The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THE ABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFT Front (+) Input
WHITE/BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THE ABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFT Front (+) Input
WHITE/BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THE ABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFT Front (+) Input
WHITE/BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THE ABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFT Front (+) Input
WHITE/BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THE ABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFT Front (+) Input
WHITE/BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
The AX-ADCT2 should be installed on a stereo’s speaker
output wires or the output wires on an OEM amplier of up to 80
watts per channel. These wires can be found behind the stereo
in the dash, on the outside of an OEM amplier, or on the input
terminals on the OEM speakers.
Wire Color & Function: The audio input wire colors are an EIA
standard for car stereo applications as follows:
YELLOW = BATTERY +12V Input
BLACK = GROUND Input
BLUE = REMOTE +12V Output
THE ABOVE POWER WIRES CAN BE CONNECTED DI-
RECTLY TO THE AMPLIFIER BEING ADDED
WHITE = LEFT Front (+) Input
WHITE/BLACK = LEFT Front (-) Input
GRAY = RIGHT Front (+) Input
GRAY/BLACK = RIGHT Front (-) Input
BLACK/WHITE = Reference Ground (-) (REFERENCE
GROUND OPTIONAL IF NOISE IS PRESENT)
NOTE: Be sure that all audio input connections are polarized or
in phase with each other. That is, the positive output wires from
the audio source need to be connected to the corresponding
positive input wires of the AX-ADCT2. The same goes for the
negative audio wires. Failure to do this will result in poor bass
response and low quality audio.
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
© COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.
The AX-ADCT2 is designed to convert 2 channels of
speaker level audio into 2 channels of line level audio.
This allows for the installation of line level products
such as ampli ers, EQs and crossovers on systems
that do not have RCA line level outputs. In addition
this device will also detect the presence of an audio
signal and then generate a +12V output (veri ed by
an illuminated LED) that can be used to turn-on an
aftermarket ampli er.
Features:
80 Watts Maximum Input, Input Circuit Corrects
Crossover Distortion Commonly Found On Other
Brands of LOCs, 6:1 Step Down with Variable Output,
Gold Flashed RCAs, Attractive & Durable Enclosure.
The AX-ADCT2 will shut off 60 seconds after no signal
detected.

Produkt Specifikationer

Mærke: AXESS
Kategori: Ikke kategoriseret
Model: AX-ADCT2

Har du brug for hjælp?

Hvis du har brug for hjælp til AXESS AX-ADCT2 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret AXESS Manualer

AXESS

AXESS AXBUCH-MZ6V Manual

29 Juli 2025
AXESS

AXESS AXABH-CH3 Manual

29 Juli 2025
AXESS

AXESS AXDSPX-HK5 Manual

25 Februar 2025
AXESS

AXESS AXAMP-CH8 Manual

25 Februar 2025
AXESS

AXESS AXTC-MZ1 Manual

25 Februar 2025
AXESS

AXESS AXBUCH-TYCAM26V Manual

25 Februar 2025
AXESS

AXESS AXAMP-FD2 Manual

25 Februar 2025
AXESS

AXESS AXBUCH-TYCAM36V Manual

25 Februar 2025
AXESS

AXESS AXAMP-TY1 Manual

25 Februar 2025
AXESS

AXESS AXAMP-TY4 Manual

25 Februar 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Advantech

Advantech MIC-711-OX Manual

30 Juli 2025
Intellinet

Intellinet 713108 Manual

30 Juli 2025
Electro Harmonix

Electro Harmonix EU12AC-1000 Manual

30 Juli 2025
Advantech

Advantech PCIE-1753 Manual

30 Juli 2025
MXR

MXR Rockman X100 Manual

30 Juli 2025
MIPRO

MIPRO MI-909R Manual

30 Juli 2025
Advantech

Advantech AMAX-4870 Manual

30 Juli 2025
Advantech

Advantech IDK-1112P-50XGA2 Manual

30 Juli 2025
MIPRO

MIPRO MP-820 Manual

30 Juli 2025
Advantech

Advantech ARES-12290 Manual

30 Juli 2025
