FireBall™

OVERVIEW:

Designed, machined, assembled and tested by Audix in the USA, the

FireBall™ is a professional dynamic instrument microphone intended

for harmonica (both diatonic and chromatic) and beatbox. Clear,

accurate and capable of handling sound pressure levels in excess of

140 dB without distortion, the FireBall™ is ideally suited for both live

stage and studio recording applications.

The FireBall™ is characterized with a cardioid pickup pattern for

isolation and feedback control and is equipped with a VLM™ (Very

Low Mass) diaphragm for natural sound reproduction with exceptional

transient response.

With a smooth, uniform frequency response of 50 Hz - 16 kHz,

the FireBall™ is lightweight, compact, and comfortable to hold.

Roadworthy construction includes a precision machined aluminum

body, steel mesh grill, unique three stage marbled anodized nish,

laser etched model and serial number, Switchcraft® XLR connector

and heavy duty nylon clip.

The FireBall™ is a low impedance microphone; when using the

FireBall™ with a guitar amplier, a high quality low-high impedance

transformer (such as T50K) is required.

APPLICATIONS:

Live stage, studio

Harmonica

Vocals

Beatbox

Percussion

Saxophone, trumpet, trombone

Flute

Accordian

SUPPLIED ACCESSORIES:

Heavy duty press fit mic clip (DCLIP)

Carrying pouch (P1)

OPTIONAL ACCESSORIES:

WS357 - External foam windscreen

DVICE - Spring loaded rim mount clamp

DCLAMP - Tension rod mic clamp

CBL-20 - 20’ XLR-XLR mic cable

CBL-DR25 - 25’ right angle XLR mic cable

CBL-BP360 - 4’ adapter cable for RAD360 Wireless Bodypack

T50K- High quality low-high impedance transformer

DYNAMIC INSTRUMENT MICROPHONE

FIREBALL

Dynamic Instrument

FIREBALL W/ CBL-BP360 DCLAMP WS357 CBL-20 T50K

FEATURES:

Fits comfortably in the palm of the hand

Handles “cupping” without impacting sound quality

Full size dynamic capsule

Clear and accurate sound reproduction

High SPL handling without distortion

Exceptional gain before feedback

Provides excellent isolation from other instruments

on stage

Precision machined aluminum body

5 year warranty

Transducer Type Dynamic Moving Coil

Frequency Response 50 Hz - 16 kHz

Polar Pattern Cardioid

Output Impedance 150 ohms

Sensitivity 1.5 mV / Pa @ 1k

Capsule Technology VLM Type B

Off Axis Rejection > 23 dB

Maximum SPL ≥140 dB

Power Requirements None

Connector Switchcraft® male

XLR connector

Polarity Positive pressure on diaphragm

produces positive voltage on pin 2

relative to pin 3 of output

XLR connector

Housing / Finish Machined Aluminum /

Anodized

Weight 128 g / 4.5 ounces

Length 77.5 mm / 3.05 inches

SPECIFICATIONS: ARCHITECTS AND ENGINEERS SPECIFICATIONS:

The microphone shall be of the dynamic type operating on the moving coil principle and the polar

pattern of the microphone shall be cardioid. The capsule shall be VLM Type B. The nominal

output impedance shall be equal to 150 ohms at 1 kHz. The microphone shall have a sensitivity of

1.5 mV / Pa at 1 kHz and a sound pressure level ≥140 dB. The microphone body shall machined

of aluminum and the grill be of steel mesh. The overall dimensions shall be 21.5 mm in diameter

at the base, 53.5 mm at the widest point on the grill, and 77.5 mm in length. The microphone shall

be the Audix FireBall™.

www.audixusa.com Call: 503-682-6933 Fax: 503-682-7114

Audix Corporation 9400 SW Barber Street, Wilsonville, OR 97070

SERVICE AND WARRANTY:

This microphone is under warranty for

a period of 5 years from any and all

manufacturing defects. Should your

microphone fail in any way, please

contact the Audix Service department at

503-682-6933. A Return Authorization

number is required before returning

any products.

CARE AND MAINTENANCE:

The Fireball™ is manufactured to exacting

specs with roadworthy construction. However,

the capsule is highly sensitive and should be

handled with care. Avoid extreme temperatures

and be sure to store your microphone in the

pouch provided when not in use. Moisture of

any kind can adversely affect the sound and

performance of your microphone.

OPERATION:

The Fireball™ is a low impedance microphone and should be plugged into a “mic level” input

on your console, mixer, or recording device. Please note that your microphone does not require

phantom power and will not be effected in any way by phantom power should it be running

simultaneously while the microphone is in operation. Avoid plugging or unplugging the microphone

from the PA system unless the channel is muted or the volume of the system turned down.Failure

to do so may result in a loud “popping” noise which could seriously damage the speakers in the

PA system.

USER TIPS:

The FireBall™ has a tight (cardioid) pick-up pattern in order to help eliminate sound from other

instruments on stage from “bleeding” into the microphone.

The FireBall™ is a low impedance microphone, however, it may be plugged directly into a guitar

amp by using the Audix T50k impedance converter. This will allow for the proper gain structure

and will insure the best possible sound quality.

The FireBall may also be used for a wide variety of instrument and vocal applications. Working

distance can be anywhere between 1-6 inches depending on the instruments on stage, the

volume of the music, and the type of stage monitors.

Allow a distance of 2-3 feet between microphones to avoid phase cancellation issues.

*Further miking techiques may be found on our website at www.audixusa.com

FREQUENCY / POLARS:

***All specications subject to change without notice.

To register your

microphone, please visit

www.audixusa.com

DIMENSIONS (mm):

FIREBALL™
