ASWC-1 GENERAL INSTRUCTIONS

I N S TA L L AT I O N I N S T R U C T I O N S

Attention! Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Installation Preparation ........................................2

Installation .............................................................2

Programming .........................................................3

Wire Description ....................................................3

ASWC-1 General Instructions

• One interface does it all, no

additional interfaces needed

• Designed to be compatible

with all major radio brands

•

Auto detects vehicle type, radio

connection, and preset controls

• Ability to dual assign steering

wheel control buttons

• Can be manually programmed

for most vehicles

• Retains settings even after

battery disconnection or

interface removal

• All connections done at the

radio location

• Micro-B USB updatable

• ASWC-1 Interface

• ASWC-1 harness (12-pin harness with male 3.5mm jack)

• Female 3.5mm connector with stripped leads

Visit AxxessInterfaces.com for more detailed information about the product and up-to-date

vehicle speciﬁc applications

INSTALLATION PREPARATION INSTALLATION (CONT.)

From axxessinterfaces.com, submit the vehicle information in the box titled Vehicle Fit Guide &

ASWC-1 Install Instructions GET PARTS, then select . This will take you to a page where you will be

notiﬁed if your vehicle will work or not with the ASWC-1 interface. If the interface is compatible,

there will be a link under the green bar titled ASWC-1 **** Wiring Instructions. Click on this link

to open the PDF document for your speciﬁc vehicle. Print this document to have with you in the

vehicle during the installation.

Note: Though we have done extensive research, testing, and verifying that the steering wheel

control wires from the vehicles listed are correct, it is still the Installer’s responsibility to verify

that the steering wheel control wires are truly correct. If a discrepancy is found, please notify our

Tech Department at 1-800-253-TECH, or techsupport@metra-autosound.com.

12-pin harness:

• Connect the wire to chassis ground.Black

• Connect the wire to the accessory power.Red

• Locate the steering wheel control wire(s) in the vehicles harness as noted in the ASWC-1

vehicle speciﬁc document. Connect this wire(s) to the ASWC-1.

Note: Axxess recommends that the wires are soldered for the best “copper-to copper”

connection. Tapping style connectors are not recommended.

3.5mm jack:

•

For the radios listed below:

Connect the

female 3.5mm connector with stripped leads

, to the male

3.5mm SWC jack from the

ASWC-1 harness

Any remaining wires tape off and disregard

• Eclipse: Connect the steering wheel control wire, normally Brown Brown/White, to the

wire from the connector. Then connect the remaining steering wheel control wire,

normally , to the wire from the connector.Brown/White Brown

• Metra OE: Connect the steering wheel control Key 1 wire to the (Gray) Brown wire.

• Kenwood or select JVC with a steering wheel control wire: Blue/Yellow Connect the

wire to the wire.Brown

If the Note: Kenwood radio auto detects as a JVC, manually set the radio type to

Kenwood Changing Radio Type. See the instructions under .

• Connect the steering wheel control SWC-2 wire from the radio to the wire.XITE: Brown

• Parrot Asteroid Smart or Tablet:

Connect the 3.5mm jack to the AX-SWC-PARROT (sold

separately). Then connect the 4-pin connector from the AX-SWC-PARROT to the radio

The radio must be updated to rev. 2.1.4 or higher software.Note:

• Universal “2 or 3 wire” radio: Connect the steering wheel control wire, referred to as

Key-A or SWC-1, to the Brown wire from the connector. Then connect the remaining

steering wheel control wire, referred to as Key-B or SWC-2, to the Brown/White wire

from the connector. If the radio comes with a third wire for ground, disregard this wire.

Note:

After the interface has been programmed to the vehicle, refer to the manual provided with

the radio for assigning the SWC buttons. Contact the radio manufacturer for more information

• For all other radios: Connect the 3.5mm jack from the

ASWC-1 harness

to the jack on

the radio designated for an external steering wheel control interface. Please refer to the

aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.

INSTALLATION
