Side 1/86

AI Auto Tracking PTZ Camera

PTC310/ PTC310H /PTC310U

PTC330/ PTC330U

*NDI model:PTC310N/PTC310UN/PTC330N

User Manual

FCC NOTICE (Class A)

This device complies with Part 15 of the FCC Rules. The operation is subject to

the following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

NOTE- This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates

uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of

the following measures:

 Reorient or relocate the receiving antenna.

 Increase the separation between the equipment and receiver.

 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

 Consult the dealer or an experienced radio/television technician for help.

Class A ITE

Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B

ITE limits. Such equipment should not be restricted in its sale but the following warning shall be

included in the instructions for use:

Warning - This is a class A product. In a domestic environment, this product may cause radio

interference in which case the user may be required to take adequate measures.

European Community Compliance Statement (Class A)

This product is herewith confirmed to comply with the requirements set out in the

Council Directives on the Approximation of the laws of the Member States

relating to Electromagnetic Compatibility Directive 2014/30/EU.

Warning - This is a Class A product. In a domestic environment, this product may cause radio

interference in which case the user may be required to take adequate measures to correct this

interference.

Produkt Specifikationer

Mærke:	AVer
Kategori:	Videokonferencesystem
Model:	PTC310H
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	180 mm
Dybde:	145 mm
Højde:	183.5 mm
Vægt:	1700 g
Produktfarve:	Sort
HD-type:	4K Ultra HD
Understøttede videotilstande:	720p, 1080i, 1080p, 2160p
Opbevaringstemperatur (T-T):	20 - 80 °C
Relativ luftfugtighed ved drift (H-H):	-20 - 60 %
Relativ luftfugtighed ved opbevaring (H-H):	20 - 95 %
Antal HDMI-porte:	1
Understøttede videoformater:	H.264, H.265
Strømforbrug (typisk):	18 W
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Kabler inkluderet:	RS-232
DC-in-stik:	Ja
Understøttede netværksprotokoller:	IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
Webbaseret administration:	Ja
Strømkilde type:	AC, PoE
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	85258900
Mikrofonindgang:	Ja
Slot til kabellås:	Ja
Understøttede Windows-operativsystemer:	Windows 10, Windows 7, Windows 8, Windows 8.1
Hvidbalance:	Auto, Manual
Megapixel:	8 MP
Sensortype:	CMOS
Maksimal videoopløsning:	- pixel
Opløsning ved indfangningshastighed:	1280x720@50fps, 1280x720@60fps, 1920x1080@25fps, 1920x1080@29.97fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@59.94fps, 1920x1080@60fps, 3840x2160@25fps, 3840x2160@29.97fps, 3840x2160@30fps
Støjreduktion:	Ja
Optisk zoom:	12 x
Digital zoom:	12 x
Hurtigste hastighed for kameralukker:	1/3200 sek./side
DC indgangsspænding:	12 V
Skærm spejling:	Ja
Maksimum billedhastighed:	30 fps
Indgangsstrøm:	5 A
Driftsspænding:	12 V
Hældningsvinkelområde:	-30 - 90 °
Kabellåseslids type:	Kensington
Minimumsbelysning:	0.4 Lux
Panoreringsområde:	170 - 170 °
Optisk sensorstørrelse:	1/2.8 "
Forstærkningskontroltype:	Auto/manuel
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte:	1
Brændviddeområde:	3.9 - 46.8 mm
Signal/støjforhold:	50 dB
Line-in:	Ja
Fjernbetjeningstype:	IR
Fjernbetjening funktion:	Ja
Monteringsbeslag inkluderet:	Ja
Power over Ethernet plus (PoE+) porte, antal:	1
Blændeområde (F-F):	1.6 - 2.8
RS-232-porte:	1
PTZ-kontrol:	Ja
Auto eksponering:	Ja
Skruer inkluderet:	Ja
Antal TV-linier:	1400
RS-422-porte:	1
USB Type-C stik:	Ja
Lyd codec:	AAC-LC (48 / 44.1 / 32 / 24K), G.711, PCM (8K)
Understøttede stikprøver:	48 kHz
Netværksstreaming:	Ja
PTZ-protokoller:	Pelco-P/D, VISCA
Auto-sporing:	Ja
3D NR (støjreduktion):	Ja
Forudindstillet hastighed:	200 grader i sekundet
Bitrate kontrol:	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Tilt forudindstillet hastighed:	200 grader i sekundet
Vippehastighed (min.):	0.1 grader i sekundet
Vippehastighed (maks.):	100 grader i sekundet
Paneringshastighed (min.):	0.1 grader i sekundet
Paneringshastighed (maks.):	100 grader i sekundet
Horisontalt visningsområde (bred):	70 °
Horisontalt visningsområde (tele):	6 °
Antal skruer:	10
Kabelbånd inkluderet:	Ja
Lyd kanaler:	2
Driftsstrøm:	5 A
Interval for bithastighed:	512 - 32000 Kbit/s
Minimum arbejdsafstand (bred):	300 mm
Antal kabelstrips:	5
Lodret synsfelt (tele):	3 °
Lodret synsfelt (bredt):	42 °
Maksimum arbejdsafstand (tele):	1500 mm
Sporingstilstande:	Presenter mode, Zone mode
Multi-stream kapacitet:	2 (RTSP / Web Page), 1080p 60fps (max.)
Sensor zoom:	2 x
Tally-lys:	Ja
Livevideo forhåndsvisning:	Ja
Netværkskonfiguration:	DHCP, IP Address, Gateway, Subnet Mask, DNS
Antal kabelfastgørelsesplader:	2
