Installation Instructions for AX-ADXSVI-AU1

REV. 9/26/2014 INSTAX-ADXSVI-AU1

(continued on next page)

AX-ADXSVI-AU1

Audi CAN interface 2006-2013

Caution: Metra recommends disconnecting the negative battery terminal before

beginning any installation. All accessories, switches, and especially air bag indicator

lights must be plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

AUDI

A3* 2006-2013

A4/RS 4/S4 w/ NAV 2005-2008

A4/RS 4/S4 2007-2008

A4/RS 4/S4* 2006

TT 2008-2013

*Note: Only for models with either a

Symphony Plus or NAV radio.

APPLICATIONS

FEATURES

Note: This harness must be used in conjunction with the AX-ADXSVI.

• Providesaccessory(12-volt10-amp)

• RetainsR.A.P.(retainedaccessorypower)

• ProvidesNAVoutputs(parkingbrake,reverse,andspeedsense)

• PrewiredASWC-1harness(ASWC-1soldseparately)

• Retainsbalanceandfade

• Micro“B”USBupdatable

Connections to be made

From the XSVI-AU1 harness to the aftermarket radio

(a) From the 12-pin harness:

• Connectthe wiretotheaccessorywire.Red

• Connectthe wiretotheilluminationwire,iftheaftermarketradiohasOrange

noilluminationwire,tapeoffthe wire.Orange

• Connectthe wiretotheampturnonwire(thiswiremustbeBlue/White

connectedtohearsoundfromthefactoryamplifier).

There is a wire on the 40-pin harness to connect as well.Note: Blue

Thefollowingwiresareforaftermarketmultimedia/navigationradiosthatprovide

thesewires(ifnotrequired,tapethemoffanddisregardthem):

• Connectthe wiretotheparkingbrakewire(ifapplicable).Light Green

• Connectthe wiretothereversewire(ifapplicable).Green/Purple

• The wirewillnotbeused,tapeitoffanddisregardit.Blue/Pink

Note: This wire will be on the 40-pin harness instead.

(b) From the 40-pin harness:

• Connectthe and wirestothegroundwire.Black Black/White

• ConnecttheYellow wiretothebatterywire.

• Connectthe wiretotheampturnonwire(thiswiremustbeconnectedBlue

tohearsoundfromthefactoryamplifier).

Thefollowingwireisforanaftermarketmultimedia/navigationradiothat

providesthiswire,ifnotrequired,tapeitoffanddisregardit:

• Connectthe wiretothespeedsensewire(V.S.S.),ifapplicable.Blue/Pink

INTERFACE COMPONENTS

•XSVI-AU1harness

TOOLS REQUIRED

•Cuttingtool•Tape•Crimpingtool

•Connectors(i.e.butt-connectors,bellcaps,etc.)

AX-ADXSVI-AU1

K PNOWLEDGE IS OWER

Enhance your installation and fabrication skills by

enrolling in the most cognized and spected re re

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for mo information and take steps re

toward a better t omorrow.

Metra recommends MECP

certified technicians

IMPORTANT WARNING

Thisproductincludesinstructionsforinstallationwhichmustbecarefullyfollowed.The

instructionsarewordedinsuchamannertoassumethattheinstalleriscapableof

completingthesetypeofelectronicinstallations.Ifyouareunclearastowhatyouare

instructedtodoorbelievethatyoudonotunderstandtheinstructionssoastoproperly

andsafelycompletetheinstallationyou should consult a technician who does have this

knowledge and understanding.

Failure to follow these instructions carefully and to install the interface as described

could cause harm to the vehicle or to safety systems on the vehicle. Interference with

certain safety systems could cause harm to persons as well. If you have any questions

in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.

For non-BOSE systems:

• Disregardthe RCA,itwillnotbeusedinthisapplication. White

• Disregardthe RCA,itwillnotbeusedinthisapplication.Gray

• Connectthe RCAtotheleftrearRCAoutput.Green

• Connectthe RCAtotherightrearRCAoutput.Purple

• Connectthe wiretotheleftfrontpositivespeakeroutput.White

• Connectthe wiretotheleftfrontnegativespeakeroutput.White/Black

• Connectthe wiretotherightfrontpositivespeakeroutput.Gray

• Connectthe wiretotherightfrontnegativespeakeroutput.Gray/Black

Tapeoffanddisregardthefollowingwires,theywillnotbeusedin 

thisapplication:

• The wires.Green,Green/Black,Purple,Purple/Black

For BOSE systems:

• Connectthe RCAtotheleftfrontRCAoutput.White

• Connectthe RCAtotherightfrontRCAoutputGray

• Connectthe RCAtotheleftrearRCAoutput.Green

• Connectthe RCAtotherightrearRCAoutputPurple

Tapeoffanddisregardthefollowingwires,theywillnotbeusedin 

thisapplication:

• TheGreen,Green/Black,Purple,Purple/Black,White,White/Black,

Gray,and wires.Gray/Black

Note: It is highly recommended that the radio being used has 2 sets

of RCA outputs to retain balance and fade; 3 sets if a sub-woofer amplifier

will be added.

• ThisharnessistobeusedinconjunctionwiththeoptionalASWC-1(not

included)toretainsteeringwheelcontrols.IftheASWC-1isnotbeing

used,disregardthisharness.Ifitwillbeused,pleaserefertotheASWC-1

instructionsforradioconnectionsandprogramming.

Note: Disregard the harness that comes with the ASWC-1.

Installing the AX-ADXSVI-AU1

• Connectthe12-pinharnessintotheAX-ADXSVIinterface(soldseparately).

• Connectthe40-pinharnessintothevehicle.

• Withallconnectionscompleted,reconnectthenegativebatteryterminal.

• Initializetheinterfacebyturningtheignitiononfor30seconds,thenturnthe

ignitionbackoff,thenbackonagain.

Troubleshooting

• IfthevehiclehasenginenoiseafterinstallingtheAX-ADXSVI-AU1,useAxxess

partnumberAX-AGL610,qty.(2).
