Side 1/16

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-ADCH03

I N S TA L L A T I O N I N S T R U C T I O N S

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder,

and heat shrink • Small ﬂat-blade screwdriver

• Tape • Wire cutter • Zip ties

TABLE OF CONTENTS

Connections to be made

For models

without

an ampliﬁer .......................3

For models

with

an ampliﬁer ............................4

Installing & programming the AX-ADCH03

AX-ADBOX1 ...........................................................5

AX-ADBOX2 ..........................................................6

Adjusting the AX-ADCH03 .....................................7

Chrysler Data Interface 2013-up*

APPLICATIONS

See inside front cover

• Provides accessory power (12-volt 10-amp)

• Maintains the retained accessory power (R.A.P.) feature

• Can be used in non-ampliﬁed, or ampliﬁed models

• Provides NAV outputs (parking brake, reverse, speed sense)

• Pre-wired ASWC-1 harness (ASWC-1 sold separately)

• Retains the factory backup camera†

• Retains the factory AUX-IN jack

• Retains balance and fade*

• Micro “B” USB updatable

• AX-ADCH03 harness

*Visit AxxessInterfaces.com for up-to-date vehicle speciﬁc applications.

INTRODUCTION

The AX-ADCH03 harness is designed for, and must be used with, the

AX-ADBOX1 or AX-ADBOX2 interface (sold separately). Please refer to the

AX-ADBOX1 or AX-ADBOX2 for the 16-pin connector with stripped leads.

† Only if the camera is displayed on the factory radio

* To retain fade in ampliﬁed models, use the AX-ADBOX1

APPLICATIONS

CHRYSLER

200 LX 2015-2016

DODGE

Dart (small screen option) 2013-2016

JEEP

Cherokee (Sport trim) 2014-2017

Compass (Sport trim) 2017.5-up

RAM

1500/2500/3500

(small screen option) 2013-2017

Chassis Cab 3500, 4500, 5500

(small screen option) 2013-2017
