OWNER’S MANUAL

AMP 100

AudioSource®

13970 SW 72nd Ave

Portland, OR 97223

503.914.4688

w.audiosource.net

AMP 100 Owner

’s Manual

Congratulations on your purchase of the AudioSource® AMP 100.

Please take a few moments to read this entire manual, and be sure to

retain this document for future reference. Please read and observe all

safety instructions detailed on page 2.

NOTE: If any part of this product is damaged or missing, please call your

dealer or AudioSource® directly at 1.877.715.5439 or 503.914.4688.

Please read your warranty and retain your receipt and original carton

for possible future use.

For more information about AudioSource® electronics, speakers and

accessories please visit www.audiosource.net

AMP 100

Home Audio Multi-Zone Stereo Power Ampliﬁer

FEATURES:

Line 1 / Line 2 priority input switching

Line 2 auxiliary output

Speaker A/B switching

Front panel Balance and Volume controls

Signal sensing “Power On”

SPECIFICATIONS

Stereo (8 ohm): 50W per channel, 20Hz ~ 20kHz, <1% THD+N

60W per channel, 1kHz, <1% THD+N

Stereo (4 ohm): 60W per channel, 20Hz ~ 20kHz, <1% THD+N

75W per channel, 1kHz, <1% THD+N

Bridged Mono (8 ohm): 160W, 1kHz, <1% THD+N

Frequency Response: 10Hz ~ 30kHz, +0dB/ -3dB

Signal to Noise Ratio: 100dBA below 50W output into 8 ohms

Channel Separation: 65dB @ 1kHz, referred to 50W output

into 8 ohms

Input Sensitivity: 900mV input for rated 50W output

into 8 ohms

AC Power Consumption: 500W maximum

Net Weight: 9.6lbs / 4.4kgs

Gross Weight: 10.8lbs / 4.9kgs

2.9”

(74mm)

16.5” (419mm)

9.5”

(242mm)

Left

Right

Balance

Volume

SPEAKERS

A B

AMP 100

STEREO POWER AMPLIFIER

Min

Max

POWER

AMP 100

OWNER’S MANUAL

13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net

CAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER. NO

USER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL!

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. The ventilation should not be impeded

by covering the ventilation openings with items such as newspaper, table-

cloths, curtains etc. Install in accordance with the manufacturer’s instructions.

8. Do not install near heat sources such as radiators, heat registers, stoves,

or other apparatus (including amplifiers) that produce heat. No open flame

sources, such as lighted candles, should be placed on the apparatus.

9. Do not defeat the safety purpose of the polarized or grounding type plug.

A polarized plug has two blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong. The wide blade or

third prong is provided for your safety. If the provided plug does not fit into

your outlet, consult an electrician for replacement of the obsolete outlet.

MAGNETIC FIELD: !!CAUTION!! Do not locate sensitive high-gain equipment such as preampliﬁers or tape decks directly above or below the unit. Because

this ampliﬁer has a high power density, it has a strong magnetic ﬁeld, which can induce hum into unshielded devices that are located nearby. The ﬁeld is

strongest just above and below the unit. If an equipment rack is used, we recommend locating the ampliﬁer(s) in the bottom of the rack and the preampliﬁer

or other sensitive equipment at the top.

EXPLANATION OF

SAFETY SYMBOLS

The exclamation point within an equilateral triangle is intended to alert the user of the presence of important

operating and maintenance (servicing) instructions in the literature accompanying the appliance.

The lightning ﬂash with the arrowhead symbol within an equilateral triangle is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the products’ enclosure that may be of sufﬁcient magnitude

to constitute a risk of electric shock to persons.

10. Protect the power cord from being walked on or pinched particularly at the

plugs, convenience receptacles, and at the point of exit from the apparatus.

11. Unplug the apparatus during lightning storms or when unused for long

periods of time.

12. Refer all servicing to qualified personnel. Servicing is required when the

apparatus has been damaged in any way, such as when the power supply

cord or plug is damaged, liquid has been spilled or objects have fallen into

the apparatus, the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

13. The apparatus should be connected to a mains socket outlet with a protective

earthing connection.

• WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THE APPARATUS SHALL NOT

BE EXPOSED

TO DRIPPING OR SPLASHING AND THAT OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL NOT BE PLACED

ON AP

PARATUS.

• WARNING: TO PREVENT FIRE OF SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET

UNLESS THE BLADES CAN BE FUL

LY INSERTED TO PREVENT BLADE EXPOSURE.

•

WARNING: THE MAINS PLUG IS USED AS DISCONNECT DEVICE. THE DISCONNECT DEVICE SHALL REMAIN READILY AVAILABLE.

•

WARNING: ONLY USE ATTACHMENTS OR ACCESSORIES SPECIFIED OR PROVIDED BY THE MANUFACTURER.

Produkt Specifikationer

Mærke:	AudioSource
Kategori:	Modtager
Model:	AMP 100
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	117 V
Vekselstrømsindgangsfrekvens:	60 Hz
Bredde:	419 mm
Dybde:	242 mm
Højde:	74 mm
Vægt:	4400 g
Produktfarve:	Sort
Pakkevægt:	4900 g
Strømforbrug (typisk):	500 W
Volumenkontrol:	Dreje
Linie-udgang (RCA):	1
Frekvensområde:	20 - 20000 Hz
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	2.0 kanaler
Formål:	Hjem
klirfaktor (THD):	1 %
Signal/støjforhold:	100 dB
Forstærker klasse:	A/B
Spidseffekt pr. kanal:	- W
Højttalere tilslutningstype:	Fortøjningsstolpe
RMS udgangseffekt pr. kanal (4 Ohm):	60 W
Linie indgående (RCA):	2
RMS udgangseffekt pr. kanal (8 ohm):	50 W
Mulighed for flere oner:	Ja
Bridge-mode effekt pr. kanal (8 ohm):	160 W
