﬁer(s). For example, in some vehicles there is an actively

crossed-over tweeter, midrange, and woofer all in the front of the ve-

hicle. The LC6i lets you take all of those signals and sum them together

to get a high-quality, full-range, pre-amp signal without the use of any

additional cables or hardware.
