INSTAX-ADXSVI-CH2
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 2/23/15
CHRYSLER
200 2011-2014
300 2008-2010
Aspen 2008-2009
Sebring 2007-2010
Town&Country 2008-up
DODGE
Avenger 2008-2014
Caliber 2009-2012
Challenger 2008-2014
Charger 2008-2010
Dakota 2008-2011
Durango 2008-2013
GrandCaravan 2008-up
Journey 2009-2010
Magnum 2008-2009
Nitro 2007-2011
Ram1500 2009-2011
Ram2500/3500 2010-2011
RamChassisCab3500/4500/5500 2011
JEEP
Commander 2008-2010
Compass 2009-up
GrandCherokee 2008-2013
Liberty 2008-2012
Patriot 2009-up
Wrangler 2007-up
MITSUBISHI
Raider 2008-2009
RAM
1500/2500/3500 2012
ChassisCab3500/4500/5500 2012
C/VTradesman 2012-up
VOLKSWAGEN
Routan 2009-2013
AX-ADXSVI-CH2
2007-up Chrysler accessory and NAV output CAN harness
• Providesaccessory(12volt10amp)
• RetainsR.A.P.(retainedaccessorypower)
• Usedinnon-amplifiedsystems,orwhenreplacingamplifiedsystem
• ProvidesNAVoutputs(parkingbrake,reverse,andV.S.S.)
• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)
• Highlevelspeakerinput
• USBupdatable
Note: ThisharnessmustbeusedinconjunctionwiththeAX-ADXSVI
APPLICATIONS
WIRING THE AX-ADXSVI-CH2
• ConnecttheYellowwiretotheradio’s12voltbatteryormemorywire.
• Connectthe wiretotheradio’sgroundwire.Black
• Connectthe wiretotheignitionwireoftheaftermarketradio. Red
INSTAX-ADXSVI-CH2
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 2/23/15
• Connectthe wiretotheilluminationwireoftheaftermarketradio.Orange
Iftheaftermarketradiohasnoilluminationwire,tapeoffthe wire.Orange
• Connectthe wiretotheantennaturnonwireoftheaftermarketradio.Blue
• Connectthe wiretotheleftfrontpositivespeakeroutputoftheWhite
aftermarketradio.
• Connectthe wiretotheleftfrontnegativespeakeroutputoftheWhite/Black
aftermarketradio.
• Connectthe wiretotherightfrontpositivespeakeroutputoftheGray
aftermarketradio.
• Connectthe wiretotherightfrontnegativespeakeroutputofthe Gray/Black
aftermarketradio.
• Connectthe wiretotheradio’sleftrearpositivespeakeroutput.Green
• Connectthe wiretotheradio’sleftrearnegativespeakeroutput.Green/Black
• Connectthe wiretotheradio’srightrearpositivespeakeroutput.Purple
• Connectthe wiretotheradio’srightrearnegativespeakeroutput.Purple/Black
Thefollowingwiresarefortheaftermarketradiosthathavenavigationbuiltin.
• Connectthe wiretotheparkingbrakewireoftheaftermarketnavigationLight Green
radio(ifapplicable).
• Connectthe wiretotheVSSorspeedsensewireoftheaftermarket Blue/Pink
navigationradio(ifapplicable).
• Connectthe wiretothereversewireoftheaftermarketnavigationradioGreen/Purple
(ifapplicable).
• Cyclethekey,byturningtheignitiononfor30seconds.Thenoffandonagaintotest
theradio.
ASWC-1 (If INSTALLING)
AftertheXSVIisinitialized,plugintheASWC-1intothe12-pinharnessofthe 
AX-ADXSVI-CH2andrefertotheASWC-1instructions.
Caution: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
Note: Refer to the instructions included with the
aftermarket radio.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinst it ute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
