Side 1/16

Attention! With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections are secure before

cycling the ignition to test this product.

I N S TA L L AT I O N I N S T R U C T I O N S

99-5848CH

KIT FEATURES

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Touchscreen display for climate and personalization features

• Included interface for climate and steering wheel functions

• Integrated hazard button and passenger airbag indicator

• Painted Charcoal

KIT COMPONENTS

• A) Radio/Display trim panel with touchscreen display • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws for pocket • E) (2) Panel Clips

• F) Antenna adapter (not shown)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 9/32” Socket wrench

TABLE OF CONTENTS

Dash Disassembly ...............................................2-3

Kit Assembly

–ISO DIN radio provision with pocket ..................4

–ISO DDIN radio provision .....................................4

Axxess Interface Installation ............................5-14

Final Assembly .......................................................9

WIRING & ANTENNA CONNECTIONS
